In this lesson,

2

00:00:01,200 --> 00:00:06,000

we look at the circuit description of the hard disk in the trigger small current related circuits

3

00:00:07,500 --> 00:00:10,533

How do we find the hard disk of the mobile phone in the drawings?

4

00:00:11,033 --> 00:00:14,200

For example, we open the mainboard schematic diagram

5

00:00:14,200 --> 00:00:16,433

and component diagram of Xiaomi 10

6

00:00:20,566 --> 00:00:24,266

We see that its position number is U5600

7

00:00:31,200 --> 00:00:33,300

We search it in the circuit diagram

8

00:00:33,866 --> 00:00:37,866

and we can find its description page, on page 57

9

00:00:40,400 --> 00:00:42,933

This chip is also called FLASH MEMORY

10

00:00:50,966 --> 00:00:53,833

First, let's look at the power supply of the hard disk

11

00:00:54,633 --> 00:00:57,700

We can directly look at the pins of the hard disk chip,

12

00:01:00,000 --> 00:01:01,800

VCC means power supply

13

00:01:12,633 --> 00:01:19,633

This power supply is called VREG_L17A_3P0, 3V power supply

14

00:01:20,966 --> 00:01:24,333

This 3V power supply is given by the power chip,

15

00:01:24,533 --> 00:01:26,633

and it is given to these pins,

16

00:01:26,633 --> 00:01:30,300

such as B8, B9, E8, etc.

17

00:01:33,000 --> 00:01:35,600

Let's look at another way to power the hard disk

18

00:01:37,200 --> 00:01:40,000

We see VCC on this pin of the hard disk

19

00:01:41,800 --> 00:01:44,200

These pins are all connected to a line,

20

00:01:44,333 --> 00:01:46,333

1.2V power supply

21

00:01:48,000 --> 00:01:50,733

This Xiaomi phone has two lines for power supply,

22

00:01:51,033 --> 00:01:54,733

one is 3V and the other is 1.2V

23

00:01:57,933 --> 00:02:01,333

Let's take a look at what else is described on the hard disk?

24

00:02:02,333 --> 00:02:07,533

We see UFS, UFS means that this hard disk is a UFS hard disk,

25

00:02:07,900 --> 00:02:13,266

that is, the hard disk particles with relatively fast transmission speed at present

26

00:02:14,466 --> 00:02:19,233

UFS0_RESET is reset signal of the hard disk,

27

00:02:19,600 --> 00:02:22,266

which is used by the CPU to reset the hard disk

28

00:02:22,766 --> 00:02:27,266

UFS0_REF_CLK is clock signal of the hard disk,

29

00:02:27,933 --> 00:02:30,100

which is also given by the CPU

30

00:02:32,333 --> 00:02:35,500

We can see which chip the power supply is connected to

31

00:02:35,500 --> 00:02:37,333

by looking at the circuit diagram,

32

00:02:37,766 --> 00:02:39,833

which means which chip is coming over

33

00:02:41,900 --> 00:02:45,500

Like UFSL0, UFSL1,

34

00:02:45,900 --> 00:02:49,066

these are the transmit data and receive data lines

35

00:02:49,300 --> 00:02:53,066

They are the data read and write channels between the hard disk and the CPU

36

00:02:53,066 --> 00:02:54,966

for transmitting high-speed data

37

00:02:59,000 --> 00:03:01,066

For example, during the boot process,

38

00:03:01,166 --> 00:03:03,533

the power supply of the hard disk is normal,

39

00:03:04,466 --> 00:03:07,033

and after the clock and reset are normal,

40

00:03:07,233 --> 00:03:12,133

the CPU will read the boot program stored in the hard disk through these 8 lines

41

00:03:15,100 --> 00:03:17,033

After booting, for example,

42

00:03:17,133 --> 00:03:19,366

we want to store a large-capacity thing,

43

00:03:19,600 --> 00:03:21,733

insert the mobile phone into the computer,

44

00:03:21,866 --> 00:03:23,266

and import a video,

45

00:03:23,633 --> 00:03:26,766

the transmission channel of the video is actually here

46

00:03:26,966 --> 00:03:28,966

Ok, here is the circuit of the hard disk

47

00:03:30,300 --> 00:03:31,766

That's it for this lesson
