1

00:00:00,166 --> 00:00:01,000

In this lesson,

2

00:00:01,000 --> 00:00:04,333

we will talk about the search of the main power supply in the bitmap

3

00:00:04,666 --> 00:00:05,900

In the last lesson,

4

00:00:06,066 --> 00:00:09,833

we learned the related circuit on the main power supply on this side of the mainboard

5

00:00:10,033 --> 00:00:13,533

Then on the other side of the mainboard where the main power supply occupys,

6

00:00:13,533 --> 00:00:15,833

Where does the main power supply lead to?

7

00:00:18,000 --> 00:00:22,366

Check if the resistor is grounded, if it is a 0 ohm resistor

8

00:00:23,333 --> 00:00:25,600

If it doesn't have a ground pin and goes to a chip,

9

00:00:25,600 --> 00:00:28,166

we also need to consider the line it goes to

10

00:00:30,933 --> 00:00:36,600

For example, this resistor R1992, the first pin is the main power supply,

11

00:00:36,866 --> 00:00:39,600

it is connected to the chip U1902

12

00:00:39,600 --> 00:00:42,333

and these two capacitors through the second pin

13

00:00:47,333 --> 00:00:48,566

If they are damaged,

14

00:00:48,566 --> 00:00:51,533

they can also cause leakage in the main power supply line

15

00:00:57,633 --> 00:00:58,866

Let's go back again,

16

00:00:59,033 --> 00:01:00,200

In the same way,

17

00:01:00,333 --> 00:01:06,733

this main power supply goes to the chip 12106_NM through the resistor R2118

18

00:01:08,900 --> 00:01:11,833

Of course, this chip is not installed on Xiaomi phones,

19

00:01:12,366 --> 00:01:14,600

including these two capacitors.

20

00:01:20,833 --> 00:01:28,366

The main power supply leads to the chip U1904 and the two capacitors C1961, C1960

21

00:01:29,100 --> 00:01:32,433

We don't care about the chip that contains NM in the logo

22

00:01:33,333 --> 00:01:35,600

The main power supply leads to the RF part,

23

00:01:35,733 --> 00:01:43,000

which is branched to the U1901 chip and two capacitors C1918 and C1919

24

00:01:43,100 --> 00:01:46,300

through the zero-ohm resistor R1910

25

00:01:46,700 --> 00:01:47,833

If they are damaged,

26

00:01:47,833 --> 00:01:50,500

they will cause leakage of the main power supply line

27

00:01:56,366 --> 00:02:01,000

The main power supply also goes to the zero-ohm resistor R1935,

28

00:02:01,533 --> 00:02:05,200

the other end of which is connected to the chip U1903

29

00:02:05,333 --> 00:02:10,266

and the capacitors C1947 and C1946

30

00:02:11,066 --> 00:02:14,733

Here, the main power supply is connected to the chip U2105

31

00:02:15,000 --> 00:02:21,533

and the capacitors C2112, C2111 through the resistor R2106

32

00:02:25,000 --> 00:02:30,933

Here, the main power supply goes to the chip U6001 and the two capacitors around it

33

00:02:34,800 --> 00:02:35,866

At the same time,

34

00:02:35,866 --> 00:02:40,366

it goes to the chip U4200 and the nine capacitors around it

35

00:02:41,933 --> 00:02:47,266

It also goes to the chip U5301 and the capacitor C5201

36

00:02:47,633 --> 00:02:48,700

At the same time,

37

00:02:48,700 --> 00:02:53,400

it goes to the chip U5200 and the five capacitors around it

38

00:02:54,266 --> 00:02:55,833

Okay, let's move on to the top

39

00:02:56,266 --> 00:03:00,000

The main power supply leads to this chip U5303

40

00:03:00,000 --> 00:03:05,333

and two capacitors C5333 and C4312 around it

41

00:03:06,333 --> 00:03:09,133

It also leads here to R2511,

42

00:03:09,600 --> 00:03:13,900

through it to these five capacitors and the chip U2500

43

00:03:18,933 --> 00:03:21,933

The main power supply goes to the chip U2501

44

00:03:21,933 --> 00:03:26,966

and four capacitors around it through the resistor R2516

45

00:03:33,300 --> 00:03:35,766

The main power supply also goes to this socket,

46

00:03:35,900 --> 00:03:38,766

and also to the component A0151

47

00:03:38,966 --> 00:03:40,300

Is this a capacitor?

48

00:03:40,466 --> 00:03:44,666

One end of it is grounded and the other end is connected to the main power supply

49

00:03:44,866 --> 00:03:46,300

It may be a capacitor

50

00:03:46,566 --> 00:03:50,700

Switch it to the circuit diagram, the capacitor usually starts with C,

51

00:03:51,266 --> 00:03:54,433

but this one is unique, it is named after A,

52

00:03:54,600 --> 00:03:56,333

then it is also a capacitor

53

00:03:57,133 --> 00:03:58,666

If the capacitor is damaged,

54

00:03:58,866 --> 00:04:00,933

it will also lead to electrical leakage

55

00:04:02,033 --> 00:04:04,200

We click here, select it,

56

00:04:04,433 --> 00:04:06,500

and click Find Bitmap Component

57

00:04:07,000 --> 00:04:10,566

If the socket has not been touched, generally we don't need consider it

58

00:04:11,000 --> 00:04:15,933

Well, these are the lines that the main supply leads to on the side of the big power supply

59

00:04:16,433 --> 00:04:21,833

that is, we can quickly find all the components to which the main power supply leads through the bitmap

60

00:04:23,133 --> 00:04:25,200

Ok, that's it for this leeson
