1

00:00:00,133 --> 00:00:06,166

In this lesson, we talk about the current phenomenon of power connection protection and its related circuits

2

00:00:07,500 --> 00:00:11,600

Let's first look at the common current phenomenon of power connection protection

3

00:00:11,900 --> 00:00:14,366

We power this mainboard with 4.2 volts,

4

00:00:14,733 --> 00:00:16,733

snap the battery to the battery holder,

5

00:00:17,133 --> 00:00:23,266

and we can see that the current jumps back and forth between 0-3-0-4-0-6 mA,

6

00:00:25,566 --> 00:00:30,933

and the jump is very fast, from 0 to 3 mA and goes to 0 soon

7

00:00:36,633 --> 00:00:39,933

This current phenomenon is the power connection protection

8

00:00:42,400 --> 00:00:44,666

After the normal mainboard is powered on,

9

00:00:45,000 --> 00:00:46,866

without pressing the power button,

10

00:00:48,000 --> 00:00:52,433

the current jumps from 0 to a dozen mA or tens of mA,

11

00:00:53,266 --> 00:00:55,100

and then returns to zero

12

00:00:56,000 --> 00:00:58,266

The current changes only once

13

00:00:59,866 --> 00:01:01,733

This is called power self-test,

14

00:01:02,400 --> 00:01:04,800

only available on individual mainboards

15

00:01:05,700 --> 00:01:09,466

The power connection protection is that when the power is connected once,

16

00:01:09,600 --> 00:01:11,400

the current will jump once,

17

00:01:12,066 --> 00:01:14,833

and then when the power is turned off and then connected,

18

00:01:15,166 --> 00:01:16,433

it will jump again

19

00:01:17,200 --> 00:01:19,733

There are similarities between the two cases,

20

00:01:20,300 --> 00:01:22,733

so we must pay attention to the distinction

21

00:01:23,033 --> 00:01:26,800

The power connection protection is that the current jumps very fast,

22

00:01:27,033 --> 00:01:29,466

and then returns to 0 immediately,

23

00:01:29,566 --> 00:01:32,433

and the current is very small, it is irregular

24

00:01:32,733 --> 00:01:35,633

As for the mainboard with normal power-on self-test,

25

00:01:36,033 --> 00:01:38,266

the current jumps to thirty or forty,

26

00:01:38,366 --> 00:01:42,000

then to fifty or sixty, and then returns to 0

27

00:01:42,933 --> 00:01:44,766

It has an incremental process

28

00:01:47,600 --> 00:01:52,333

Let's take a look at which circuits or components are related to power-on protection

29

00:01:52,933 --> 00:01:56,066

We learned earlier that in the power-on circuit,

30

00:01:58,400 --> 00:02:02,866

the power supply of the battery is converted into the main power supply through the charging chip,

31

00:02:03,533 --> 00:02:06,433

which is supplied to the power chip, display chip,

32

00:02:06,533 --> 00:02:09,533

WIFI chip or radio frequency

33

00:02:11,066 --> 00:02:13,733

What is the problem with the power connection protection?

34

00:02:14,433 --> 00:02:17,133

It is the main power supply that has a short circuit,

35

00:02:17,433 --> 00:02:20,600

which leads to the phenomenon of power connection protection,

36

00:02:21,733 --> 00:02:24,600

which causes the mobile phone to not be turned on

37

00:02:35,866 --> 00:02:38,000

Let's see where the main power lines go

38

00:02:38,633 --> 00:02:40,633

Here, we also need to pay attention

39

00:02:40,800 --> 00:02:46,366

This main power supply code VPH_PWR is commonly used on Xiaomi or Oppo

40

00:02:46,766 --> 00:02:51,333

There is also a code for the main power supply called VBAT_SYS,

41

00:02:51,433 --> 00:02:53,300

which is commonly used by Huawei

42

00:02:54,533 --> 00:02:57,966

Android phones generally use two codes on the drawing

43

00:03:03,000 --> 00:03:04,766

In the actual maintenance,

44

00:03:05,033 --> 00:03:08,533

what will cause this short circuit phenomenon in the main power supply,

45

00:03:08,766 --> 00:03:13,633

we conclude that any damage to the components connected to the main power supply line

46

00:03:13,700 --> 00:03:17,433

may cause the main power supply line to have connection protection

47

00:03:20,300 --> 00:03:23,233

How can we detect the short circuit of the main power supply?

48

00:03:23,700 --> 00:03:27,866

We use the diode gear of the multimeter to measure the diode value to ground,

49

00:03:28,066 --> 00:03:30,500

that is, the resistance value to ground

50

00:03:32,600 --> 00:03:36,333

If it shows 0, this is called a short circuit to ground,

51

00:03:36,533 --> 00:03:39,600

that is, the main power supply is short circuited

52

00:03:40,966 --> 00:03:43,133

If the main power supply is short-circuited,

53

00:03:43,300 --> 00:03:45,300

power-on protection will occur,

54

00:03:45,866 --> 00:03:48,400

so we call it power-on short-circuit

55

00:03:50,233 --> 00:03:52,166

Ok, that's it for this lesson
