1

00:00:00,166 --> 00:00:04,100

In this lesson, we talk about how to maintain the power connection protection

2

00:00:04,400 --> 00:00:07,966

We have learned the current phenomenon of power connection protection

3

00:00:08,466 --> 00:00:13,333

The current jumps quickly between 0-3-0-6-0-4-0mA

4

00:00:13,566 --> 00:00:16,700

This phenomenon is called power connection protection

5

00:00:17,000 --> 00:00:19,033

Let's take a look at how to repair it

6

00:00:19,266 --> 00:00:20,733

As we mentioned earlier,

7

00:00:20,833 --> 00:00:24,966

the power connection protection is caused by the short circuit on the main power supply

8

00:00:25,566 --> 00:00:27,833

We opened the curcuit diagarm of Xiaomi 10,

9

00:00:28,066 --> 00:00:31,433

and we also talked about how to find the main power supply in the drawing

10

00:00:31,800 --> 00:00:35,466

The code name of Xiaomi's main power supply is VPH_PWR

11

00:00:36,733 --> 00:00:40,033

We can directly search for the bitmap signal in the bitmap,

12

00:00:40,700 --> 00:00:42,500

and wen can see its specific line

13

00:00:44,833 --> 00:00:47,333

It can be said that when the bitmap is enlarged,

14

00:00:47,600 --> 00:00:50,700

we will see that the VPH_PWR line corresponds

15

00:00:50,700 --> 00:00:53,033

to the position of the components on the mainboard

16

00:00:54,166 --> 00:00:55,733

So in the actual maintenance,

17

00:00:56,133 --> 00:00:58,833

how should we maintain the power connection protection?

18

00:01:01,400 --> 00:01:03,566

We generally focus on two aspects

19

00:01:04,366 --> 00:01:06,866

The first is to check the appearance first,

20

00:01:07,633 --> 00:01:09,366

remove the mainboard from the phone,

21

00:01:10,833 --> 00:01:13,166

and first check the overall appearance of the mainboard

22

00:01:13,166 --> 00:01:14,966

to see if there is any problem

23

00:01:17,433 --> 00:01:22,133

We need to see if this mainboard has been repaired by maintenance personnel or customers,

24

00:01:23,066 --> 00:01:26,166

or has been disassembled by customers themselves

25

00:01:29,733 --> 00:01:31,966

If the chip on this mainboard has been repaired and

26

00:01:31,966 --> 00:01:33,966

the main power supply is connected to this chip,

27

00:01:34,666 --> 00:01:37,266

then we have to re-solder or replace the chip

28

00:01:45,566 --> 00:01:48,833

In terms of appearance, where else do we check?

29

00:01:52,266 --> 00:01:54,800

We need to see if the mainboard is corroded by water

30

00:01:55,766 --> 00:01:59,566

We can ask the customer, or we can observe it under the microscope,

31

00:01:59,833 --> 00:02:01,966

whether the mainboard is corroded by water

32

00:02:06,733 --> 00:02:09,766

If there is serious corrosion, such as capacitors,

33

00:02:10,133 --> 00:02:12,100

we first remove the capacitors,

34

00:02:14,533 --> 00:02:16,566

then measure the main power supply line,

35

00:02:16,833 --> 00:02:19,400

and use the diode gear of the multimeter to measure

36

00:02:19,400 --> 00:02:21,966

the ground impedance to see if there is a short circuit

37

00:02:26,766 --> 00:02:29,900

If the impedance to ground recovers to more than 200,

38

00:02:30,766 --> 00:02:33,433

it proves that we have found the cause of the fault

39

00:02:34,566 --> 00:02:39,233

It is this capacitor corrosion that leads to the short circuit of the main power supply,

40

00:02:39,733 --> 00:02:42,066

which leads to the power connection protection

41

00:02:46,633 --> 00:02:49,766

At this time, we can ignore this capacitor,

42

00:02:50,666 --> 00:02:52,900

because this is a filter capacitor,

43

00:02:54,133 --> 00:02:55,400

As we mentioned earlier,

44

00:02:55,900 --> 00:02:59,666

we only need to ensure that there are 3 filter capacitors on this line

45

00:03:00,333 --> 00:03:03,766

And there are a lot of filter capacitors on this main power supply line,

46

00:03:04,166 --> 00:03:06,133

so we don't need to care about it

47

00:03:12,866 --> 00:03:18,066

What should we do if we remove a capacitor and measure the ground impedance of the main power supply line

48

00:03:18,066 --> 00:03:20,466

and find that it is still a short circuit?

49

00:03:21,633 --> 00:03:25,466

We have to continue to find the capacitors that are corroded by water,

50

00:03:27,666 --> 00:03:31,466

that is, remove them one by one until we find the capacitors

51

00:03:31,466 --> 00:03:33,566

that cause the power connection protection

52

00:03:38,666 --> 00:03:43,000

Corrosion in the capacitor may cause a short circuit in the main power supply line

53

00:03:47,666 --> 00:03:49,733

Ok, that's it for this lesson
