1

00:00:00,200 --> 00:00:04,466

In this lesson, we talk about how to maintain the power connection protection

2

00:00:04,900 --> 00:00:08,233

In another case, if there is no problem with the capacitor,

3

00:00:08,366 --> 00:00:12,000

we should also pay attention to the chip during the investigation

4

00:00:12,400 --> 00:00:16,566

Let's get the mainboard and take a look at the chips that the main power supply leads to

5

00:00:16,966 --> 00:00:21,100

For example, Xiaomi 10, these chips, and these chips

6

00:00:22,366 --> 00:00:26,700

We focus on observing whether there is corrosion and there is water ingress

7

00:00:29,900 --> 00:00:31,700

Like this chip in this mainboard

8

00:00:34,766 --> 00:00:37,066

If the main power supply has lead to it,

9

00:00:37,833 --> 00:00:41,733

when we find that the chip is seriously corroded by water, like this,

10

00:00:41,800 --> 00:00:43,066

we must remove it

11

00:00:46,366 --> 00:00:50,233

That is, when we see chips that are seriously corroded by water,

12

00:00:50,666 --> 00:00:52,566

we also remove them one by one

13

00:00:56,933 --> 00:01:01,100

We take off a chip and measure the ground value of the main power supply line

14

00:01:01,500 --> 00:01:03,800

If it recovers to more than 200,

15

00:01:04,233 --> 00:01:08,933

it proves that it was the chip that got water ingress and a short circuit occurred,

16

00:01:09,366 --> 00:01:12,433

which caused the power connection protection failure

17

00:01:13,433 --> 00:01:17,433

We take off a chip and measure the ground value of the main power supply line

18

00:01:17,800 --> 00:01:19,700

If it is still shorted to ground,

19

00:01:20,033 --> 00:01:22,466

it means that the chip we suspect is fine

20

00:01:25,500 --> 00:01:29,966

At this time, we will continue to find other chips that are corroded by water

21

00:01:30,066 --> 00:01:34,200

until the line of the main power supply is no longer short-circuited

22

00:01:38,000 --> 00:01:41,600

When we remove a chip that is seriously corroded by water,

23

00:01:41,600 --> 00:01:44,733

the main power supply is no longer short-circuited,

24

00:01:45,666 --> 00:01:47,600

what should we do at this time?

25

00:01:50,666 --> 00:01:51,866

We re-solder the chip,

26

00:01:52,466 --> 00:01:55,633

which is to remove the residue on the surface of the chip,

27

00:01:55,766 --> 00:01:58,266

and reball it, and then install it

28

00:02:02,466 --> 00:02:04,133

If there is no short circuit,

29

00:02:04,133 --> 00:02:08,133

it means that the short circuit is caused by the residue after water corrosion

30

00:02:08,733 --> 00:02:11,400

In another case, if we re-solder the chip,

31

00:02:11,866 --> 00:02:13,500

the circuit is still shorted

32

00:02:13,900 --> 00:02:15,733

which means that the chip is damaged,

33

00:02:15,900 --> 00:02:17,733

then we have to replace the chip

34

00:02:18,333 --> 00:02:20,466

Here's how to exclude one by one

35

00:02:21,366 --> 00:02:23,633

If the chip is not corroded by water,

36

00:02:23,766 --> 00:02:25,166

it has not been repaired,

37

00:02:25,500 --> 00:02:27,600

but the mainboard has been heavily dropped

38

00:02:28,333 --> 00:02:31,566

The mainboard that is seriously dropped will be deformed

39

00:02:32,400 --> 00:02:34,866

The mainboard itself is a flat surface,

40

00:02:35,100 --> 00:02:37,366

and it becomes bent after being dropped

41

00:02:38,466 --> 00:02:40,500

We need to observe the chip at the bend,

42

00:02:40,500 --> 00:02:43,566

whether there is a main power supply line leading to this chip

43

00:02:44,233 --> 00:02:47,900

If there is, we take off the chip at the deformed position

44

00:02:49,600 --> 00:02:52,733

and measure the ground value of the main power supply line

45

00:02:52,733 --> 00:02:55,666

to see if the main power supply is short-circuited

46

00:03:03,866 --> 00:03:05,600

If it is not  shorted anymore,

47

00:03:05,766 --> 00:03:07,200

we're going to replace the chip,

48

00:03:07,366 --> 00:03:10,033

and installing a good chip will fix the fault

49

00:03:18,533 --> 00:03:21,233

If we remove the chip and measure the ground value,

50

00:03:21,500 --> 00:03:23,066

and it is still shorted,

51

00:03:23,866 --> 00:03:27,033

we will continue to find the chip in the deformed position

52

00:03:30,100 --> 00:03:33,866

The chip connected to the main power supply is the chip we are looking for

53

00:03:36,733 --> 00:03:39,433

Continue to check whether the next chip is broken

54

00:03:40,733 --> 00:03:43,600

Because when it falls, the mainboard is stressed,

55

00:03:43,933 --> 00:03:45,900

and the chip is damaged by force

56

00:03:47,133 --> 00:03:49,033

Ok, that's it for this lesson
