1

00:00:00,166 --> 00:00:04,833

In this lesson, we talk about the maintenance of protection after triggered,

2

00:00:04,966 --> 00:00:07,866

which we usually call short-circuit after triggered

3

00:00:08,233 --> 00:00:10,800

We mainly focus on the following four aspects

4

00:00:11,100 --> 00:00:14,466

The first is the current phenomenon of the protection after triggered

5

00:00:14,900 --> 00:00:17,833

The second is the understanding of this phenomenon

6

00:00:19,133 --> 00:00:22,766

The third is what electrical circuits are related to this phenomenon

7

00:00:23,266 --> 00:00:27,433

Fourth, how do we repair the fault of protection after triggered

8

00:00:27,933 --> 00:00:31,833

Let's first look at the current phenomenon of protection after triggered

9

00:00:35,233 --> 00:00:38,000

We power this mainboard with 4.2 volts,

10

00:00:39,466 --> 00:00:41,200

after pressing the power button

11

00:00:41,533 --> 00:00:44,166

The current jumps from 0 to 3mA

12

00:00:45,266 --> 00:00:50,066

We release the power button, it stops immediately and goes back to 0

13

00:00:50,700 --> 00:00:54,000

Let's take a look again, 0-3 mA,

14

00:00:54,233 --> 00:00:58,900

in fact, it will return to 0 even if we don't release the power button

15

00:00:59,166 --> 00:01:02,133

This phenomenon is called protection after triggered

16

00:01:02,500 --> 00:01:03,366

To sum up,

17

00:01:03,700 --> 00:01:07,100

the protection after triggered phenomenon of Android phones

18

00:01:07,200 --> 00:01:09,200

is that when we press the power button,

19

00:01:09,366 --> 00:01:12,333

it has a current jump, and the jump is very fast

20

00:01:13,500 --> 00:01:20,633

The common ones are 0-3 mA, 0-9 mA or 0-10 mA

21

00:01:26,933 --> 00:01:28,800

After we release the power button,

22

00:01:28,966 --> 00:01:30,900

the current returns to 0,

23

00:01:31,466 --> 00:01:35,600

even if we keep pressing the power button, it will return to 0

24

00:01:36,133 --> 00:01:39,233

How do we understand this protection after triggered phenomenon?

25

00:01:39,533 --> 00:01:41,066

Let's sum it up in words

26

00:01:42,033 --> 00:01:45,833

We adjust the voltage of the DC power supply to 4.3V,

27

00:01:46,166 --> 00:01:49,366

use the power cord to supply power to the mainboard battery holder,

28

00:01:49,866 --> 00:01:51,200

press the power button,

29

00:01:51,500 --> 00:01:55,233

and there will be a small current jump in the current display position

30

00:01:58,600 --> 00:02:00,966

What are the characteristics of this current jump?

31

00:02:01,266 --> 00:02:05,266

It is 0-10 mA, which will return to 0 immediately,

32

00:02:05,466 --> 00:02:09,800

or 0 to dozen mA, which will return to 0 immediately

33

00:02:13,333 --> 00:02:15,133

If we don't press the power button,

34

00:02:15,300 --> 00:02:16,733

it will no longer jump

35

00:02:18,533 --> 00:02:21,533

This phenomenon is called protection after triggered

36

00:02:23,800 --> 00:02:27,533

Let's take a look at which circuits are associated with this phenomenon

37

00:02:32,566 --> 00:02:36,200

We have learned the entire boot process of the boot circuit before

38

00:02:36,633 --> 00:02:38,833

The battery supplies power to the mainboard,

39

00:02:40,466 --> 00:02:42,633

the mainboard supplies power to the charging chip,

40

00:02:45,600 --> 00:02:49,433

the charging chip converts the positive pole of the battery to the main power supply,

41

00:02:49,966 --> 00:02:52,166

and then provides power to the power chip

42

00:02:55,033 --> 00:02:59,533

After the power chip works, It will give a voltage to the power button signal

43

00:03:02,466 --> 00:03:04,200

When we press the power button,

44

00:03:04,533 --> 00:03:08,400

the power supply chip outputs VBUCK power supply to the CPU,

45

00:03:08,700 --> 00:03:10,866

temporary storage and hard disk

46

00:03:13,333 --> 00:03:17,466

In addition, it also outputs LDO type power supply,

47

00:03:17,900 --> 00:03:20,633

which is also called small current power supply

48

00:03:22,900 --> 00:03:26,600

It will output these two types of power supply to the CPU,

49

00:03:26,600 --> 00:03:28,566

temporary storage and hard disk

50

00:03:29,466 --> 00:03:33,100

And which circuits cause the phenomenon of protection after triggered?

51

00:03:33,733 --> 00:03:37,666

First of all, we must know that this machine can be triggered

52

00:03:38,100 --> 00:03:43,000

Since it can be triggered, it has nothing to do with the positive pole of the battery

53

00:03:44,600 --> 00:03:45,866

It can be triggered

54

00:03:46,233 --> 00:03:49,000

It proves that the positive line of the battery,

55

00:03:49,200 --> 00:03:52,366

the main power supply line and the power-on signal line

56

00:03:52,366 --> 00:03:55,133

from the power-on button to the power chip are all OK

57

00:03:58,766 --> 00:04:01,266

These two lines are no problem,

58

00:04:01,800 --> 00:04:03,300

we don't consider them

59

00:04:06,333 --> 00:04:08,433

So what do we mainly consider?

60

00:04:13,500 --> 00:04:16,333

It is the power supply circuit of the power output,

61

00:04:16,600 --> 00:04:20,466

that is, the power supply circuit that is output to the CPU,

62

00:04:20,600 --> 00:04:24,633

temporary storage, and hard disk after the power chip is triggered

63

00:04:32,933 --> 00:04:35,500

What does this power supply line contain?

64

00:04:38,466 --> 00:04:41,700

It is all the components that the power supply leads to,

65

00:04:43,100 --> 00:04:46,466

either the capacitor on the power supply line is short-circuited,

66

00:04:46,766 --> 00:04:49,566

or the chip on the power supply line is short-circuited

67

00:04:59,600 --> 00:05:01,666

Under normal circumstances,

68

00:05:03,100 --> 00:05:05,700

to repair the fault of protection after triggered,

69

00:05:07,066 --> 00:05:10,466

we mainly consider the power supply circuits of the CPU,

70

00:05:10,466 --> 00:05:12,766

temporary storage, and hard disk

71

00:05:14,700 --> 00:05:16,733

Ok, that's it for this lesson
