1

00:00:00,566 --> 00:00:05,400

This lesson is about finding the circuit of the trigger protection in the circuit diagram

2

00:00:06,066 --> 00:00:07,500

As we learned earlier,

3

00:00:07,900 --> 00:00:12,566

the trigger protection is caused by the short circuit of the power output to the CPU,

4

00:00:12,700 --> 00:00:14,966

temporary storage, and hard disk

5

00:00:15,433 --> 00:00:17,866

Let's open Xinzhizao maintenance system,

6

00:00:18,166 --> 00:00:22,733

open the bitmap, component map, and mainboard circuit diagram of Xiaomi 10

7

00:00:26,166 --> 00:00:28,900

How can we quickly find the power supply of CPU,

8

00:00:28,900 --> 00:00:31,133

temporary storage, and hard disk?

9

00:00:33,333 --> 00:00:35,000

Let's find the CPU first

10

00:00:35,533 --> 00:00:38,466

The fastest way is to find the component map first

11

00:00:38,900 --> 00:00:40,933

There are labels on the component map

12

00:00:41,700 --> 00:00:47,233

For example, in this position, the U3100 chip is the CPU

13

00:00:48,300 --> 00:00:52,966

We open the circuit diagram and enter U3100 in the search bar

14

00:00:52,966 --> 00:00:55,900

to find the description of the CPU in the circuit diagram

15

00:00:59,133 --> 00:01:04,533

Here is the U3100-2, this is the description of some signals,

16

00:01:04,833 --> 00:01:07,233

it is not the power supply we are looking for

17

00:01:08,100 --> 00:01:09,733

We click to find the next one,

18

00:01:10,966 --> 00:01:13,566

this is not the power supply description

19

00:01:13,700 --> 00:01:15,300

We continued to find it,

20

00:01:15,533 --> 00:01:18,400

and when we find U3100-1,

21

00:01:19,966 --> 00:01:23,900

the label begins with VREG refers to the power supply

22

00:01:28,833 --> 00:01:32,433

Let's take a look, which pin of the CPU it goes to,

23

00:01:32,766 --> 00:01:34,833

and who supplies power to the CPU

24

00:01:35,166 --> 00:01:37,533

Of course, it is generally a power chip

25

00:01:38,200 --> 00:01:41,233

We can find which power chip supplies power to the CPU

26

00:01:41,666 --> 00:01:45,500

U3100-1, U3100-7

27

00:01:46,433 --> 00:01:49,933

These are the descriptions of the power supply of the CPU

28

00:01:52,166 --> 00:01:56,533

Let's see if it has any other power supply descriptions in other locations

29

00:02:02,133 --> 00:02:05,500

U3100-8 is the CPU power supply,

30

00:02:05,900 --> 00:02:10,266

and U3100-9 is also the CPU power supply

31

00:02:11,966 --> 00:02:15,766

Let's go back to the location U3100-7 we just found,

32

00:02:16,500 --> 00:02:19,566

let's take a look at the power supply of the CPU

33

00:02:19,900 --> 00:02:22,233

What is the purpose of finding the power supply?

34

00:02:22,533 --> 00:02:25,400

First, how many power supplies are there,

35

00:02:26,100 --> 00:02:30,000

and second, which power chip is the power supply of the CPU from?

36

00:02:30,433 --> 00:02:34,433

Because the power supply of the CPU is provided by the power chip

37

00:02:49,000 --> 00:02:52,800

In a mobile phone mainboard, there is more than one power chip,

38

00:02:53,333 --> 00:02:55,566

and there may be multiple power chips

39

00:02:58,000 --> 00:02:59,133

Let's take a look

40

00:02:59,300 --> 00:03:03,266

For example, this VREG_0P75,

41

00:03:03,800 --> 00:03:06,600

it is a 0.75 volts power supply

42

00:03:07,666 --> 00:03:09,866

Let's see which power chip it comes from

43

00:03:10,200 --> 00:03:13,333

Let's first look at how many power supplies the CPU has

44

00:03:14,066 --> 00:03:16,633

We want to find the ones that are not repeated

45

00:03:17,000 --> 00:03:20,366

For example, here, U3100-1,

46

00:03:20,633 --> 00:03:24,200

we can see that there are 6 power supply descriptions here

47

00:03:33,366 --> 00:03:37,400

The power supply of the CPU in this page is the 11th description

48

00:03:41,000 --> 00:03:45,266

Here are S6A, S6C, 13 lines

49

00:03:46,566 --> 00:03:53,566

We see S7C, line 14, and here, 15, 16, 17, 18

50

00:03:55,933 --> 00:03:58,200

In the process of looking up its power supply,

51

00:03:58,600 --> 00:04:02,066

we will find that it is on the description of the power supply

52

00:04:02,466 --> 00:04:07,166

Maybe what we looked for in the front and what we looked for in the back will be repeated,

53

00:04:07,433 --> 00:04:11,966

because it is divided into pages to describe the power supply of the CPU

54

00:04:12,700 --> 00:04:13,933

For the power supply here,

55

00:04:14,033 --> 00:04:16,533

we don't need to know how many channels it has

56

00:04:17,266 --> 00:04:21,200

When we are repairing, as long as we measure every power supply,

57

00:04:21,333 --> 00:04:23,100

don't miss any power supply

58

00:04:24,666 --> 00:04:27,500

That is, when we search the circuit diagram,

59

00:04:27,500 --> 00:04:30,700

we find that it is very troublesome and repeated

60

00:04:31,133 --> 00:04:34,166

It has the same power supply in different page numbers

61

00:04:34,566 --> 00:04:37,400

In this case, we can check the drawings

62

00:04:39,400 --> 00:04:43,266

We need to find out how many channels of power supply this CPU has

63

00:04:43,633 --> 00:04:45,333

We first find the CPU,

64

00:04:46,066 --> 00:04:49,300

and then see which ones on the CPU are power supplies

65

00:04:52,600 --> 00:04:56,633

The labels that begin with V or VREG are the power supplies

66

00:04:58,400 --> 00:05:00,133

Ok, that's it for this lesson
