1

00:00:00,166 --> 00:00:05,200

We continue the lesson with the search of the power supply of the CPU that caused the trigger protection

2

00:00:05,800 --> 00:00:09,966

After finding the CPU, see which is the power supply of the CPU

3

00:00:10,433 --> 00:00:14,733

Those begin with V or VREG are all the power supplies

4

00:00:15,066 --> 00:00:16,166

Let's take a look

5

00:00:17,700 --> 00:00:21,300

Generally, Xiaomi and Huawei use more than 24 lines,

6

00:00:22,033 --> 00:00:24,433

and up to 35 lines of power supply

7

00:00:26,033 --> 00:00:30,866

This is the power supply of the CPU, temporary storage and hard disk together

8

00:00:31,233 --> 00:00:34,000

I will analyze one of the power supplies for you

9

00:00:34,200 --> 00:00:39,833

Such as U3100_9, this is the power supply for the CPU, why?

10

00:00:40,466 --> 00:00:42,200

Because this is a power supply,

11

00:00:42,200 --> 00:00:44,700

and at the same time it goes to the CPU,

12

00:00:45,000 --> 00:00:47,933

the CPU itself cannot generate electricity,

13

00:00:48,300 --> 00:00:50,933

then the power needs to be provided by other chips,

14

00:00:51,266 --> 00:00:54,200

so we say that this is the power supply of the CPU

15

00:00:55,666 --> 00:00:58,533

This is the power supply connected to the CPU chip,

16

00:00:58,900 --> 00:01:01,166

we call it the power supply of the CPU

17

00:01:01,400 --> 00:01:04,800

Another question is, where does this power come from?

18

00:01:05,800 --> 00:01:07,400

We double click on it,

19

00:01:07,833 --> 00:01:11,233

here we go to another part of the CPU, to another chip

20

00:01:11,733 --> 00:01:14,866

Of course, there is no CPU here, let's ignore it

21

00:01:15,333 --> 00:01:19,800

This is to U4200, let's see what chip it is

22

00:01:20,200 --> 00:01:24,533

We found that it was connected to a chip U4200

23

00:01:26,500 --> 00:01:30,900

The model of the U4200 chip is PM8250,

24

00:01:32,200 --> 00:01:35,066

and PM8250 is the power chip

25

00:01:37,433 --> 00:01:41,166

This power supply, VREG_S4A_1P8,

26

00:01:41,766 --> 00:01:48,100

it is output by the 119 pin of the chip U4200, and then to the CPU

27

00:02:01,066 --> 00:02:05,666

This is to draw a conclusion that this power supply comes from the power chip

28

00:02:06,133 --> 00:02:10,000

In the process of supplying this power from the power supply to the CPU,

29

00:02:10,400 --> 00:02:14,700

it will also be supplied to other circuits, or chips on other circuits

30

00:02:19,866 --> 00:02:23,033

So, now we just look at the line it supplies to the CPU

31

00:02:24,300 --> 00:02:28,433

For example, it comes from the chip U5800 again

32

00:02:28,833 --> 00:02:30,100

That is to say,

33

00:02:30,166 --> 00:02:32,900

this power supply actually has many functions,

34

00:02:33,100 --> 00:02:35,400

and it needs to supply a lot of chips

35

00:02:36,400 --> 00:02:38,766

When we fix the trigger protection fault now,

36

00:02:38,900 --> 00:02:40,833

we can see the line to the CPU

37

00:02:43,800 --> 00:02:47,666

It leads to a lot of chips, let's not pay attention to it here

38

00:02:47,866 --> 00:02:51,633

We only find it to go to CPU U3100

39

00:02:51,833 --> 00:02:55,933

We just found it, it went to CPU U3100

40

00:02:57,033 --> 00:03:02,066

Then the search method of other power supply is the same, it is the same method

41

00:03:02,666 --> 00:03:05,533

Let me summarize the search for CPU power supply

42

00:03:07,800 --> 00:03:10,200

There are many power supplies for the CPU,

43

00:03:10,833 --> 00:03:13,266

which mainly come from the power supply chip

44

00:03:14,300 --> 00:03:16,966

There is a problem with the CPU powered lookup

45

00:03:18,066 --> 00:03:21,500

Second, it has a lot of ways and a lot of groups

46

00:03:21,866 --> 00:03:24,266

Third, it comes from the power chip

47

00:03:24,566 --> 00:03:27,700

So how to quickly determine the power supply of the CPU,

48

00:03:28,000 --> 00:03:29,666

we must pay attention to this

49

00:03:30,166 --> 00:03:32,133

First, it is a power supply,

50

00:03:32,633 --> 00:03:34,533

how to see that it is a power supply?

51

00:03:35,066 --> 00:03:41,533

The labels begin with VREG or V, or begin with VBUCK or VOUT,

52

00:03:41,766 --> 00:03:44,066

these are the signs of power supply

53

00:03:44,966 --> 00:03:47,933

Second, the CPU can only accept power

54

00:03:49,400 --> 00:03:52,566

Third, the power supply connected to the CPU chip,

55

00:03:53,000 --> 00:03:55,233

which is given to it by the power supply chip,

56

00:03:55,800 --> 00:03:59,033

which means that this power supply is given to it by other chips

57

00:04:02,733 --> 00:04:05,166

The power supply is given to it by the power chip,

58

00:04:05,400 --> 00:04:08,500

and it is regarded as the power supply of the CPU

59

00:04:10,966 --> 00:04:14,200

Well, this is the introduction to the power supply of the CPU

60

00:04:15,166 --> 00:04:17,000

Ok, that's it for this lesson
