1

00:00:00,966 --> 00:00:05,966

This class is about temporary power supply directly related to the trigger protection

2

00:00:07,733 --> 00:00:10,500

Many processors today are double-layered

3

00:00:11,433 --> 00:00:13,666

The upper layer is the temporary storage,

4

00:00:13,666 --> 00:00:17,800

that is, the running memory, and the lower layer is the CPU

5

00:00:24,533 --> 00:00:27,733

This is the processor commonly used in current mobile phones

6

00:00:33,400 --> 00:00:34,766

Because of its structure,

7

00:00:35,000 --> 00:00:37,400

regarding the temporary power supply problem,

8

00:00:38,166 --> 00:00:41,300

we do not need to distinguish it in the actual maintenance,

9

00:00:42,466 --> 00:00:44,700

that is, the temporary power supply

10

00:00:46,866 --> 00:00:49,133

There is no clear separation on the drawing,

11

00:00:49,633 --> 00:00:53,733

whether it is CPU power supply or temporary storage power supply

12

00:01:01,000 --> 00:01:04,833

We also need to pay attention to a problem through the structure

13

00:01:05,133 --> 00:01:07,966

The temporary storage is soldered on the CPU

14

00:01:08,033 --> 00:01:12,700

It means that the power supply for the temporary storage must come to the CPU first,

15

00:01:13,000 --> 00:01:16,533

that is, the power is first supplied to the CPU,

16

00:01:16,600 --> 00:01:19,133

and then connected to the temporary storage

17

00:01:26,833 --> 00:01:29,066

When we repair the trigger protection,

18

00:01:29,466 --> 00:01:32,833

we give the priority to checking the power supply of the CPU,

19

00:01:32,833 --> 00:01:35,200

temporary storage, and the hard disk

20

00:01:39,966 --> 00:01:41,700

This is what I said earlier

21

00:01:42,033 --> 00:01:46,300

When we check the short circuit of the CPU and the temporary storage power supply,

22

00:01:46,833 --> 00:01:48,766

we look at the two of them together

23

00:01:53,466 --> 00:01:58,666

Let's measure whether there is a short circuit in the power supply of the CPU or the temporary storage

24

00:01:59,466 --> 00:02:04,466

There is no need to distinguish the power supply between the CPU and the temporary storage

25

00:02:12,066 --> 00:02:13,466

Because of its structure,

26

00:02:13,966 --> 00:02:16,800

the temporary storage is welded on the CPU

27

00:02:17,000 --> 00:02:22,300

The power supply must first be supplied to the CPU and then supplied to the temporary storage

28

00:02:25,466 --> 00:02:27,566

So when we repair the trigger protection,

29

00:02:28,200 --> 00:02:31,133

we find out whether it is the CPU power supply,

30

00:02:31,666 --> 00:02:35,400

the temporary storage supply, or the hard disk power supply

31

00:02:35,533 --> 00:02:38,066

Which way of power supply has a short circuit,

32

00:02:38,566 --> 00:02:42,700

we don't need to distinguish which way the temporary stored power supply is

33

00:02:46,000 --> 00:02:50,500

We can directly test whether there is a short circuit in the power supply of the CPU

34

00:02:51,100 --> 00:02:53,533

This is a temporary power supply problem

35

00:02:54,633 --> 00:02:57,700

On the drawings, we see many descriptions

36

00:02:58,433 --> 00:03:02,333

For example, here is the description of the graphics card,

37

00:03:04,033 --> 00:03:07,400

The main description here is the power supply of the CPU

38

00:03:07,866 --> 00:03:11,000

This SM8250 is the CPU,

39

00:03:13,600 --> 00:03:17,800

and then LPDDR5 is described here, which is the running memory,

40

00:03:18,000 --> 00:03:20,333

but it is not clearly separated

41

00:03:20,633 --> 00:03:24,600

So in actual maintenance, we don't have to worry about this problem

42

00:03:25,133 --> 00:03:27,066

Okay, that's all for this lesson
