In this class, we talk about the search of CPU and the temporary storage power supply in the bitmap

2

00:00:05,566 --> 00:00:10,133

Trigger protection is mainly caused by the short circuits of the power output to the CPU,

3

00:00:10,333 --> 00:00:12,233

temporary storage, and hard disk

4

00:00:15,033 --> 00:00:18,566

Let's take a look at the lookup of these power supplies in the bitmap

5

00:00:19,166 --> 00:00:21,966

We open Xinzhizao intelligent maintenance system,

6

00:00:22,400 --> 00:00:27,633

and open the bitmap, circuit schematic diagram, and component map of Xiaomi 10

7

00:00:28,300 --> 00:00:30,733

We can directly check the component map

8

00:00:31,700 --> 00:00:34,733

This is what people who are just getting started can do

9

00:00:35,100 --> 00:00:39,833

People with basic knowledge can know what the chip does by observing the appearance

10

00:00:40,566 --> 00:00:43,500

Let's take a look at the U4700,

11

00:00:43,933 --> 00:00:45,633

the power management written here

12

00:00:46,000 --> 00:00:47,833

This is on the side of the hard disk

13

00:00:49,166 --> 00:00:54,066

On the other side, we can see that the position number is U4200,

14

00:00:54,366 --> 00:00:56,300

which is also the main power chip

15

00:00:56,300 --> 00:00:59,866

That is, on this mobile phone, it has two power chips

16

00:01:01,233 --> 00:01:03,166

Ok, we found U4200,

17

00:01:04,233 --> 00:01:09,000

we first click to the schematic diagram and search for U4200

18

00:01:09,533 --> 00:01:13,766

But what are we going to find? the output part of its power supply

19

00:01:14,400 --> 00:01:15,600

Let's keep looking

20

00:01:15,933 --> 00:01:18,833

Here, we find the U4200-4,

21

00:01:19,333 --> 00:01:21,833

this is the power it outputs to the outside

22

00:01:23,033 --> 00:01:25,366

VREG refers to the power supply

23

00:01:25,766 --> 00:01:30,233

This is on Xiaomi phone, VREG is powered by 1.8 volts

24

00:01:34,533 --> 00:01:35,766

Right click,

25

00:01:36,266 --> 00:01:40,433

look for the bitmap signal, it will automatically switch to the bitmap

26

00:01:41,000 --> 00:01:44,066

Then on this bitmap we can quickly see a phenomenon

27

00:01:44,533 --> 00:01:47,900

The same line, it will clearly display yellow

28

00:01:49,866 --> 00:01:53,800

then this shows that the yellow ones are all on the same line

29

00:01:55,166 --> 00:02:02,733

For example, VREG_S1A_S2A_S3A_0P75 in the lower left corner,

30

00:02:02,966 --> 00:02:06,000

it is a 0.75 V power supply

31

00:02:06,400 --> 00:02:11,500

The power supply starts with VREG comes from the chip U4200

32

00:02:11,733 --> 00:02:14,733

We know that it is a power chip on the component map

33

00:02:21,566 --> 00:02:26,533

Its power supply goes to L4301, L4302,

34

00:02:26,633 --> 00:02:28,800

and also to these capacitors

35

00:02:29,100 --> 00:02:31,733

These yellow highlights are where it leads

36

00:02:32,733 --> 00:02:38,500

Here it leads to U3100, U3100 is the CPU

37

00:02:39,000 --> 00:02:42,866

It goes to these pins of the CPU and powers the CPU

38

00:02:51,766 --> 00:02:55,933

Here we see that there are inductors, capacitors and the CPU

39

00:02:56,333 --> 00:02:57,766

In actual maintenance,

40

00:02:57,866 --> 00:03:02,200

generally we can quickly find the power supply of the CPU with only a bitmap

41

00:03:02,766 --> 00:03:04,266

Let's see how to find

42

00:03:04,733 --> 00:03:07,333

The periphery of the power chip is generally designed

43

00:03:07,333 --> 00:03:10,566

to output power from the power supply to the outside

44

00:03:11,333 --> 00:03:15,533

For example, this is the power chip U4200,

45

00:03:15,666 --> 00:03:17,766

it has a large inductor around it

46

00:03:18,233 --> 00:03:20,833

We usually look for large inductors first

47

00:03:21,133 --> 00:03:24,533

Then one end of the large inductor is connected to the power chip,

48

00:03:24,966 --> 00:03:27,333

and the other end is connected to the CPU

49

00:03:28,300 --> 00:03:31,566

We can see at a glance that this is the CPU power supply

50

00:03:32,000 --> 00:03:33,333

Let's find another way

51

00:03:33,700 --> 00:03:37,800

Here, the 3 inductors are combined together to power the CPU

52

00:03:38,366 --> 00:03:41,700

Click on this inductor L4404,

53

00:03:42,066 --> 00:03:44,266

one end of it is to the power supply,

54

00:03:44,433 --> 00:03:46,000

this end is the feedback,

55

00:03:46,200 --> 00:03:48,733

this end is its power supply adjustment,

56

00:03:49,200 --> 00:03:53,133

here is the output, the output powers the CPU

57

00:03:56,833 --> 00:04:01,166

This is to supply power to the CPU of the U3100

58

00:04:03,033 --> 00:04:04,900

Let's take a look at the other way

59

00:04:05,033 --> 00:04:10,400

This is two inductors in parallel to output a power supply to the U3100

60

00:04:12,266 --> 00:04:15,100

This line is also the power supply of the CPU,

61

00:04:15,466 --> 00:04:20,133

it starts with VREG, it is the root output of the power supply,

62

00:04:20,133 --> 00:04:23,300

and finally leads to U3100

63

00:04:24,100 --> 00:04:26,133

Then let's take a look at other lines

64

00:04:26,433 --> 00:04:31,700

For example, in this way, we click on the right side of L4303

65

00:04:32,300 --> 00:04:36,233

Its power supply is VREG_S4A_1P8

66

00:04:36,500 --> 00:04:38,866

which is a 1.8 volts power supply

67

00:04:39,100 --> 00:04:45,866

It can be quickly seen that the power supply of this route comes from the power supply chip U4200,

68

00:04:46,300 --> 00:04:49,333

which directly leads to the U3100

69

00:04:49,766 --> 00:04:55,066

The U3100 is the CPU, and its upper layer is the temporary storage

70

00:04:55,766 --> 00:04:58,133

As long as the power supply to the CPU,

71

00:04:58,466 --> 00:05:02,000

we can also see it as the power supply to the temporary storage

72

00:05:02,366 --> 00:05:04,533

Then, let's look at the inductor around it

73

00:05:04,866 --> 00:05:07,133

This one is also from the power supply,

74

00:05:07,466 --> 00:05:10,533

and the end of it is not connected to the CPU

75

00:05:10,900 --> 00:05:13,233

This end of it leads to other chips,

76

00:05:13,233 --> 00:05:16,366

so this power supply is not the power supply of the CPU

77

00:05:16,866 --> 00:05:18,466

Let's look at this again

78

00:05:18,600 --> 00:05:22,500

This end comes from the power supply chip U4200,

79

00:05:22,866 --> 00:05:25,900

but the other end of it also goes to other chips

80

00:05:26,333 --> 00:05:28,900

If it doesn't go to U3100,

81

00:05:29,166 --> 00:05:31,433

it is not the power supply of this chip

82

00:05:32,800 --> 00:05:34,800

Ok, that's it for this lesson
