In this lesson, we learn to find the hard disk power supply related to trigger protection in the bitmap

2

00:00:05,600 --> 00:00:08,600

We open Xinzhizao intelligent maintenance system,

3

00:00:08,900 --> 00:00:13,500

open the bitmap, circuit diagram, and component map of Xiaomi 10

4

00:00:13,933 --> 00:00:17,200

After we open the component map, we find this side,

5

00:00:17,333 --> 00:00:18,900

where the hard disk is written,

6

00:00:19,300 --> 00:00:24,066

and its location number is U5600, then it is the hard disk

7

00:00:25,000 --> 00:00:26,866

We switch to the circuit diagram,

8

00:00:27,033 --> 00:00:32,400

search for the U5600, and find the description of U5600

9

00:00:34,933 --> 00:00:36,933

We can see that it is the hard disk

10

00:00:38,933 --> 00:00:40,266

What are we looking for?

11

00:00:40,533 --> 00:00:42,400

We're looking for its power supply

12

00:00:43,266 --> 00:00:48,333

The power supply code starts with VCC, VDD or VREG

13

00:00:49,066 --> 00:00:54,200

What we see in this circuit is VREG_L17A_3P0,

14

00:00:54,400 --> 00:00:57,000

which is the 3V power supply of the hard disk

15

00:00:57,166 --> 00:01:01,433

Then the power supply below is VREG_L6A_1P2,

16

00:01:01,666 --> 00:01:03,833

which is a 1.2 volts power supply

17

00:01:05,733 --> 00:01:09,133

On this model, we see that it has two power supplies

18

00:01:09,333 --> 00:01:11,733

Then here, they are not power supplies,

19

00:01:12,000 --> 00:01:15,700

they are communication protocols, we have to find the power supply

20

00:01:16,400 --> 00:01:19,133

If the power supply circuit of the hard disk fails,

21

00:01:19,233 --> 00:01:21,366

it will lead to the trigger protection

22

00:01:22,100 --> 00:01:24,400

The hard disk we saw has two power supplies

23

00:01:25,066 --> 00:01:27,500

We switch to the bitmap, right-click,

24

00:01:27,833 --> 00:01:29,566

click to find the bitmap signal,

25

00:01:29,966 --> 00:01:32,466

and then it will automatically jump to the bitmap,

26

00:01:33,033 --> 00:01:36,966

We can directly see that U4200 is a power chip

27

00:01:38,666 --> 00:01:44,200

The 97th pin of the power chip VREG_L17A_3P0,

28

00:01:44,800 --> 00:01:47,333

this is the power output from the power supply

29

00:01:52,366 --> 00:01:55,133

These 4 capacitors are filter capacitors

30

00:01:55,533 --> 00:01:58,966

Then the purpose of this power supply is not to the filter capacitor,

31

00:01:59,233 --> 00:02:00,266

where does it go?

32

00:02:00,866 --> 00:02:05,000

then it needs to go to the hard disk chip U5600

33

00:02:07,266 --> 00:02:10,666

What is one thing we often do when we actually repair it?

34

00:02:12,400 --> 00:02:16,100

For example, if the hard disk has been touched by others,

35

00:02:16,400 --> 00:02:20,233

you can test whether the power supply of this hard disk is short-circuited

36

00:02:21,433 --> 00:02:25,566

You can use this method to measure its ground value on the capacitors,

37

00:02:26,033 --> 00:02:29,433

that is, use the diode gear to measure the ground value

38

00:02:32,500 --> 00:02:34,433

If the measured value is 0,

39

00:02:35,200 --> 00:02:38,566

it means that there is a short circuit in the power supply of the hard disk

40

00:02:42,466 --> 00:02:44,400

Switch back to the circuit diagram,

41

00:02:44,766 --> 00:02:47,200

this is the 3 volts power supply line,

42

00:02:47,500 --> 00:02:49,533

we double-click this power supply,

43

00:02:49,766 --> 00:02:52,133

then right-click, select this,

44

00:02:52,566 --> 00:02:54,633

and click to find the bitmap signal

45

00:02:55,533 --> 00:02:58,666

This power supply can be clearly displayed on the bitmap

46

00:02:59,033 --> 00:03:02,633

Let's see if it's powered, if it's what we're looking for

47

00:03:05,100 --> 00:03:08,066

It's the 12th pin output of the power supply

48

00:03:08,500 --> 00:03:11,833

Its name is VREG_L6A_1P2

49

00:03:12,133 --> 00:03:15,900

The source of this power supply is here, and it comes from here

50

00:03:16,433 --> 00:03:18,500

After the 3 filter capacitors,

51

00:03:18,766 --> 00:03:22,800

it is divided into two channels, one is to the hard disk,

52

00:03:22,800 --> 00:03:24,800

and the other is to the CPU

53

00:03:27,400 --> 00:03:31,300

It is the power supply of the hard disk and the power supply of the CPU

54

00:03:33,766 --> 00:03:38,200

This is another power supply for the hard disk, 1.2V power supply

55

00:03:38,666 --> 00:03:40,000

In the actual measurement,

56

00:03:40,233 --> 00:03:42,466

we have to judge the power supply of the hard disk,

57

00:03:42,666 --> 00:03:45,000

to test whether its voltage is normal,

58

00:03:45,000 --> 00:03:46,866

or whether it has a short circuit,

59

00:03:47,066 --> 00:03:49,633

how should we measure it, and where should we measure it?

60

00:03:51,100 --> 00:03:53,600

The method is the same as what I just said,

61

00:03:53,800 --> 00:03:55,266

we can find the capacitor,

62

00:03:55,433 --> 00:03:57,533

and set the multimeter to the diode gear

63

00:03:59,200 --> 00:04:01,666

The red test lead is connected to the ground wire,

64

00:04:02,800 --> 00:04:05,600

and the black test lead is connected to the capacitor

65

00:04:09,700 --> 00:04:14,533

Both ends of the capacitor can be used because they are all connected to one line

66

00:04:18,266 --> 00:04:20,400

When the ground value we measure is 0,

67

00:04:20,600 --> 00:04:22,500

it means that it is a short circuit

68

00:04:22,700 --> 00:04:25,866

When we measure a certain value, we don't care about it

69

00:04:30,666 --> 00:04:34,033

This is the way to find the power supply of the hard disk in the bitmap,

70

00:04:34,166 --> 00:04:35,500

and the judgment method

71

00:04:41,233 --> 00:04:43,066

Ok, that's it for this lesson
