1

00:00:00,300 --> 00:00:03,900

In this class, we will talk about how to repair the trigger protection

2

00:00:04,000 --> 00:00:07,900

caused by the short circuit of the CPU and the temporary storage power supply

3

00:00:08,433 --> 00:00:09,800

As we mentioned earlier,

4

00:00:09,866 --> 00:00:13,500

short circuits in the power supply of CPU, temporary storage,

5

00:00:13,600 --> 00:00:15,700

and hard disk are the most common

6

00:00:17,133 --> 00:00:20,866

Let's take a look, how do we repair it when this happens?

7

00:00:21,266 --> 00:00:22,700

As mentioned earlier,

8

00:00:22,833 --> 00:00:25,966

how to find its power supply and where to measure the power supply

9

00:00:26,900 --> 00:00:28,900

Today we talk about how to repair

10

00:00:36,000 --> 00:00:39,033

First observe the capacitors and chips on this line,

11

00:00:39,233 --> 00:00:41,466

whether there is water corrosion around them

12

00:00:42,000 --> 00:00:43,333

This is number 1

13

00:00:45,400 --> 00:00:47,766

We first observe the capacitor on this line,

14

00:00:48,400 --> 00:00:50,366

the chip connected to this line,

15

00:00:50,700 --> 00:00:54,333

and whether there is water corrosion around the capacitor and the surface

16

00:00:57,500 --> 00:01:00,933

If we see that there is a capacitor corroded by water on this line,

17

00:01:01,033 --> 00:01:02,466

we remove it first,

18

00:01:04,500 --> 00:01:08,933

and then we measure the ground value of this line to see if it is still short-circuited

19

00:01:11,833 --> 00:01:13,433

Then there are two cases

20

00:01:13,700 --> 00:01:16,666

In the first case, after we remove the capacitor,

21

00:01:16,766 --> 00:01:18,666

there is no longer a short circuit,

22

00:01:18,766 --> 00:01:22,166

indicating that the damage to the capacitor caused the short circuit

23

00:01:23,433 --> 00:01:27,733

If we just removed 1 or 2 capacitors, we don't have to replace them

24

00:01:36,800 --> 00:01:38,600

If it is still a short circuit,

25

00:01:38,966 --> 00:01:44,700

we have to continue to find the capacitor with water corrosion until it is no longer short circuited

26

00:01:54,866 --> 00:01:58,966

Okay, this is how to repair the capacitor with water corrosion on this line

27

00:02:02,266 --> 00:02:04,666

If the capacitor is not corroded by water,

28

00:02:04,933 --> 00:02:07,966

there are traces of corrosion around the chip on this line,

29

00:02:08,466 --> 00:02:11,033

and this chip is not sealed with black glue,

30

00:02:11,166 --> 00:02:12,500

how do we fix it?

31

00:02:18,333 --> 00:02:22,266

We take off the chip and measure this line to see if it is a short circuit

32

00:02:24,000 --> 00:02:26,066

We will encounter two situations

33

00:02:26,400 --> 00:02:30,333

First, after we remove the chip, it is no longer short-circuited

34

00:02:30,800 --> 00:02:33,866

We need to remove the tin residue on the surface of the chip,

35

00:02:34,133 --> 00:02:37,866

reball it, and then re-solder it and measure again

36

00:02:38,633 --> 00:02:42,166

If there is no short circuit, the fault has been repaired

37

00:02:42,866 --> 00:02:44,733

What is the cause of the short circuit?

38

00:02:44,966 --> 00:02:48,733

In fact, the impurities after corrosion caused the short circuit,

39

00:02:48,933 --> 00:02:50,400

and the chip was not damaged

40

00:02:52,166 --> 00:02:56,033

In the second case, after re-soldering and measuring again,

41

00:02:56,300 --> 00:02:58,266

the line is still short-circuited,

42

00:02:58,700 --> 00:03:02,466

indicating that the chip is damaged and the short-circuit is caused,

43

00:03:03,000 --> 00:03:05,500

and we can repair it by replacing the chip

44

00:03:10,866 --> 00:03:15,300

If the circuit is still short-circuited after removing the chip and measuring again,

45

00:03:15,533 --> 00:03:19,600

we will use the burn-in method to be discussed in the next lesson to repair it

46

00:03:24,100 --> 00:03:27,966

Ok, this is how to repair the short circuit caused by water corrosion

47

00:03:30,066 --> 00:03:31,700

That's all for this lesson
