1

00:00:00,833 --> 00:00:06,800

In this lesson, we will talk about how to repair the short circuit of CPU and the temporary storage power supply

2

00:00:07,500 --> 00:00:11,900

When there is a short circuit in the power supply line of the temporary storage and CPU,

3

00:00:12,266 --> 00:00:15,966

there is no water ingress and corrosion, how do we repair it?

4

00:00:16,466 --> 00:00:19,800

First of all, we turn the multimeter to the diode gear

5

00:00:19,800 --> 00:00:22,266

to measure the capacitor around the power supply

6

00:00:23,800 --> 00:00:26,333

We measure the ground value on the capacitor

7

00:00:26,666 --> 00:00:30,066

Find the specific power supply that has a short circuit to ground

8

00:00:33,766 --> 00:00:36,466

When we find the circuit, what should we do?

9

00:00:36,800 --> 00:00:40,333

We can use the burn-in method to quickly find the component on the circuit

10

00:00:43,300 --> 00:00:44,400

Let's take a look

11

00:00:44,700 --> 00:00:48,733

First, use a DC power supply to output a voltage of about 1V

12

00:00:50,100 --> 00:00:53,033

Do not open the protection at the current position

13

00:00:56,466 --> 00:01:01,233

This is the power cord, with positive, negative, and alligator clips

14

00:01:01,833 --> 00:01:05,700

The clip of the negative pole should be clamped on the shield of the mainboard

15

00:01:07,466 --> 00:01:11,200

The shield is the negative pole of the battery, and they are connected

16

00:01:15,000 --> 00:01:16,633

Solder a wire to the circuit,

17

00:01:17,600 --> 00:01:23,133

the other end of this wire, we clamp it with the positive clip to see where the heat is

18

00:01:28,233 --> 00:01:30,966

Smoke rosin, then clip it on

19

00:01:31,633 --> 00:01:33,366

The negative clip is grounded,

20

00:01:33,866 --> 00:01:36,733

and the positive clip is used to clamp this wire

21

00:01:37,266 --> 00:01:38,366

At this time,

22

00:01:38,666 --> 00:01:43,333

the short-circuited components will melt the rosin we smoked on the surface

23

00:01:43,900 --> 00:01:48,100

We find the faulty component by looking at the location of the melted rosin

24

00:01:49,400 --> 00:01:54,100

The maintenance of CPU, temporary storage, and its power supply short circuit,

25

00:01:54,466 --> 00:01:57,233

including the power supply short circuit of the hard disk,

26

00:01:58,333 --> 00:02:00,233

the maintenance method is the same

27

00:02:02,200 --> 00:02:04,933

Let's take a look at how the burn-in method works

28

00:02:06,700 --> 00:02:11,200

We smoke the surface of the components connected to the power supply line with rosin,

29

00:02:16,266 --> 00:02:17,900

It is the power chip on the line,

30

00:02:18,200 --> 00:02:20,366

the rosin is smoked on the capacitor,

31

00:02:26,000 --> 00:02:31,000

In addition, we also smoke the surface and surrounding of the CPU with rosin

32

00:02:38,200 --> 00:02:42,433

After the rosin is smoked, we provide a power supply to the line

33

00:02:43,333 --> 00:02:46,800

We adjust the voltage to 1 volt, a safe voltage

34

00:02:55,666 --> 00:02:59,833

Then, we find a wire, solder one end to the short circuit,

35

00:03:00,166 --> 00:03:02,466

connect the other end to the red clip,

36

00:03:02,800 --> 00:03:04,866

and connect the black clip to ground

37

00:03:07,300 --> 00:03:10,133

Then we see where on the line the rosin melts

38

00:03:15,000 --> 00:03:17,166

Okay, that's all for this lesson
