1

00:00:00,300 --> 00:00:04,000

We will continue this lesson on maintenance for trigger protection

2

00:00:04,233 --> 00:00:07,033

If the rosin on the surface of the capacitor melts,

3

00:00:07,600 --> 00:00:09,433

then we directly remove it,

4

00:00:09,600 --> 00:00:12,866

and then measure the ground value to see if there is a short circuit

5

00:00:13,266 --> 00:00:18,100

In most cases, we removed the melted capacitor and then the fault was fixed

6

00:00:18,300 --> 00:00:22,333

After the capacitor is removed, we don't need to replace it

7

00:00:22,466 --> 00:00:24,433

Because it is a power supply line,

8

00:00:24,766 --> 00:00:28,133

the capacitor on the power supply line is a filter capacitor,

9

00:00:28,466 --> 00:00:30,900

it doesn't matter if we take one or two

10

00:00:31,466 --> 00:00:33,666

If the rosin on the power chip is melted,

11

00:00:34,300 --> 00:00:37,466

we remove the power chip and measure the ground value of this line

12

00:00:41,666 --> 00:00:43,366

There are two situations

13

00:00:43,600 --> 00:00:48,900

First, the line is no longer short-circuited, then we will replace the power chip

14

00:00:50,233 --> 00:00:54,300

Remove a good power supply chip from the mainboard and install it on the mainboard,

15

00:00:54,700 --> 00:00:56,733

the fault is basically repaired

16

00:00:57,333 --> 00:01:01,766

Second, if we remove the power chip and measure the ground value of this line,

17

00:01:02,966 --> 00:01:05,433

we find that it is still a short circuit

18

00:01:06,566 --> 00:01:08,933

This shows that the power chip is not damaged,

19

00:01:09,333 --> 00:01:10,966

it has nothing to do with it

20

00:01:11,500 --> 00:01:13,800

We can not rush to install the power chip

21

00:01:14,266 --> 00:01:18,533

We use the burn-in method with 1 volt to see if other places are melted

22

00:01:21,500 --> 00:01:24,666

Wherever it melts, we remove the components first,

23

00:01:24,800 --> 00:01:27,666

and then measure to see if there is still a short circuit

24

00:01:28,466 --> 00:01:31,666

Here's what to do when we find a problem with the power supply

25

00:01:31,966 --> 00:01:33,433

In the actual maintenance,

26

00:01:33,800 --> 00:01:39,133

if the surface of the CPU and hard disk is melted, we have to divide it into two situations

27

00:01:43,033 --> 00:01:45,600

First, this mainboard has not been repaired,

28

00:01:46,600 --> 00:01:48,400

it is an unrepaired machine,

29

00:01:48,633 --> 00:01:51,333

and there is no tin explosion around the CPU,

30

00:01:52,233 --> 00:01:54,500

and the mainboard has not been dropped heavily

31

00:01:57,400 --> 00:02:01,100

Because a heavy drop will cause the CPU position to be deformed

32

00:02:02,466 --> 00:02:07,800

In this case, we basically know that the possibility of CPU failure is relatively high,

33

00:02:08,033 --> 00:02:10,333

and there is basically no way to repair it

34

00:02:10,800 --> 00:02:13,633

Because the CPU cannot be replaced at will,

35

00:02:14,033 --> 00:02:15,766

it has encrypted module

36

00:02:16,133 --> 00:02:20,000

We are going to return the machine to the customer, this is irreparable

37

00:02:20,533 --> 00:02:25,166

The second situation is that when the mainboard has been repaired by maintenance personnel,

38

00:02:25,466 --> 00:02:28,800

or there are obvious tin beads around the CPU

39

00:02:31,833 --> 00:02:36,500

The reason for the existence of tin beads is that the welding method is improper,

40

00:02:37,533 --> 00:02:39,766

which leads to the explosion of tin

41

00:02:41,566 --> 00:02:44,933

So at this time, we have to re-solder the CPU

42

00:02:45,400 --> 00:02:48,533

After re-soldering, we measure the line again

43

00:02:50,200 --> 00:02:53,700

If it still has a short circuit, then basically,

44

00:02:53,766 --> 00:02:56,033

the machine has no maintenance value

45

00:02:56,600 --> 00:02:59,066

What is the reason for no maintenance value?

46

00:02:59,233 --> 00:03:03,833

It is caused by damage to the CPU, and the CPU cannot be replaced at will

47

00:03:04,066 --> 00:03:07,666

If we measure again, the supply line is no longer shorted,

48

00:03:07,966 --> 00:03:10,133

which means the fault is repaired

49

00:03:13,200 --> 00:03:14,400

what is the reason?

50

00:03:14,933 --> 00:03:19,633

It is the chip that has tin explosion, which is caused by human beings

51

00:03:22,000 --> 00:03:26,266

When soldering, the chip will explode due to the improper methods,

52

00:03:26,766 --> 00:03:28,866

and the tin will cause a short circuit

53

00:03:30,066 --> 00:03:31,900

Okay, that's it for this lesson
