1

00:00:00,133 --> 00:00:03,200

Our class is about maintenance for no trigger failures

2

00:00:03,633 --> 00:00:07,500

Not trigger is also called no response after pressing the power button

3

00:00:07,766 --> 00:00:10,133

We talk about it mainly from 4 aspects

4

00:00:10,366 --> 00:00:12,966

First, the understanding of this phenomenon

5

00:00:13,500 --> 00:00:16,633

Second, how is the current phenomenon of no trigger

6

00:00:17,000 --> 00:00:20,333

Third, which circuits are related to no trigger fault,

7

00:00:20,633 --> 00:00:23,466

or which circuits should we consider when repairing

8

00:00:24,833 --> 00:00:27,300

Four, how to repair no trigger failure

9

00:00:28,533 --> 00:00:34,033

What we mean by no trigger here is actually that the mobile phone cannot be turned on normally

10

00:00:35,466 --> 00:00:36,600

Then let's take a look

11

00:00:37,900 --> 00:00:41,233

First, let's take a look at the understanding of no trigger

12

00:00:44,800 --> 00:00:49,266

We use the DC power supply to transfer a voltage of 4.3 volts,

13

00:00:49,966 --> 00:00:53,766

and use the power cord to supply power to the battery holder of the mainboard

14

00:00:54,400 --> 00:00:59,900

We press the power button, or we find the power button signal on the power button base,

15

00:01:00,333 --> 00:01:02,800

and ground it for more than 5 seconds

16

00:01:10,166 --> 00:01:11,300

At this time,

17

00:01:11,866 --> 00:01:15,933

we see that the current display of the DC power supply is 0 mA,

18

00:01:16,533 --> 00:01:18,900

that is, there is no response

19

00:01:21,600 --> 00:01:24,900

This phenomenon is usually called trigger no response,

20

00:01:25,100 --> 00:01:28,033

or no current response when pressing the power button,

21

00:01:28,200 --> 00:01:30,600

and sometimes we call it no trigger

22

00:01:32,166 --> 00:01:34,900

This is a description of this phenomenon

23

00:01:35,600 --> 00:01:37,333

What is the essence of no trigger?

24

00:01:37,966 --> 00:01:40,200

That is, we press the power button,

25

00:01:40,700 --> 00:01:44,866

it does not respond to the current, we call it no trigger

26

00:01:45,533 --> 00:01:47,966

When we pull down the power button signal,

27

00:01:48,066 --> 00:01:51,600

there is a current response, this is called trigger

28

00:01:53,900 --> 00:01:56,966

Let's look at a display of this current of this phenomenon

29

00:01:59,066 --> 00:02:01,466

What kind of phenomenon is called no trigger?

30

00:02:02,066 --> 00:02:04,600

That is, when we get a mobile phone,

31

00:02:05,333 --> 00:02:08,833

we use the DC power supply to adjust it to more than 4 volts,

32

00:02:09,166 --> 00:02:11,466

usually 4 to 4.3 volts

33

00:02:14,000 --> 00:02:16,100

This is the current display position

34

00:02:16,433 --> 00:02:20,200

Then we use the power cord to buckle the battery holder on the mainboard

35

00:02:22,233 --> 00:02:23,866

Then press the power button,

36

00:02:26,133 --> 00:02:28,333

the current position has no response

37

00:02:28,833 --> 00:02:32,100

If the current doesn't respond, the phone just doesn't work,

38

00:02:32,800 --> 00:02:35,233

if it doesn't work, it doesn't turn on

39

00:02:36,433 --> 00:02:38,433

Okay, that's it for this lesson
