1

00:00:00,166 --> 00:00:04,333

In this lesson, we will talk about which circuits are related to no trigger

2

00:00:05,500 --> 00:00:09,600

As we mentioned earlier, the relevant circuit is the power-on circuit

3

00:00:10,266 --> 00:00:11,866

The first is the battery

4

00:00:12,366 --> 00:00:14,733

The battery provides a positive voltage

5

00:00:15,166 --> 00:00:18,466

We said that it is 4.3 volts at its highest

6

00:00:21,866 --> 00:00:25,266

This battery supplies power to the MOS tube in the charging chip,

7

00:00:25,500 --> 00:00:28,133

which is turned on under the control of the charging chip,

8

00:00:28,566 --> 00:00:34,433

and outputs a main power supply called VPH_PWR, or VBAT_SYS

9

00:00:38,600 --> 00:00:41,533

The charging chip converts the battery into the main power supply,

10

00:00:41,833 --> 00:00:44,966

and this main power supply is supplied to the power supply chip

11

00:00:45,900 --> 00:00:49,366

At this time, the power chip needs to work on standby,

12

00:00:50,233 --> 00:00:53,700

and it will give a voltage to the power-on button signal

13

00:00:57,700 --> 00:01:01,433

This voltage is 1.8 volts for Xiaomi and Huawei,

14

00:01:02,066 --> 00:01:05,733

and the voltage of Oppo phones is equal to the battery voltage,

15

00:01:05,900 --> 00:01:07,233

it is about 4 volts

16

00:01:10,133 --> 00:01:12,666

When we give it a voltage of 1.8V,

17

00:01:12,966 --> 00:01:14,433

we press the power button

18

00:01:16,233 --> 00:01:21,766

the power button signal is called PWRON, or KYPD_PWR

19

00:01:23,466 --> 00:01:28,166

Xiaomi's power button signal is called PHONE_ON_N

20

00:01:28,666 --> 00:01:32,700

As for Huawei, generally these codes are the power button signals

21

00:01:33,066 --> 00:01:35,766

We connect the power button signal to the ground wire,

22

00:01:36,100 --> 00:01:38,600

which is equivalent to pressing the power button

23

00:01:40,600 --> 00:01:43,600

Here's 1.8 or 4.3 volts

24

00:01:44,233 --> 00:01:48,166

As long as it is pulled down to the ground, more than 5 seconds

25

00:01:50,833 --> 00:01:53,500

Then, the power supply will output power to the CPU，

26

00:01:53,600 --> 00:01:56,266

temporary storage and the hard disk

27

00:02:01,033 --> 00:02:03,733

At this time, there will be a current

28

00:02:03,966 --> 00:02:06,466

So no trigger is no current response

29

00:02:07,166 --> 00:02:10,533

What is it related to? W e have to distinguish

30

00:02:11,000 --> 00:02:13,133

It has nothing to do with the part on the right

31

00:02:17,233 --> 00:02:19,800

Generally, we only consider 2 parts

32

00:02:20,166 --> 00:02:24,266

One part is here, converts from the battery power to the main power supply

33

00:02:25,700 --> 00:02:27,600

And the other part is the power chip itself

34

00:02:27,900 --> 00:02:30,333

From the circuit is here, here

35

00:02:30,633 --> 00:02:33,166

Whether the positive pole of the battery is normal,

36

00:02:33,333 --> 00:02:37,700

the main power supply is normal, and whether the power chip itself is normal

37

00:02:38,600 --> 00:02:40,800

Because if the power chip is abnormal,

38

00:02:41,266 --> 00:02:44,533

it has no way to output voltage to the power-on signal,

39

00:02:45,266 --> 00:02:47,400

even if there is main power supply to it

40

00:02:48,300 --> 00:02:50,700

First, the positive electrode of the battery

41

00:02:50,900 --> 00:02:53,066

Second, the main power supply

42

00:02:53,333 --> 00:02:54,933

Third, the power chip

43

00:02:56,133 --> 00:03:00,433

The line from the battery button to the power chip, this is the fourth

44

00:03:02,133 --> 00:03:04,333

We only consider these four parts

45

00:03:04,966 --> 00:03:09,366

That is, whether the voltage of the positive electrode of the battery is normal

46

00:03:09,700 --> 00:03:12,500

After the positive voltage of the battery is normal,

47

00:03:12,800 --> 00:03:15,266

whether the main power supply voltage is normal

48

00:03:15,866 --> 00:03:19,200

That is, whether its voltage has been pulled down,

49

00:03:19,433 --> 00:03:23,266

whether there is a problem, and whether the voltage can not be measured

50

00:03:23,800 --> 00:03:25,833

After these circuits are normal,

51

00:03:26,333 --> 00:03:29,733

we will see if there is any problem with the power chip itself

52

00:03:30,033 --> 00:03:33,200

If there is no problem, after getting the main power supply,

53

00:03:33,600 --> 00:03:36,566

it will output power to the power-on button signal

54

00:03:36,966 --> 00:03:41,233

The next thing to consider is the line from the power-on button to the power chip,

55

00:03:41,966 --> 00:03:44,100

also called the power-on signal line

56

00:03:46,733 --> 00:03:52,333

When we repair no trigger fault, we only consider these 4 circuits,

57

00:03:53,133 --> 00:03:55,833

including the positive electrode of the battery,

58

00:03:56,033 --> 00:04:01,566

the main power supply, the power chip itself, and the power-on signal line

59

00:04:02,400 --> 00:04:06,633

The power-on signal line is the line from the power-on button to the power supply,

60

00:04:08,000 --> 00:04:09,966

Okay, that's it for this lesson
