In this lesson we talk about how to repair no trigger faults

2

00:00:05,066 --> 00:00:07,400

According to the working process of the circuit,

3

00:00:07,666 --> 00:00:11,200

firstly, the positive power of the battery must be normal,

4

00:00:11,533 --> 00:00:14,100

and then when there is no problem with the charging chip,

5

00:00:14,266 --> 00:00:16,800

the main power supply can go to the power supply chip,

6

00:00:17,366 --> 00:00:22,600

and then the power supply can supply a 1.8V voltage to the power-on signal line,

7

00:00:23,366 --> 00:00:24,766

that is to say,

8

00:00:25,100 --> 00:00:28,966

the line from the power button circuit to the power supply should be normal

9

00:00:30,000 --> 00:00:32,500

In detail, there are 5 parts

10

00:00:33,133 --> 00:00:35,200

The positive circuit of the battery,

11

00:00:35,433 --> 00:00:36,500

the charging chip,

12

00:00:36,900 --> 00:00:39,300

the circuit of converting the main power supply,

13

00:00:39,500 --> 00:00:42,300

the power chip, and the power button circuit

14

00:00:42,633 --> 00:00:44,400

Ok, let's see how to repair

15

00:00:45,666 --> 00:00:48,900

We first observe whether the mainboard is corroded by water

16

00:00:50,633 --> 00:00:53,066

What about this water ingress corrosion

17

00:00:54,866 --> 00:00:57,433

We mainly look at the position of the power chip,

18

00:00:57,466 --> 00:01:00,833

and their circuits to see if it is corroded by water

19

00:01:03,833 --> 00:01:06,833

There is also the charging chip and its wiring,

20

00:01:06,866 --> 00:01:08,800

to see if it is corroded by water

21

00:01:09,200 --> 00:01:10,900

We focus on these

22

00:01:11,400 --> 00:01:13,533

If there is water ingress corrosion,

23

00:01:14,500 --> 00:01:16,400

we will deal with the corrosion first

24

00:01:16,733 --> 00:01:20,533

Dispose the corrosion and then power it up to see if it can be triggered

25

00:01:20,900 --> 00:01:23,100

If there is no water ingress corrosion,

26

00:01:23,400 --> 00:01:24,900

then what should we consider?

27

00:01:25,900 --> 00:01:28,300

We have to measure the voltage of the power button

28

00:01:28,633 --> 00:01:31,666

We should note that the voltage of Oppo's power button

29

00:01:31,666 --> 00:01:34,666

is equal to the battery voltage, about 4 volts

30

00:01:34,933 --> 00:01:38,566

Then Xiaomi and Huawei's power button voltage is 1.8 volts

31

00:01:39,200 --> 00:01:41,533

Use the voltage range of the multimeter to measure

32

00:01:41,533 --> 00:01:43,933

whether the voltage on the power button is normal

33

00:01:45,000 --> 00:01:48,566

The normal voltage of the power button is more than 1.7 volts

34

00:01:49,400 --> 00:01:51,400

This is basically no problem

35

00:01:52,800 --> 00:01:57,800

This is 1.8 volts, the error about 0.1 volts is no problem

36

00:01:58,366 --> 00:02:01,500

Ok, this is the boot voltage of 1.8 volts

37

00:02:02,466 --> 00:02:05,533

We are going to test to see if there is any problem

38

00:02:05,933 --> 00:02:06,966

Let's take a look

39

00:02:07,566 --> 00:02:10,033

The power button signal has different brands,

40

00:02:10,900 --> 00:02:13,000

and their pin definitions are different

41

00:02:14,233 --> 00:02:15,766

This is a Xiaomi phone,

42

00:02:16,133 --> 00:02:20,233

the power button signal of Xiaomi phone is called PW_ON,

43

00:02:20,633 --> 00:02:22,366

PW is the power

44

00:02:24,400 --> 00:02:27,366

It's called PHONE_ON_N here

45

00:02:29,100 --> 00:02:31,833

The voltage on the power-on button signal is actually

46

00:02:31,833 --> 00:02:34,300

added to the power-on line by the power supply

47

00:02:35,133 --> 00:02:39,166

Its English is this, which is always used by Xiaomi mobile phones,

48

00:02:39,333 --> 00:02:41,766

and the voltage on it is 1.8 volts

49

00:02:42,266 --> 00:02:45,500

So what about Huawei's power button? Let's take a look

50

00:02:45,600 --> 00:02:49,366

It is a voltage of 1.8 volts output by the power chip,

51

00:02:49,833 --> 00:02:53,466

which is a power supply, VOUT_PMUD

52

00:02:54,166 --> 00:02:57,466

Output this voltage to a 100K resistor,

53

00:02:57,933 --> 00:03:01,133

then the other end of the resistor is the signal end,

54

00:03:01,466 --> 00:03:04,333

we call it PWR_ON_N

55

00:03:06,200 --> 00:03:11,766

Then this end will go through the pull-up resistor, and there is a 1.8 volts

56

00:03:12,833 --> 00:03:17,533

Then the 1.8 volts voltage passes through this two-ohm resistor

57

00:03:18,200 --> 00:03:21,466

The power button holder also has a 1.8 volts

58

00:03:22,000 --> 00:03:23,600

This is the power-on signal

59

00:03:24,666 --> 00:03:27,466

This resistor cannot be short-circuited

60

00:03:28,400 --> 00:03:30,000

But for this resistor,

61

00:03:30,233 --> 00:03:35,733

we can generally choose 100K, 200K, both can be used

62

00:03:36,533 --> 00:03:39,000

When this resistor is falsely welded,

63

00:03:39,633 --> 00:03:43,133

there will be voltage on the left and no voltage on the right

64

00:03:44,666 --> 00:03:49,033

If there is no voltage on the right, then there is no voltage here

65

00:03:49,600 --> 00:03:51,066

There is no voltage here,

66

00:03:51,733 --> 00:03:55,266

we press the power button and there will be no response

67

00:03:56,000 --> 00:03:58,333

So this voltage is very important

68

00:03:59,600 --> 00:04:03,166

Let's take a look at the principle of Oppo 's power button signal

69

00:04:03,733 --> 00:04:05,233

The first is the battery

70

00:04:05,700 --> 00:04:09,900

The positive pole of the battery outputs a voltage of about 4 volts,

71

00:04:14,766 --> 00:04:19,700

The output voltage is given to this pull-up resistor, R2802

72

00:04:20,333 --> 00:04:23,400

This is one of the models we used as an example,

73

00:04:24,233 --> 00:04:27,333

and the location numbers of different models are different

74

00:04:28,266 --> 00:04:30,233

The resistor gets the voltage,

75

00:04:30,666 --> 00:04:34,533

then there is a voltage of about 4 volts on the power button signal

76

00:04:35,833 --> 00:04:40,400

This power button signal is called KYPD_PWR_N

77

00:04:40,900 --> 00:04:44,633

There is about 4 volts here, and it is about 4 volts here

78

00:04:45,400 --> 00:04:46,966

This is the same line

79

00:04:47,633 --> 00:04:49,366

There are about 4 volts here

80

00:04:49,600 --> 00:04:51,833

The power button also has 4 volts

81

00:04:55,400 --> 00:04:58,200

Here, ANT means antenna shrapnel

82

00:04:58,466 --> 00:05:00,900

Its power button is in the form of a shrapnel,

83

00:05:01,266 --> 00:05:04,933

not a boot room seat, not that kind of connector

84

00:05:06,666 --> 00:05:07,900

Here's how it works

85

00:05:08,733 --> 00:05:12,366

Its working principle is that when the battery voltage is normal,

86

00:05:12,900 --> 00:05:16,633

after the pull-up resistor, there is only a voltage here

87

00:05:16,933 --> 00:05:21,066

The voltage here is equal to the voltage of the positive electrode of the battery

88

00:05:21,666 --> 00:05:23,933

After there is a voltage of 4 volts,

89

00:05:24,433 --> 00:05:26,766

here and here are the same line,

90

00:05:27,333 --> 00:05:29,333

then there is a 4 volts at one end,

91

00:05:30,200 --> 00:05:35,100

after a 1K resistor, there will be a 4 volts at this end

92

00:05:35,400 --> 00:05:38,066

This is the power button signal of Oppo

93

00:05:39,166 --> 00:05:41,000

Okay, that's it for this lesson
