1

00:00:00,066 --> 00:00:03,766

In this lesson, we will talk about how to repair no trigger faults

2

00:00:04,466 --> 00:00:09,333

As we mentioned earlier, when the power button cannot be measured 1.8 volts,

3

00:00:09,766 --> 00:00:13,066

we can measure whether the 4 volts of the main power supply is normal,

4

00:00:13,500 --> 00:00:15,800

and we don't need to check the circuit diagram

5

00:00:16,333 --> 00:00:19,200

If the 4 volts can be measured around the power supply,

6

00:00:19,566 --> 00:00:21,666

it means the main power supply is normal

7

00:00:24,100 --> 00:00:25,766

If we can't measure the 4 volts,

8

00:00:26,066 --> 00:00:28,366

it means the main power supply is abnormal

9

00:00:29,300 --> 00:00:33,700

Let's take a look at where the main power supply is generally measured, and its voltage

10

00:00:34,300 --> 00:00:37,866

The voltage of the main power supply is equal to the voltage of the battery,

11

00:00:38,533 --> 00:00:42,833

if the battery voltage is 4.3 volts, it is 4.3 volts

12

00:00:43,266 --> 00:00:49,800

If the battery is low, only 3.8, 3.9, or 4 volts,

13

00:00:50,133 --> 00:00:51,566

we can measure 4 volts

14

00:00:52,100 --> 00:00:53,733

So where do we measure?

15

00:00:53,933 --> 00:00:55,100

When we get a mainboard,

16

00:00:55,100 --> 00:00:58,066

we can compare the bitmap or position map to measure

17

00:01:02,100 --> 00:01:06,200

Generally, we measure these capacitors around the main power supply,

18

00:01:06,366 --> 00:01:08,300

which is called blind measurement

19

00:01:08,633 --> 00:01:10,066

When we don't check the picture,

20

00:01:10,533 --> 00:01:12,500

we can measure the capacitors around it

21

00:01:12,833 --> 00:01:16,000

Generally, when measuring relatively large capacitors,

22

00:01:16,500 --> 00:01:17,833

we use the voltage gear

23

00:01:18,100 --> 00:01:19,900

If there is a voltage of 4 volts,

24

00:01:20,233 --> 00:01:24,066

but the power button has no voltage, what should we do at this time?

25

00:01:24,633 --> 00:01:26,766

We basically have to replace the power chip

26

00:01:27,300 --> 00:01:30,733

Ok, let's take a look at the conversion principle of the main power supply

27

00:01:31,233 --> 00:01:34,400

This is the common conversion principle of the main power supply,

28

00:01:34,700 --> 00:01:38,300

that is to say, how does the main power supply come from

29

00:01:41,333 --> 00:01:45,666

First, the positive pole of the battery supplies power to the charging chip

30

00:01:47,600 --> 00:01:50,566

The charging chip gets this power supply of about 4 volts,

31

00:01:50,933 --> 00:01:53,500

and its internal MOS tube will be turned on

32

00:02:00,066 --> 00:02:06,066

After it is turned on, it is directly converted into the main power supply, VPH_PWR

33

00:02:06,633 --> 00:02:08,833

This power supply outputs a voltage,

34

00:02:09,266 --> 00:02:11,300

which is equal to the battery voltage,

35

00:02:11,766 --> 00:02:13,333

and is given to the power chip

36

00:02:14,800 --> 00:02:17,900

This is the general conversion principle of the main power supply

37

00:02:18,800 --> 00:02:22,333

Let's take a look at Oppo phone's main power supply conversion principle

38

00:02:23,200 --> 00:02:25,100

Oppo mobile phones are special

39

00:02:25,666 --> 00:02:29,466

First of all, here is the positive electrode of the battery,

40

00:02:29,966 --> 00:02:34,000

which is turned on through a MOS tube, and then goes here directly

41

00:02:35,800 --> 00:02:38,666

First convert it into a battery reset power supply

42

00:02:38,800 --> 00:02:43,733

It's called VBT_RST, which is actually the positive pole of the battery,

43

00:02:44,133 --> 00:02:45,533

but the name has changed

44

00:02:48,700 --> 00:02:53,533

After the MOS tube, it arrives here and gives it to the charging chip

45

00:03:02,133 --> 00:03:04,866

The MOS tube inside the charging chip is turned on,

46

00:03:05,100 --> 00:03:08,800

the positive electrode of the battery is converted into the main power supply,

47

00:03:09,466 --> 00:03:11,566

and then supplied to the power supply chip

48

00:03:12,033 --> 00:03:15,200

The main power supply voltage equals to the battery voltage

49

00:03:17,766 --> 00:03:20,766

After we learn the conversion principle of the main power supply,

50

00:03:21,100 --> 00:03:23,200

When the main power supply is abnormal,

51

00:03:23,500 --> 00:03:25,766

we know how to consider the problem

52

00:03:35,433 --> 00:03:37,900

when we measure that the main power supply is 4 volts,

53

00:03:38,066 --> 00:03:40,766

but there is no 1.8 volts on the power button,

54

00:03:40,900 --> 00:03:42,500

what should we do at this time?

55

00:03:44,466 --> 00:03:48,233

We generally re-solder the power chip, or replace the power chip

56

00:03:49,533 --> 00:03:51,333

Okay, that's it for this lesson
