1

00:00:00,300 --> 00:00:03,466

In this lesson, we will talk about the maintenance of the fault that

2

00:00:03,466 --> 00:00:06,333

the mobile phone starts normally but cannot be displayed

3

00:00:07,066 --> 00:00:09,800

We talk about it mainly from the following aspects

4

00:00:10,466 --> 00:00:15,133

First, the current phenomenon that mobile phone starts normally but cannot be displayed

5

00:00:15,833 --> 00:00:18,466

Second, the general cause of this failure

6

00:00:19,233 --> 00:00:22,166

Third, the working condition of the display circuit

7

00:00:22,633 --> 00:00:25,900

Fourth, what circuit is related to the display circuit,

8

00:00:26,200 --> 00:00:28,600

or what the display circuit contains

9

00:00:30,366 --> 00:00:32,600

The last is how to repair this fault

10

00:00:34,900 --> 00:00:38,366

Let's take a look at the current phenomenon that the mobile phone does not display

11

00:00:38,366 --> 00:00:40,500

but can boot into the system normally

12

00:00:41,566 --> 00:00:44,400

When we repair a mobile phone that does not display,

13

00:00:44,900 --> 00:00:48,933

first of all, the premise is that the mobile phone can be turned on normally,

14

00:00:49,266 --> 00:00:52,033

that is, it can enter the system normally

15

00:01:02,833 --> 00:01:05,233

We mainly look at its take-off current,

16

00:01:05,700 --> 00:01:08,033

and whether the current can increase gradually,

17

00:01:08,200 --> 00:01:09,933

and reach a maximum current,

18

00:01:10,500 --> 00:01:13,766

and then fall back to about 100 to 200 mA

19

00:01:20,333 --> 00:01:24,133

Such a jump process is a process that can normally boot into the system

20

00:01:25,366 --> 00:01:27,866

When we see a mobile phone with such a current change,

21

00:01:28,000 --> 00:01:31,500

but it cannot display, the display does not respond,

22

00:01:32,500 --> 00:01:35,433

we think it just boots normally but doesn't display

23

00:01:39,766 --> 00:01:41,766

Okay, let's take a look at its current

24

00:01:42,433 --> 00:01:45,933

After pressing the power button, the current does not change

25

00:01:50,600 --> 00:01:52,600

Now the current jumps for a while,

26

00:01:53,033 --> 00:01:56,533

four or five hundred, more than five hundred to one ampere

27

00:01:59,800 --> 00:02:05,200

Now it's one thousand eighteen, one thousand seventeen, about two amps

28

00:02:07,000 --> 00:02:10,400

But some machines do not have such a large maximum current

29

00:02:11,033 --> 00:02:14,533

It's back down now, back down to three or four hundred

30

00:02:15,466 --> 00:02:18,933

At this time, it has actually entered the system

31

00:02:19,533 --> 00:02:21,633

When we see this current phenomenon,

32

00:02:22,133 --> 00:02:26,200

the phone can basically be concluded that it can be turned on normally,

33

00:02:26,333 --> 00:02:28,233

it just does not display

34

00:02:29,700 --> 00:02:32,833

At this time, we are going to repair the display circuit,

35

00:02:33,033 --> 00:02:37,600

and check whether it is a screen problem that causes the display not to be displayed

36

00:02:38,100 --> 00:02:42,166

Ok, this is the judgment of the current that can be turned on but not displayed

37

00:02:43,066 --> 00:02:46,500

Let's take a look, in the actual maintenance,

38

00:02:47,066 --> 00:02:49,866

many people regard the non-boot as the non-display,

39

00:02:50,266 --> 00:02:52,233

which has such a misunderstanding

40

00:02:52,966 --> 00:02:57,466

How to make sure that a mobile phone can be booted into the system but not displayed?

41

00:03:00,533 --> 00:03:02,633

There are mainly the following methods

42

00:03:03,433 --> 00:03:05,433

First, observe the current.

43

00:03:06,233 --> 00:03:09,866

We judge by the current entering the system when it is turned on normally

44

00:03:12,533 --> 00:03:16,900

This is the method we used just now, it is called the current method

45

00:03:23,033 --> 00:03:27,566

Second, install a SIM card in the phone and use another phone to dial the number

46

00:03:28,133 --> 00:03:30,666

If the phone has an incoming call prompt sound,

47

00:03:30,900 --> 00:03:35,233

it means that the phone can be turned on to enter the system, but does not display

48

00:03:38,600 --> 00:03:41,266

There is another method, for example,

49

00:03:41,666 --> 00:03:44,266

the display of the mobile phone cannot be displayed,

50

00:03:44,900 --> 00:03:46,700

but there is an alarm sound

51

00:03:47,600 --> 00:03:51,033

Indicates that the phone can be turned on but does not display

52

00:03:56,533 --> 00:03:58,533

Okay, that's it for this lesson
