1

00:00:00,166 --> 00:00:03,833

In this lesson we talk about the reasons for the failure to display

2

00:00:05,266 --> 00:00:08,833

If a mobile phone, we have determined that it can be turned on normally,

3

00:00:09,233 --> 00:00:10,666

but does not display

4

00:00:11,833 --> 00:00:14,200

Then what factors should we mainly consider?

5

00:00:18,000 --> 00:00:20,966

First, is there any problem with the screen?

6

00:00:21,633 --> 00:00:23,800

Is it because the screen is broken,

7

00:00:24,700 --> 00:00:27,766

since the screen is mainly responsible for displaying

8

00:00:28,700 --> 00:00:31,633

Second, if there is no problem with the screen,

9

00:00:32,033 --> 00:00:34,233

take a new screen to test the mainboard

10

00:00:36,633 --> 00:00:38,500

If it still does not display,

11

00:00:38,733 --> 00:00:41,300

it means that it is not the problem of the screen,

12

00:00:41,600 --> 00:00:43,766

it must be the problem of the mainboard

13

00:00:50,466 --> 00:00:55,233

Next, we need to learn the circuit principle and the maintenance method of the screen

14

00:00:55,466 --> 00:01:00,733

The reasons for not displaying are mainly the problem of the mainboard and the problem of the screen

15

00:01:13,766 --> 00:01:16,433

In the actual maintenance, for example,

16

00:01:16,733 --> 00:01:19,966

the screen is broken and it is broken like this

17

00:01:22,100 --> 00:01:24,600

And this screen has two-stage separation,

18

00:01:25,000 --> 00:01:26,966

then this screen must be damaged

19

00:01:32,166 --> 00:01:34,266

Some screens are corroded by water

20

00:01:36,400 --> 00:01:38,900

How to judge the general quality of this screen?

21

00:01:40,600 --> 00:01:45,033

First, the root of the screen cable is seriously corroded by water ingress

22

00:01:49,166 --> 00:01:51,500

Second, the screen is broken

23

00:01:52,300 --> 00:01:57,200

Of course, if the screen cable is broken, you don't have to think about it

24

00:01:57,866 --> 00:02:00,133

There must be a problem with the screen

25

00:02:05,800 --> 00:02:08,566

Third, by carefully observing the screen,

26

00:02:09,066 --> 00:02:11,033

we found that the inner screen burst,

27

00:02:11,666 --> 00:02:14,600

but the outer screen does not seem to have much problem

28

00:02:19,900 --> 00:02:24,333

Another is that the whole from the outer screen to the inner screen is obviously broken,

29

00:02:24,800 --> 00:02:27,566

so there must be something wrong with this kind of screen

30

00:02:39,100 --> 00:02:41,100

When there is no problem with the screen,

31

00:02:41,666 --> 00:02:46,400

the mainboard is very clean, no water corrosion, no deformation

32

00:02:52,900 --> 00:02:56,200

At this time, we generally do not consider the mainboard

33

00:02:57,566 --> 00:02:59,500

Well, this is how to judge the screen,

34

00:02:59,500 --> 00:03:01,933

from the appearance to see if the screen is damaged

35

00:03:02,766 --> 00:03:04,633

Ok, that's it for this lesson
