In this lesson, we will talk about the screen circuit principle of LCD backlight screen
2
00:00:08,866 --> 00:00:12,100
First, let's look at the working conditions of its circuit
3
00:00:13,533 --> 00:00:19,066
In general, the power supply of the backlight screen circuit has the following four power supplies
4
00:00:20,066 --> 00:00:21,300
1.8 volts,
5
00:00:22,633 --> 00:00:25,000
positive and negative voltage power supplies,
6
00:00:26,433 --> 00:00:28,800
VSP is positive voltage power supply,
7
00:00:29,500 --> 00:00:32,066
and VSN is negative voltage power supply
8
00:00:39,933 --> 00:00:43,900
LED+ and WLED are the positive poles of the backlight,
9
00:00:44,200 --> 00:00:46,433
which are the power supplies for the backlight,
10
00:00:46,733 --> 00:00:50,066
usually a high voltage of 14 to 21 volts
11
00:00:58,233 --> 00:01:02,566
When it reaches 14 volts, basically this screen can light up
12
00:01:03,333 --> 00:01:07,333
Well, there is another one that is 1.8 volts for this power supply
13
00:01:13,633 --> 00:01:15,666
What is shown here is the real thing
14
00:01:17,033 --> 00:01:19,400
There is a set of lamp beads behind the screen,
15
00:01:19,800 --> 00:01:21,900
which is the light source of the backlight
16
00:01:22,433 --> 00:01:26,266
These are all backlights, that is, light-emitting diodes
17
00:01:29,133 --> 00:01:33,033
Well, let's look at another working condition of it, reset
18
00:01:36,366 --> 00:01:38,900
This is generally described in the drawings
19
00:01:39,500 --> 00:01:43,266
The reset signal identifier starting with GPIO is Huawei's
20
00:01:49,433 --> 00:01:50,933
What does N mean?
21
00:01:51,366 --> 00:01:53,200
N means low level active
22
00:02:01,200 --> 00:02:03,400
The reset signal has a characteristic
23
00:02:03,566 --> 00:02:08,033
When it is high, there is a voltage, usually 1.8 volts,
24
00:02:08,300 --> 00:02:10,433
indicating that it has no problem
25
00:02:17,200 --> 00:02:19,500
Next we look at the detection signal
26
00:02:20,800 --> 00:02:24,033
There are two types of detection signals on the circuit,
27
00:02:24,333 --> 00:02:26,700
one is ID and the other is DET
28
00:02:27,033 --> 00:02:28,733
For example, in the drawing,
29
00:02:29,033 --> 00:02:32,400
what we see is a detection signal that starts with ID
30
00:02:37,066 --> 00:02:42,366
This display screen detection can read screen information, manufacturer information
31
00:02:48,433 --> 00:02:50,133
If there is a problem with it,
32
00:02:50,500 --> 00:02:53,166
it will also cause the phone to have a black screen
33
00:02:53,933 --> 00:02:57,366
OK, let's look at another operating condition, the bus
34
00:03:01,733 --> 00:03:06,500
On Android phones, the bus usually starts with DSI and has clock pins
35
00:03:13,633 --> 00:03:18,533
This is the clock signal of the bus, not the clock signal of the display
36
00:03:19,166 --> 00:03:22,666
This is DATA, which usually has 3 sets of data,
37
00:03:23,100 --> 00:03:28,433
that is, 6 roots, which are used to transmit image information
38
00:03:36,833 --> 00:03:40,033
Then there is the synchronization signal, TE,
39
00:03:40,333 --> 00:03:44,166
which has another name, called anti-tearing signal
40
00:03:53,766 --> 00:03:55,666
What is a key point we need to know?
41
00:03:56,433 --> 00:03:58,166
If the line is disconnected,
42
00:03:58,633 --> 00:04:01,433
or the components in the line are falsely welded,
43
00:04:01,900 --> 00:04:05,966
the signal cannot communicate with the screen and the CPU normally
44
00:04:07,533 --> 00:04:09,566
We call it an open circuit,
45
00:04:09,933 --> 00:04:13,666
which will cause a black screen, that is, no display
46
00:04:15,800 --> 00:04:18,133
What we focus on are these conditions,
47
00:04:18,433 --> 00:04:20,866
how do we judge whether it is good or bad
48
00:04:22,133 --> 00:04:24,800
This is the working condition of the backlight screen
49
00:04:26,433 --> 00:04:28,366
Okay, that's all for this lesson
