In this lesson, we talk about the description of the backlight screen circuit in the circuit diagram

2

00:00:06,966 --> 00:00:08,033

Let's take a look

3

00:00:08,600 --> 00:00:10,900

This is the drawing of an Android phone,

4

00:00:11,233 --> 00:00:13,700

the whole drawing of the backlit screen circuit

5

00:00:15,966 --> 00:00:17,333

Of course, in this drawing,

6

00:00:17,566 --> 00:00:20,366

we should first exclude a few points not to see

7

00:00:20,766 --> 00:00:25,900

The first one is this FP, the FP circuit is the fingerprint circuit,

8

00:00:26,400 --> 00:00:30,166

we don't consider it, because we're talking about display

9

00:00:32,200 --> 00:00:34,500

So the other one is TP,

10

00:00:34,966 --> 00:00:38,266

we don't consider the touch circuit that starts with TP

11

00:00:44,100 --> 00:00:48,566

We excluded these two categories, the red and blue ones

12

00:00:49,600 --> 00:00:53,433

Let's look at the power supply of the display circuit we are going to talk about

13

00:00:53,800 --> 00:00:57,733

The power supply of the display circuit is VOUT _1V8,

14

00:00:57,900 --> 00:01:00,400

which is its 1.8 volt power supply

15

00:01:02,866 --> 00:01:06,300

It also has the power supplies VSP and VSN

16

00:01:10,233 --> 00:01:12,033

We put the two of them together,

17

00:01:12,100 --> 00:01:15,133

usually called positive and negative voltage power supply,

18

00:01:15,666 --> 00:01:17,866

that is, screen power supply

19

00:01:18,066 --> 00:01:21,233

It's the power supply for the screen, not the backlight

20

00:01:21,600 --> 00:01:26,333

The general actual voltage of VSP and VSN is about 4.8 volts

21

00:01:28,500 --> 00:01:33,266

VSP is about 5 volts, and VSN is about -5 volts

22

00:01:43,033 --> 00:01:45,200

Then there is another power supply,

23

00:01:45,200 --> 00:01:49,866

that is, the backlight power supply, which is a high-voltage

24

00:01:51,166 --> 00:01:54,366

Let's take a look at the general rule of the backlight power supply

25

00:01:55,066 --> 00:02:01,733

A positive pole, we see that the LED minus 3 minus 1 and minus 2,

26

00:02:02,800 --> 00:02:04,733

minus is actually negative,

27

00:02:05,200 --> 00:02:07,433

which is the negative pole of the backlight,

28

00:02:08,000 --> 00:02:11,633

also called the loop, there are three loops

29

00:02:12,600 --> 00:02:14,800

A positive pole has 3 loops

30

00:02:15,433 --> 00:02:17,366

This is the backlight power supply

31

00:02:17,766 --> 00:02:19,500

What are we going to see after that?

32

00:02:19,933 --> 00:02:22,033

We're going to see the reset of the display,

33

00:02:22,500 --> 00:02:25,100

we see that there are RST, LCD

34

00:02:25,900 --> 00:02:30,633

LCD is the liquid crystal display, RST is the power supply reset

35

00:02:32,266 --> 00:02:34,800

There is also screen detection here,

36

00:02:36,033 --> 00:02:39,833

there are two lines, ID0 ID1

37

00:02:41,833 --> 00:02:46,233

There is also a TE, the sync signal, which is here

38

00:02:47,000 --> 00:02:49,700

J1701 is a display connector,

39

00:02:51,700 --> 00:02:53,633

it is actually a touch connector

40

00:02:56,000 --> 00:02:58,133

We're talking about the display at the moment,

41

00:02:58,700 --> 00:03:01,166

so we'll just look at the display circuit

42

00:03:03,866 --> 00:03:07,966

It also has a bus, also called a communication protocol,

43

00:03:08,300 --> 00:03:11,466

which starts with DSI and has four sets of data,

44

00:03:11,766 --> 00:03:15,900

data 0, data 1, data 2, and data 3

45

00:03:22,566 --> 00:03:24,133

Another is the clock signal

46

00:03:28,000 --> 00:03:32,200

It is not the clock signal of the screen, but the clock signal of the bus,

47

00:03:32,633 --> 00:03:34,100

which everyone should know

48

00:03:36,100 --> 00:03:40,233

Ok, this is a display of the backlight screen circuit in the circuit diagram

49

00:03:41,266 --> 00:03:43,233

Okay, that's it for this lesson
