1

00:00:00,166 --> 00:00:04,666

In this lesson we will talk about other working conditions of OLED screens

2

00:00:05,000 --> 00:00:05,800

detection

3

00:00:06,200 --> 00:00:11,500

Detection is called ID on the circuit, or DET, or both appear at the same time

4

00:00:14,533 --> 00:00:16,266

For example, this mobile phone,

5

00:00:16,433 --> 00:00:19,866

its detection is called LCD_ID_DET

6

00:00:23,333 --> 00:00:26,833

The signal begins with GPIO is also detection

7

00:00:29,833 --> 00:00:31,833

Generally there are two line channels,

8

00:00:31,900 --> 00:00:34,266

only one channel is shown here

9

00:00:47,133 --> 00:00:50,666

It mainly reflects the manufacturer information of the screen

10

00:00:57,000 --> 00:00:59,600

During the maintenance, after booting,

11

00:00:59,866 --> 00:01:03,366

if the screen is not detected, the screen is not bright

12

00:01:06,633 --> 00:01:09,400

Its damage will directly lead to a black screen,

13

00:01:09,633 --> 00:01:11,333

the screen does not display

14

00:01:11,500 --> 00:01:13,433

OK, this is the detection

15

00:01:14,533 --> 00:01:17,066

Let's look at another working condition of it,

16

00:01:17,200 --> 00:01:20,266

the bus, or the communication protocol

17

00:01:24,700 --> 00:01:26,833

It mainly transmits image data,

18

00:01:27,100 --> 00:01:29,533

which is the picture on the mobile phone screen,

19

00:01:29,833 --> 00:01:33,033

mainly through MIPI bus or DSI bus

20

00:01:42,333 --> 00:01:44,466

DSI is usually marked on the drawing

21

00:01:49,566 --> 00:01:54,233

DATA refers to the transmission data, CLK is the clock

22

00:02:07,966 --> 00:02:11,533

LANE refers to the transmission channel of data

23

00:02:19,200 --> 00:02:22,033

EMI is anti-electromagnetic interference,

24

00:02:22,266 --> 00:02:25,733

which means that there are EMI components connected in the circuits

25

00:02:25,733 --> 00:02:27,900

between the display screen and the CPU

26

00:02:38,333 --> 00:02:42,600

Another signal is the synchronization signal, VSYNC

27

00:02:49,800 --> 00:02:52,533

Here are a few working conditions of the display

28

00:02:54,066 --> 00:02:58,233

Let's summarize, there are 5 types of working conditions

29

00:02:58,733 --> 00:03:01,466

No matter which working condition goes wrong,

30

00:03:01,966 --> 00:03:04,266

it will directly lead to a black screen,

31

00:03:04,533 --> 00:03:07,066

that is, the screen does not display

32

00:03:07,633 --> 00:03:12,933

For example, if there is a short circuit or an open circuit in the synchronization,

33

00:03:13,233 --> 00:03:15,300

the mobile phone will not display

34

00:03:16,466 --> 00:03:20,233

For example, whether it is detection or reset,

35

00:03:20,666 --> 00:03:24,300

if there is a short circuit, the screen will not be displayed

36

00:03:26,266 --> 00:03:29,266

OK, here are the working conditions of the display

37

00:03:29,666 --> 00:03:31,533

Okay, that's it for this lesson
