1

00:00:00,166 --> 00:00:03,600

In this class, we talk about the description of the working conditions

2

00:00:03,600 --> 00:00:07,333

of the display circuit of the OLED screen in the drawings

3

00:00:07,533 --> 00:00:11,633

According to its working conditions, let's look at its power supply first

4

00:00:13,266 --> 00:00:18,100

Here is AVDD_7P6, 7.6V power supply

5

00:00:18,966 --> 00:00:23,066

There is also a 3 volts power supply and a 1.8 volts power supply

6

00:00:24,333 --> 00:00:28,566

And the ELVSS here, the -4 volts power supply,

7

00:00:29,100 --> 00:00:32,000

and the other one is 4.6 volts power supply

8

00:00:32,600 --> 00:00:35,466

Let's not look at these two, they are touch

9

00:00:36,800 --> 00:00:38,100

What are we looking for?

10

00:00:40,033 --> 00:00:43,266

These are all display circuits except the blue ones

11

00:00:44,766 --> 00:00:48,433

Here, ELVDD is the 4.6 volts power supply

12

00:00:54,833 --> 00:00:58,633

We see its power going to the socket J6400

13

00:00:59,300 --> 00:01:03,033

This connector, we can think of it as a display

14

00:01:03,333 --> 00:01:06,600

Because the connection of the screen is through this connector

15

00:01:09,500 --> 00:01:13,933

These power supplies or signals are to be given to the display screen

16

00:01:22,200 --> 00:01:25,600

All of these power supplies are supplied from other chips,

17

00:01:25,833 --> 00:01:28,366

and the arrows here indicate the direction

18

00:01:40,866 --> 00:01:45,100

During the power transmission process, there is a 0 ohm resistor

19

00:01:45,366 --> 00:01:47,900

This 0R means 0 ohm resistance

20

00:01:48,466 --> 00:01:49,833

In the actual maintenance,

21

00:01:50,100 --> 00:01:52,700

pay attention to whether it has false welding,

22

00:01:53,166 --> 00:01:55,766

or corrosion, open circuit

23

00:01:57,133 --> 00:02:00,266

This 0 ohm resistor can be regarded as a wire

24

00:02:00,633 --> 00:02:03,333

If there is a problem, we can short it

25

00:02:03,633 --> 00:02:04,966

When is it shorted?

26

00:02:05,133 --> 00:02:06,833

It's all chips on this end

27

00:02:07,200 --> 00:02:09,633

For example, in the pin 31,

28

00:02:10,000 --> 00:02:12,800

when using the diode gear to measure the ground value,

29

00:02:13,033 --> 00:02:14,633

if there is an infinity

30

00:02:15,466 --> 00:02:18,933

we first need to measure this foot to see if it is infinite

31

00:02:20,533 --> 00:02:22,166

If there is no infinity,

32

00:02:22,433 --> 00:02:26,033

it means that there is a problem with this 0 ohm resistor

33

00:02:30,533 --> 00:02:34,233

We can take it off, connect it directly with a wire,

34

00:02:35,266 --> 00:02:37,533

and connect its two pins together

35

00:02:38,033 --> 00:02:39,966

ok, this is its power supply

36

00:02:40,500 --> 00:02:42,300

Next we look at the signal

37

00:02:42,866 --> 00:02:44,400

This is the reset signal

38

00:02:49,766 --> 00:02:53,133

The following VDDP_EN is an enable signal

39

00:02:53,600 --> 00:02:56,500

EL_ON2 is also an enable signal

40

00:02:58,733 --> 00:03:02,600

We should note that the turn-on signals are all sent by the screen,

41

00:03:03,333 --> 00:03:06,300

and only when the power supply chip is supplied to the screen

42

00:03:06,500 --> 00:03:08,600

can it output these power supplies

43

00:03:10,766 --> 00:03:15,300

There is also an interrupt signal below, ERR_INT_N

44

00:03:16,666 --> 00:03:21,266

There is also a sync signal, MDP_VSYNC

45

00:03:21,766 --> 00:03:26,066

There is a detection signal below, LCD_ID_DET

46

00:03:26,766 --> 00:03:28,333

OK, then to the left,

47

00:03:28,333 --> 00:03:32,933

here is the bus, which usually starts with DSI on Android phones,

48

00:03:33,066 --> 00:03:34,700

and D means display

49

00:03:40,666 --> 00:03:44,933

Then here, LANE refers to the data channel

50

00:03:52,900 --> 00:03:57,700

The MIPI bus has a characteristic, it all leads to the CPU

51

00:03:59,466 --> 00:04:01,200

When we fix the no display fault,

52

00:04:01,733 --> 00:04:04,633

we can find its specific pin and open the bitmap

53

00:04:05,233 --> 00:04:08,833

For example, we can find the 27 pin line

54

00:04:11,433 --> 00:04:15,266

We can find this pin with the black test lead of the multimeter

55

00:04:16,633 --> 00:04:19,700

Measure the ground value from the pin of the socket to see

56

00:04:19,700 --> 00:04:23,100

if there is any problem with the channel from it to the CPU

57

00:04:24,333 --> 00:04:27,800

Whether there are components connected in series on the channel,

58

00:04:28,300 --> 00:04:31,233

whether the components in series have false welding,

59

00:04:31,800 --> 00:04:33,800

whether there is an open circuit,

60

00:04:33,966 --> 00:04:36,000

and whether there is a short circuit

61

00:04:36,366 --> 00:04:38,833

We will talk about these later in the maintenance

62

00:04:39,400 --> 00:04:41,933

This is the description of the working conditions

63

00:04:41,933 --> 00:04:44,666

of the OLED screen in the circuit diagram

64

00:04:45,100 --> 00:04:47,233

Okay, that's all for this lesson
