1

00:00:00,166 --> 00:00:05,700

In this class, we will talk about the direct circuits that cause the OLED screen not to display

2

00:00:06,166 --> 00:00:10,400

This is a display connector, we can think it as a screen,

3

00:00:10,633 --> 00:00:13,966

because the screen is connected to the mainboard through a cable

4

00:00:16,066 --> 00:00:17,766

After the phone is turned on,

5

00:00:18,033 --> 00:00:22,500

the power chip provides power and outputs a 1.8 volts to the screen

6

00:00:22,933 --> 00:00:25,600

It outputs a power supply to the LDO,

7

00:00:25,933 --> 00:00:30,500

which is stepped down by the LDO and converted to output a 3V

8

00:00:32,033 --> 00:00:35,766

The CPU detects the screen, resets the screen,

9

00:00:36,166 --> 00:00:39,266

and then feeds back data through the DSI bus

10

00:00:44,933 --> 00:00:46,900

After the screen is detected,

11

00:00:47,033 --> 00:00:50,233

it will output a turn-on signal to the display chip

12

00:01:01,700 --> 00:01:05,866

The display chip will output 3 channels of power supply to the display,

13

00:01:06,666 --> 00:01:10,600

AVDD, ELVDD, ELVSS

14

00:01:14,433 --> 00:01:15,366

At this time,

15

00:01:15,766 --> 00:01:20,666

the CPU transmits the image data to the display screen through the DSI bus,

16

00:01:21,166 --> 00:01:23,900

and the display screen displays the image

17

00:01:29,800 --> 00:01:33,466

This is the general process of OLED screen work

18

00:01:37,166 --> 00:01:41,700

OLED screen does not display and which lines are directly related?

19

00:01:42,333 --> 00:01:43,933

First, the power chip

20

00:01:44,933 --> 00:01:48,100

For example, there is a problem with it itself,

21

00:01:48,333 --> 00:01:51,866

and it cannot provide a 1.8 volts of power

22

00:01:57,766 --> 00:02:00,133

Second, the display chip

23

00:02:00,500 --> 00:02:03,900

This display chip refers to a display power supply chip

24

00:02:04,366 --> 00:02:07,766

There is a problem with the display power supply chip itself,

25

00:02:07,900 --> 00:02:12,466

it does not work, it will not output the 3-way power supplies,

26

00:02:14,300 --> 00:02:17,166

then the display screen can not be displayed

27

00:02:19,800 --> 00:02:22,400

This is the possibility of the power supply chip

28

00:02:23,600 --> 00:02:26,133

Another possibility is the LDO

29

00:02:26,400 --> 00:02:31,300

The LDO chip steps down the power supply of 3.5 to 4 volts,

30

00:02:33,500 --> 00:02:35,766

converts the output to the screen,

31

00:02:35,933 --> 00:02:38,333

and the output is smaller than the input

32

00:02:39,100 --> 00:02:40,900

It is a step-down module

33

00:02:49,900 --> 00:02:52,000

If this LDO module is damaged,

34

00:02:52,266 --> 00:02:55,033

it will also cause the screen not to display

35

00:03:00,900 --> 00:03:03,066

Another possibility is the CPU

36

00:03:03,366 --> 00:03:06,500

In general, we don't consider the CPU,

37

00:03:06,866 --> 00:03:08,800

so, when will we consider it?

38

00:03:09,466 --> 00:03:13,500

For example, this mobile phone has been repaired many times,

39

00:03:14,000 --> 00:03:16,833

and the CPU of this mobile phone is often soldered

40

00:03:19,866 --> 00:03:22,900

We can know by measuring these signals and lines

41

00:03:23,366 --> 00:03:25,466

The mobile phone has not been repaired,

42

00:03:25,800 --> 00:03:28,000

but it has been seriously dropped,

43

00:03:28,300 --> 00:03:32,600

and the position of the heavy drop is within the welding range of the CPU,

44

00:03:33,033 --> 00:03:35,100

we must consider the CPU

45

00:03:35,500 --> 00:03:39,866

If the position of the heavy fall is not within the welding range of the CPU,

46

00:03:41,800 --> 00:03:44,366

The mainboard is not deformed or crushed

47

00:03:46,600 --> 00:03:48,066

We do not consider it

48

00:03:49,200 --> 00:03:54,066

Xiaomi Black Shark, Xiaomi 11 series mobile phones have common problems,

49

00:03:54,400 --> 00:03:56,866

and there are many CPU false welding

50

00:03:58,966 --> 00:04:03,066

When the mobile phone with 888 CPU is not turned on,

51

00:04:03,633 --> 00:04:05,666

we only consider the CPU,

52

00:04:06,100 --> 00:04:08,666

otherwise we generally do not consider it

53

00:04:10,133 --> 00:04:13,233

Display connector, when should we consider it?

54

00:04:14,133 --> 00:04:17,666

When this seat is corroded by water and has poor contact,

55

00:04:18,100 --> 00:04:19,833

we only need to consider it

56

00:04:21,066 --> 00:04:23,866

Because this connector has only one function,

57

00:04:25,100 --> 00:04:29,066

it only conducts power or signals, it is not a chip

58

00:04:29,800 --> 00:04:33,366

If it is not corroded by water, has not been repaired,

59

00:04:33,666 --> 00:04:35,333

and has not been deformed,

60

00:04:35,733 --> 00:04:38,433

it means that it is absolutely no problem,

61

00:04:38,700 --> 00:04:40,766

then we should not move this connector

62

00:04:43,966 --> 00:04:49,500

This is the direct circuit that related to the no dislay fault of the OLED screen

63

00:04:55,566 --> 00:04:57,600

Okay, that's it for this lesson
