1

00:00:00,133 --> 00:00:01,100

In this class,

2

00:00:01,533 --> 00:00:06,900

we will talk about how to repair the fault that the mobile phone can be turned on but does not display

3

00:00:07,133 --> 00:00:08,566

and what are the steps?

4

00:00:09,200 --> 00:00:12,233

First of all, when we get a mobile phone,

5

00:00:12,533 --> 00:00:15,166

we usually first check if the screen is broken

6

00:00:15,833 --> 00:00:18,900

This can be seen without disassembling the mobile phone

7

00:00:20,333 --> 00:00:22,633

How can we see if the screen is broken?

8

00:00:22,933 --> 00:00:29,100

For example, this is a badly broken screen, with tears, or dents

9

00:00:32,833 --> 00:00:36,466

In this case, there must be something wrong with the screen,

10

00:00:36,866 --> 00:00:38,800

even if it can be turned on

11

00:00:39,000 --> 00:00:42,933

Then we need to take a good screen and put it on the mobile phone to test

12

00:00:47,966 --> 00:00:50,900

There will also be a situation in the actual maintenance,

13

00:00:51,166 --> 00:00:52,900

the screen has no problem

14

00:00:54,033 --> 00:00:57,900

I took a good screen to test, it still does not display

15

00:00:58,900 --> 00:01:01,900

At this time, we need to remove the mainboard,

16

00:01:02,066 --> 00:01:06,233

and first check the appearance to see if the mainboard is corroded by water

17

00:01:11,000 --> 00:01:14,233

We focus on the parts related to the display circuits

18

00:01:15,233 --> 00:01:16,800

If there is water corrosion,

19

00:01:17,100 --> 00:01:21,600

we will deal with the water corrosion, or re-solder the chip

20

00:01:23,300 --> 00:01:27,166

If there is no water corrosion, the mainboard is very clean,

21

00:01:27,600 --> 00:01:29,766

but the mobile phone does not display,

22

00:01:30,000 --> 00:01:31,766

what should we do at this time?

23

00:01:32,866 --> 00:01:36,966

We can measure the circuit and measure a working condition in the display circuit

24

00:01:37,500 --> 00:01:42,666

For example, measure the MIPI bus and measure its ground value on the connector

25

00:01:46,700 --> 00:01:48,666

We find the connector socket,

26

00:01:50,200 --> 00:01:52,300

the red test lead is grounded,

27

00:01:52,566 --> 00:01:55,966

and the black test lead is connected with the MIPI bus

28

00:02:00,600 --> 00:02:06,033

MIPI lines are pair-to-pair, and each group is connected in series

29

00:02:06,666 --> 00:02:08,766

In the process leading to the CPU,

30

00:02:09,633 --> 00:02:12,166

there are two inductors connected in series

31

00:02:12,900 --> 00:02:17,066

At this time, we can directly find these nearby pins

32

00:02:17,400 --> 00:02:21,033

If we don't look at the drawings, we directly measure here

33

00:02:21,400 --> 00:02:24,366

Because, this line generally corresponds to this,

34

00:02:25,300 --> 00:02:27,333

and there is a ground wire in the middle

35

00:02:37,633 --> 00:02:41,533

Open a drawing and take a look, such as Xiaomi 9PRO

36

00:02:43,433 --> 00:02:46,200

We open the bitmap and find the display seat

37

00:02:48,466 --> 00:02:51,700

There will be a row inductors next to the display seat,

38

00:02:52,966 --> 00:02:55,766

which are the inductors at the beginning of FL

39

00:02:56,700 --> 00:02:59,766

This end of the inductor is connected to the socket

40

00:03:00,333 --> 00:03:02,333

We use the diode gear to measure this

41

00:03:03,766 --> 00:03:06,800

If there is a ground value, we will ignore it

42

00:03:11,533 --> 00:03:13,433

If there is no ground value measured,

43

00:03:13,666 --> 00:03:17,733

at this time, we have to test the end leading to the CPU again

44

00:03:24,800 --> 00:03:27,000

If there is a ground value on this end,

45

00:03:27,366 --> 00:03:30,666

it means that there is no connection between here and here

46

00:03:31,333 --> 00:03:34,366

It can be removed and shorted here with a wire

47

00:03:36,800 --> 00:03:38,733

This are two line channels,

48

00:03:38,966 --> 00:03:43,133

we use two lines to short circuit, this fault can be repaired

49

00:03:43,900 --> 00:03:45,700

Then there may be a situation

50

00:03:46,200 --> 00:03:47,933

Let's click on this position,

51

00:03:48,533 --> 00:03:52,533

this section is connected to the CPU U3100

52

00:03:53,800 --> 00:03:56,133

If we measure the value to be infinite,

53

00:03:57,000 --> 00:03:59,533

then this phone is complicated to repair

54

00:04:01,300 --> 00:04:04,200

We need to take the CPU off and re-solder

55

00:04:08,233 --> 00:04:13,533

Ok, this is how to repair the no display fault due to the problem of MIPI line

56

00:04:16,966 --> 00:04:18,933

Okay, that's it for this lesson
