We continue the lesson of repairing the fault of no display

2

00:00:04,966 --> 00:00:08,200

When we test that the MIPI bus is not abnormal,

3

00:00:08,566 --> 00:00:12,733

we need to test its other working conditions, such as reset signal,

4

00:00:12,900 --> 00:00:14,100

detection signal

5

00:00:17,200 --> 00:00:20,733

Well, let's take a look at this phone, Xiaomi 9 PRO

6

00:00:21,266 --> 00:00:22,600

We open the bitmap

7

00:00:24,300 --> 00:00:27,300

The bitmap is equivalent to an actual mobile phone,

8

00:00:27,600 --> 00:00:31,033

which corresponds to the circuit components one-to-one

9

00:00:33,233 --> 00:00:36,033

Let's zoom in on it and find its reset,

10

00:00:36,566 --> 00:00:38,966

this is the reset of the touch screen

11

00:00:39,266 --> 00:00:41,866

For example, pin 22 is reset

12

00:00:42,700 --> 00:00:45,000

Let's see where the detection is

13

00:00:45,833 --> 00:00:50,233

This is 3 volts power supply, 1.8 volts power supply

14

00:00:51,333 --> 00:00:56,166

Pin 16 is its detection, LCD_ID_DET

15

00:01:00,666 --> 00:01:02,700

OK, let's see how to analyze

16

00:01:04,600 --> 00:01:07,466

We measure the ground value of the detection pin

17

00:01:07,766 --> 00:01:12,133

Let's first see where the detection pin goes, we light it up,

18

00:01:12,633 --> 00:01:17,633

and we can see that it goes straight to the CPU without going through any components

19

00:01:18,133 --> 00:01:20,500

If we measure the ground value to be normal,

20

00:01:21,033 --> 00:01:24,333

it means that there is no problem with the detection signal,

21

00:01:30,200 --> 00:01:32,266

and we don't need to care about it

22

00:01:34,233 --> 00:01:36,600

If the measured ground value is infinite,

23

00:01:36,900 --> 00:01:39,600

we can see if the connector is falsely soldered

24

00:01:54,133 --> 00:01:58,433

There are only two possibilities, either it has been repaired,

25

00:01:58,866 --> 00:02:03,166

or it is corroded by water, and there will be false welding

26

00:02:05,600 --> 00:02:11,366

We take the corrosion treatment, re-solder the seat, or replace the seat

27

00:02:17,000 --> 00:02:19,300

If it is not the problem of the connector,

28

00:02:19,800 --> 00:02:22,500

it means that there is a problem with the CPU

29

00:02:23,300 --> 00:02:28,000

We have to remove the CPU and re-solder it, and it can be repaired

30

00:02:41,733 --> 00:02:46,866

If we re-solder the CPU and measure the ground value, it still shows infinity

31

00:02:48,966 --> 00:02:53,500

We need to measure the signal point on the CPU to see if there is a ground value,

32

00:02:54,166 --> 00:02:57,233

or there is a problem with the board layer of the mainboard

33

00:02:57,833 --> 00:03:00,033

If there is a problem with the board layer,

34

00:03:00,366 --> 00:03:02,033

it is difficult to repair,

35

00:03:02,333 --> 00:03:05,966

basically, the machine can be returned to the customer

36

00:03:20,533 --> 00:03:23,000

Of course, in this case it is rare

37

00:03:24,566 --> 00:03:28,500

Here's how we can fix it if something goes wrong with the detection pin

38

00:03:29,400 --> 00:03:31,600

Ok, that's all for this lesson
