1

00:00:00,200 --> 00:00:02,800

we talk about how to repair the vote of No Display

2

00:00:02,800 --> 00:00:03,800

in this lesson

3

00:00:04,100 --> 00:00:05,700

if we measure the reset

4

00:00:05,766 --> 00:00:08,999

detection bus there is no problem

5

00:00:09,533 --> 00:00:11,666

at this time we need to test this

6

00:00:12,300 --> 00:00:15,100

volts power supply and 3V power supply

7

00:00:15,266 --> 00:00:18,266

under a power on stage to see if there is any voltage

8

00:00:18,800 --> 00:00:21,100

turn the multimeters DC voltage gear

9

00:00:21,533 --> 00:00:23,499

and the black test lead is grounded

10

00:00:24,500 --> 00:00:25,866

and the red test leads used

11

00:00:25,866 --> 00:00:29,099

to find the position of the 1.8V power supply

12

00:00:29,200 --> 00:00:31,600

and the 3V power supply on the Memeboard

13

00:00:31,900 --> 00:00:34,600

of course the Memeboard must be powered on

14

00:00:36,200 --> 00:00:38,133

let's Xiaomin 9 Pro as an example

15

00:00:38,133 --> 00:00:38,733

to see where

16

00:00:38,733 --> 00:00:41,699

the mailman position of its power supply 1.8

17

00:00:41,700 --> 00:00:43,000

and 3V are

18

00:00:43,733 --> 00:00:47,266

1.8V power supply is here pin 3rd one

19

00:00:47,666 --> 00:00:48,399

V R E G

20

00:00:48,400 --> 00:00:50,366

out 14 a one P 8

21

00:00:51,133 --> 00:00:53,733

this is the 1.8 power supply for the screen

22

00:00:54,266 --> 00:00:57,066

this is the 3V power supply for the screen

23

00:00:57,533 --> 00:00:59,466

let's test here in the booth states

24

00:01:00,533 --> 00:01:03,133

let's see where these 1.8V comes from

25

00:01:03,400 --> 00:01:06,200

it has 2 photographs connected to it

26

00:01:06,533 --> 00:01:09,699

it comes from the power trip you fall to 0 0

27

00:01:10,266 --> 00:01:13,366

if we can measure the 1.8V in this place

28

00:01:13,600 --> 00:01:15,866

then we have to restore the power trip

29

00:01:16,266 --> 00:01:17,899

or replace the power trip

30

00:01:22,500 --> 00:01:23,700

after resortering

31

00:01:24,000 --> 00:01:26,133

we still can't matter this voltage

32

00:01:26,500 --> 00:01:29,133

at this time we need to buy a new one

33

00:01:29,133 --> 00:01:31,066

or remove good power trip

34

00:01:31,100 --> 00:01:33,666

from the disassembly board and replace it

35

00:01:37,100 --> 00:01:39,133

let's look at 3V power supply

36

00:01:39,666 --> 00:01:43,899

I'm 35th pin of the display socket J 64 0 0

37

00:01:44,300 --> 00:01:47,800

VCI 3 P O is the power supply of 3V

38

00:01:49,600 --> 00:01:52,666

when we test we can test at this position

39

00:01:53,133 --> 00:01:55,299

there is a condition for this measurement

40

00:01:56,666 --> 00:01:57,799

the screen of the mobile

41

00:01:57,800 --> 00:01:59,766

phone should be buckled on the seat

42

00:02:00,533 --> 00:02:02,599

and then the power on should be triggered

43

00:02:04,000 --> 00:02:08,100

the 3V power supply comes from this U 64 0 2

44

00:02:09,600 --> 00:02:13,866

in 64 0 2 steps down the V R E G B O B power supply

45

00:02:14,300 --> 00:02:17,133

and outputs the 3V power supply to the screen

46

00:02:19,466 --> 00:02:22,799

at this time if this voltage cannot be married

47

00:02:23,300 --> 00:02:26,166

we can replace the trip use 64 0 2

48

00:02:29,000 --> 00:02:30,533

if we don't have this trip

49

00:02:30,800 --> 00:02:32,000

it's hard to find

50

00:02:32,466 --> 00:02:33,466

what do we do

51

00:02:37,533 --> 00:02:40,166

we can also remove the use 64 0 2

52

00:02:41,000 --> 00:02:42,100

after removing it

53

00:02:42,566 --> 00:02:43,333

short circuit

54

00:02:43,333 --> 00:02:45,899

input power supply and the output power supply

55

00:02:46,266 --> 00:02:48,466

that is connect a wire

56

00:02:49,900 --> 00:02:51,166

and then test again

57

00:03:03,266 --> 00:03:05,466

if the display is normal at this time

58

00:03:05,733 --> 00:03:08,333

it means that there is a problem with the chip

59

00:03:08,700 --> 00:03:10,166

and it does not work

60

00:03:10,533 --> 00:03:13,366

causing the 3V power supply to normal output

61

00:03:14,400 --> 00:03:15,733

well let's summarize

62

00:03:19,166 --> 00:03:21,066

what if we can't matter the voltage

63

00:03:21,066 --> 00:03:22,366

when the power is turned down

64

00:03:40,766 --> 00:03:42,699

first of all make sure

65

00:03:42,700 --> 00:03:45,466

that there is no problem with measured ground value

66

00:03:45,900 --> 00:03:48,000

but this voltage cannot be measured

67

00:03:49,266 --> 00:03:51,133

we can resort the partnership

68

00:03:59,366 --> 00:04:00,566

after resortering

69

00:04:00,766 --> 00:04:02,599

if there is still no voltage

70

00:04:03,100 --> 00:04:05,133

it is time to replace the parkship

71

00:04:10,566 --> 00:04:14,133

this is the case where 1.8V cannot be measured

72

00:04:14,300 --> 00:04:15,966

so what about 3V

73

00:04:16,800 --> 00:04:18,733

it comes from LDO module

74

00:04:26,166 --> 00:04:27,699

if the ground value is normal

75

00:04:27,700 --> 00:04:30,300

and the 3V power supply cannot be measured

76

00:04:32,600 --> 00:04:35,800

we directly replace the chip use 64 0 2

77

00:04:36,500 --> 00:04:38,133

which is a step down trip

78

00:04:38,600 --> 00:04:40,666

and the food is usually repaired

79

00:04:43,600 --> 00:04:45,000

we go to test the game

80

00:04:45,333 --> 00:04:47,533

the voltage can basically be measured

81

00:05:01,266 --> 00:05:02,933

okay that's it for this lesson
