00:00:00,233 --> 00:00:03,966

We talk about how to repair the fault of no display in this lesson

2

00:00:04,366 --> 00:00:06,566

If there is no problem with the bus,

3

00:00:06,766 --> 00:00:09,333

the ground value of reset and detection,

4

00:00:09,733 --> 00:00:13,333

including the power supply of 1.8V and 3V,

5

00:00:14,033 --> 00:00:18,100

we need to detect the 3 power supplies that provide  the display,

6

00:00:18,500 --> 00:00:21,633

that is, the power supplies of the OLED screen,

7

00:00:22,000 --> 00:00:25,666

AVDD, ELVDD and ELVSS

8

00:00:40,333 --> 00:00:43,833

The characteristic of OLED screen power supply is that

9

00:00:44,566 --> 00:00:47,766

there are usually 3 inductors around the power supply chip

10

00:01:05,300 --> 00:01:08,533

Let's take a look at the overall structure of its circuit

11

00:01:09,433 --> 00:01:11,866

This chip is called the screen power supply chip

12

00:01:12,166 --> 00:01:17,300

It mainly boosts the main power supply and outputs a power supply of 7.6 volts

13

00:01:36,100 --> 00:01:38,400

Then this one is 4.6 volts,

14

00:01:38,733 --> 00:01:43,500

ELVSS is a negative voltage, negative 4 volts

15

00:01:44,300 --> 00:01:47,033

Why do we usually think of it as boost?

16

00:01:47,900 --> 00:01:50,100

We can see its output voltage,

17

00:01:50,366 --> 00:01:53,433

it outputs 3 way power supplies to the display

18

00:01:58,033 --> 00:02:04,200

The input is 4.3 volts, the output is 7.6 volts, 4.6 volts

19

00:02:04,900 --> 00:02:08,200

The output voltage is higher than the input voltage,

20

00:02:08,400 --> 00:02:09,833

this is a boost chip

21

00:02:10,666 --> 00:02:12,933

Well, this is a whole frame of it

22

00:02:13,366 --> 00:02:16,700

In fact, it still has some detailed circuits

23

00:02:19,133 --> 00:02:23,500

We can see from the drawing that it has 3 energy storage inductors

24

00:02:38,066 --> 00:02:42,433

This screen power supply chip is called U1701

25

00:02:44,233 --> 00:02:47,766

In this drawing, it is called the screen power supply chip,

26

00:02:48,033 --> 00:02:50,433

which is to supply power to the screen

27

00:02:50,933 --> 00:02:55,066

The VBAT_SYS on the left is the input power supply

28

00:02:56,100 --> 00:03:05,000

That is, it takes a power input to come in and outputs 7.6 volts, 4.6 volts and -4 volts

29

00:03:10,600 --> 00:03:13,700

After this chip adjusts the main power supply voltage,

30

00:03:13,900 --> 00:03:16,633

it outputs 3 channels of power supply

31

00:03:22,000 --> 00:03:25,100

Here we should pay attention to several key components,

32

00:03:25,666 --> 00:03:31,233

L1703, L1701, and this inductor

33

00:03:40,033 --> 00:03:44,266

Its inductance is actually the circuit of this negative 4 volts

34

00:03:45,666 --> 00:03:50,533

Then on the left side of this chip, AGND is also a ground wire

35

00:03:51,533 --> 00:03:57,900

AMOLED_AVDD_EN is an enable signal that turns on this 7.6 volts

36

00:04:15,066 --> 00:04:20,466

AMOLED is the trun on signal of ELVDD and ELVSS,

37

00:04:21,066 --> 00:04:25,900

that is, the turn on signal of 4.6 volts and -4 volts

38

00:04:34,633 --> 00:04:36,966

Okay, that's it for this lesson
