1

00:00:00,233 --> 00:00:02,966

In this class, we will talk about how to repair

2

00:00:02,966 --> 00:00:07,000

when the power supply chip of OLED screen has no voltage output

3

00:00:08,200 --> 00:00:11,366

To get a mainboard, we have to take a look at its appearance

4

00:00:11,566 --> 00:00:14,766

First of all, we have to observe this chip,

5

00:00:15,033 --> 00:00:20,733

which is the chip that outputs 7.6 volts, 4.6 volts and -4 volts

6

00:00:21,100 --> 00:00:23,933

Find this chip and see if it is corroded by water

7

00:00:24,300 --> 00:00:27,533

If there is water ingress, and the phone does not display

8

00:00:29,066 --> 00:00:33,900

At this time, we can also remove the screen power supply chip without testing,

9

00:00:34,433 --> 00:00:37,266

process the pad, and then reinstall the chip

10

00:00:40,533 --> 00:00:42,966

Basically, this failure is fixed

11

00:00:43,400 --> 00:00:45,000

This is a situation

12

00:00:45,433 --> 00:00:49,000

If the chip is not corroded by water, what should we do?

13

00:00:49,766 --> 00:00:52,400

We can measure the ground value of the display chip

14

00:00:55,966 --> 00:01:02,666

The display has 3 ways of power supplies of 7.6, 4.6, -4 volts,

15

00:01:03,066 --> 00:01:05,400

we need to find where the 3 power supplies are

16

00:01:05,966 --> 00:01:08,266

Let's take Xiaomi 11 as an example,

17

00:01:10,300 --> 00:01:12,666

we can directly find its display seat,

18

00:01:12,766 --> 00:01:15,800

which is the place where the screen cable is connected

19

00:01:16,400 --> 00:01:19,700

This is the display seat, J6503,

20

00:01:19,900 --> 00:01:21,966

its power supply is in this position,

21

00:01:23,233 --> 00:01:25,533

ELVSS is -4 volts,

22

00:01:28,666 --> 00:01:31,000

ELVDD is 4.6 volts

23

00:01:33,333 --> 00:01:36,566

We can also quickly find this socket in the circuit diagram

24

00:01:42,266 --> 00:01:46,066

We click "Find Schematic Components" and it jumps here,

25

00:01:46,900 --> 00:01:49,800

J6503 is the display seat

26

00:01:50,933 --> 00:01:55,333

This seat contains a touch circuit, TS, TP means touch circuit

27

00:01:56,066 --> 00:01:59,966

It also has number cards, but who are not our concern

28

00:02:00,833 --> 00:02:03,100

Because we are repairing no display,

29

00:02:03,200 --> 00:02:05,733

we need to find a screen power supply circuit

30

00:02:06,533 --> 00:02:10,266

This is the DSI bus, this is the fingerprint,

31

00:02:10,766 --> 00:02:12,100

we don't care about them

32

00:02:13,866 --> 00:02:20,366

These are the screen power supplies, ELVDD, ELVSS, and AVDD

33

00:02:22,133 --> 00:02:24,366

We click "Find Bitmap Signal"

34

00:02:26,333 --> 00:02:31,100

It can be seen that AVDD passes through the first pin of this resistor,

35

00:02:31,700 --> 00:02:35,600

here is AVDD, the power supply of 7.6 volts

36

00:02:44,300 --> 00:02:47,966

Let's test its ground value here to see if there is any problem

37

00:02:48,366 --> 00:02:50,166

Measure ELVDD here,

38

00:02:50,300 --> 00:02:51,800

measure AVDD here,

39

00:02:52,200 --> 00:02:54,433

and measure ELVSS here,

40

00:02:55,200 --> 00:02:57,233

measure these 3 power supplies,

41

00:02:57,566 --> 00:03:00,466

and see if there is any problem with the ground value

42

00:03:01,500 --> 00:03:03,733

If we measure the ground value to infinity

43

00:03:04,100 --> 00:03:06,433

For example, when we measure the first pin

44

00:03:07,333 --> 00:03:10,966

Let's look at its lines first, it's 7.6 volts,

45

00:03:14,900 --> 00:03:18,266

This R6507 is a 0 ohm resistor,

46

00:03:18,966 --> 00:03:21,700

this end is powered by a 7.6 volts,

47

00:03:22,533 --> 00:03:23,866

then where does it go?

48

00:03:24,300 --> 00:03:28,233

It goes to this screen power supply chip, U6401,

49

00:03:28,533 --> 00:03:30,900

there are three large inductors around it

50

00:03:31,600 --> 00:03:35,600

This is the characteristic of the OLED screen power supply chip

51

00:03:37,666 --> 00:03:41,233

Let's analyze, what should we do if there is infinity

52

00:03:45,500 --> 00:03:50,666

First, infinity has nothing to do with this capacitor C6505,

53

00:03:50,866 --> 00:03:52,200

it is not considered

54

00:03:52,733 --> 00:03:56,733

Infinity is only related to the series components in this line

55

00:03:57,800 --> 00:04:03,166

This R6507 is connected in series at this end, to the point of this chip

56

00:04:04,433 --> 00:04:07,233

It has nothing to do with these 3 capacitors

57

00:04:07,766 --> 00:04:09,133

OK, let's summarize

58

00:04:13,066 --> 00:04:17,000

If we measure the ground value of the first pin of the connector is infinite,

59

00:04:17,333 --> 00:04:19,366

there are several situations

60

00:04:24,766 --> 00:04:30,000

If we measure the value to more than 600 on the second pin of R6507,

61

00:04:31,400 --> 00:04:35,833

it means that R6507 is damaged or falsely soldered

62

00:04:36,266 --> 00:04:42,233

We can directly remove the R6507 and connect its two pins with wires

63

00:04:47,166 --> 00:04:51,800

When we measure that the first pin of R6507 is also infinite

64

00:04:52,200 --> 00:04:55,733

It means that there is a problem with the screen power supply chip

65

00:04:56,533 --> 00:04:58,533

Re-solder or replace it

66

00:04:59,766 --> 00:05:03,033

After re-soldering, it is still infinite,

67

00:05:03,300 --> 00:05:05,233

then we will replace the chip

68

00:05:05,800 --> 00:05:08,033

That way, it's usually solved

69

00:05:08,933 --> 00:05:10,933

Okay, that's it for this lesson
