1

00:00:00,133 --> 00:00:05,933

In this class, we will talk about how to repair the power supply of the screen if the voltage cannot be measured

2

00:00:06,866 --> 00:00:09,200

Let's take Xiaomi 11 as an example,

3

00:00:09,533 --> 00:00:11,866

if we can't measure the power supply voltage

4

00:00:12,533 --> 00:00:16,433

For example, this screen has 3 power supply channels,

5

00:00:16,800 --> 00:00:18,166

this is AVDD,

6

00:00:18,466 --> 00:00:19,966

this is ELVDD,

7

00:00:20,433 --> 00:00:22,333

this is ELVSS

8

00:00:22,833 --> 00:00:26,433

What should we do if we measure it with no problem with ground,

9

00:00:26,633 --> 00:00:28,933

but no voltage can be measured here?

10

00:00:35,633 --> 00:00:38,866

Generally, this is caused by chip damage,

11

00:00:39,433 --> 00:00:41,833

we can just replace the chip directly

12

00:00:45,700 --> 00:00:48,100

What is the premise for us to replace the chip?

13

00:00:49,100 --> 00:00:52,600

There is no problem with the ground value of the screen power supply

14

00:01:03,833 --> 00:01:07,233

Does this seat have any abnormality to the ground value?

15

00:01:09,733 --> 00:01:13,633

First find the position of these three power supplies on the drawing,

16

00:01:15,866 --> 00:01:19,633

AVDD, ELVDD, ELVSS

17

00:01:30,800 --> 00:01:35,266

Find these three points, use the diode gear to measure the ground value

18

00:01:35,666 --> 00:01:38,500

What is good and what is bad about the ground value?

19

00:01:39,800 --> 00:01:43,633

A reference value is given on the maintenance inquiry system

20

00:01:44,066 --> 00:01:48,300

For example, ELVDD, 553,

21

00:01:48,966 --> 00:01:53,766

if the value we measure is similar to this value, we think it is no problem

22

00:01:55,333 --> 00:02:01,466

AVDD is marked here with 678, if we measure 600 or 700,

23

00:02:01,700 --> 00:02:02,900

there is no problem

24

00:02:03,333 --> 00:02:07,366

ELVSS is marked with -492 here

25

00:02:09,100 --> 00:02:11,000

We need to pay attention to a problem,

26

00:02:11,400 --> 00:02:13,533

ELVSS is negative voltage,

27

00:02:16,533 --> 00:02:20,500

when negative voltage is actually measured, we must pay attention

28

00:02:24,100 --> 00:02:29,133

A value of 492 can only be measured by measuring with a red pen,

29

00:02:29,866 --> 00:02:33,866

that is, it must be measured with the red pen of a multimeter,

30

00:02:34,066 --> 00:02:37,133

so that it can display the normal diode value

31

00:02:45,933 --> 00:02:47,866

If measured with a black pen,

32

00:02:48,033 --> 00:02:50,133

it will be close to infinity

33

00:02:51,100 --> 00:02:53,833

OK, this is how to measure the negative voltage

34

00:02:54,333 --> 00:02:56,333

When measuring all negative voltages,

35

00:02:56,733 --> 00:02:58,200

use a red pen to measure

36

00:03:01,666 --> 00:03:06,100

This is the ground value of the 3 way display power supplies we want to measure

37

00:03:06,100 --> 00:03:08,000

before replacing the display chip

38

00:03:09,233 --> 00:03:11,200

Okay, that's it for this lesson
