1

00:00:00,133 --> 00:00:05,266

In this lesson, we will talk about the maintenance of the OLED screen not displaying

2

00:00:06,000 --> 00:00:10,533

We have analyzed the situation that the power supply has an infinite value to the ground

3

00:00:12,033 --> 00:00:17,100

Next, let's take a look at the short circuit of the screen power supply to the ground value

4

00:00:18,466 --> 00:00:20,600

If there is a short circuit in the power supply,

5

00:00:21,500 --> 00:00:26,900

that is, when we measure its ground value, the value is not 553

6

00:00:28,166 --> 00:00:30,900

So what kind of state does the short circuit show?

7

00:00:31,666 --> 00:00:32,966

It shows 0

8

00:00:36,766 --> 00:00:40,233

There is a short circuit to ground, what is the reason?

9

00:00:46,066 --> 00:00:51,533

We only consider components with one end connected to this line and one end grounded,

10

00:00:54,566 --> 00:00:59,166

that is to say, which component is connected to this line at one end

11

00:00:59,700 --> 00:01:02,966

For example, if it is the ELVDD line,

12

00:01:03,400 --> 00:01:05,633

we measure that it is short-circuited

13

00:01:06,966 --> 00:01:12,733

This C6508 has one end connected to this line and the other end is grounded

14

00:01:13,066 --> 00:01:15,033

We must suspect this component

15

00:01:21,266 --> 00:01:26,800

For example, this ELVDD, how to analyze the short circuit we measure

16

00:01:29,733 --> 00:01:36,533

Take off this C6508 first, its line is connected to L6404 in series,

17

00:01:37,266 --> 00:01:39,433

we do not consider this component,

18

00:01:39,833 --> 00:01:42,200

because it is not grounded at both ends

19

00:01:42,500 --> 00:01:48,200

Although the L6404 is connected to this line, the other end is not grounded

20

00:01:50,833 --> 00:01:55,966

This inductor C6423 will be regarded as a wire at this time

21

00:01:56,866 --> 00:02:01,400

It is grounded at one end and connected to this line at the other end

22

00:02:01,866 --> 00:02:07,600

C6424 is also grounded at one end and connected to this line at one end

23

00:02:08,100 --> 00:02:14,166

including the chip U6401 is also connected to this ELVDD at one end

24

00:02:15,466 --> 00:02:17,633

So what components should we consider?

25

00:02:18,066 --> 00:02:26,133

U6401, C6424, C6423, and C6508

26

00:02:33,633 --> 00:02:36,133

We can remove these capacitors first,

27

00:02:37,133 --> 00:02:39,366

and measure again after removing them

28

00:02:42,566 --> 00:02:46,600

If the ground value is restored, the fault will be fixed

29

00:02:47,433 --> 00:02:51,466

If we only remove one capacitor, we don't need to replace it

30

00:02:53,866 --> 00:02:57,066

If it is still not enough to remove this capacitor,

31

00:02:57,400 --> 00:03:00,833

it will be better after removing 3 capacitors at last

32

00:03:01,800 --> 00:03:04,266

These capacitors can be added to it

33

00:03:04,966 --> 00:03:08,400

Make sure that there are at least two capacitors in this line

34

00:03:09,566 --> 00:03:13,600

If all 3 capacitors are taken out and it is still shorted,

35

00:03:14,100 --> 00:03:16,366

at this time we have to remove the chip

36

00:03:16,866 --> 00:03:20,433

Because there are three capacitors plus a chip in this circuit,

37

00:03:21,066 --> 00:03:23,000

it is generally a chip problem

38

00:03:24,166 --> 00:03:28,400

Remove the chip, reinstall it and measure again,

39

00:03:29,466 --> 00:03:32,933

if it is not shorted, the fault will be fixed

40

00:03:35,233 --> 00:03:40,166

If the chip is reinstalled and it still has a short circuit, then replace the chip

41

00:03:43,566 --> 00:03:47,933

This is an example of how to repair ELVDD short circuit

42

00:03:48,300 --> 00:03:50,300

Okay, that's it for this lesson
