96. Search for switch pin and standby power supply
In this lesson, we mainly explain how to find the switch pin, how to find the standby power supply.
Detail
Comments

1

00:00:00,300 --> 00:00:04,033

In this lesson, let's learn the maintenance steps of no touch faults

2

00:00:07,000 --> 00:00:10,400

When the ground value of the power supply is measured to be normal,

3

00:00:11,933 --> 00:00:15,466

it is necessary to measure the next working condition of the touch,

4

00:00:15,500 --> 00:00:18,666

that is, the ground value of the reset signal

5

00:00:19,300 --> 00:00:23,066

If there is infinity in the ground value, how should we analyze it?

6

00:00:24,100 --> 00:00:26,233

Take Xiaomi 11 as an example

7

00:00:26,433 --> 00:00:28,100

Open the schematic diagram

8

00:00:28,566 --> 00:00:30,800

TS is touch, RESET is reset

9

00:00:33,100 --> 00:00:34,733

This line is touch reset

10

00:00:36,466 --> 00:00:39,433

It goes to the pin 45 of the touch connector

11

00:00:41,733 --> 00:00:43,233

We switch to bitmap

12

00:00:45,300 --> 00:00:51,033

Double-click the left mouse utton to select the position number J6503 of the touch connector

13

00:00:51,300 --> 00:00:56,033

Right-click and click find the bitmap component, so you can find the touch connector

14

00:01:00,366 --> 00:01:04,433

This is the bitmap, the connector on the actual mainboard is here

15

00:01:06,600 --> 00:01:11,766

Pin 45 is the touch reset signal, let's take a look at its circuit

16

00:01:17,066 --> 00:01:20,400

There is a capacitor connected to this line, let's ignore it

17

00:01:21,366 --> 00:01:22,800

we continue to search

18

00:01:24,233 --> 00:01:31,400

There is a pull-up resistor here, which is powered by VREG_L2C_1P8 to provide pull-up

19

00:01:33,000 --> 00:01:34,300

we continue to search

20

00:01:35,566 --> 00:01:39,433

It goes to pin C28 of CPU U3100

21

00:01:45,433 --> 00:01:50,900

By learning the diagram, we know that there is a capacitor, a pull-up resistor, a CPU,

22

00:01:50,966 --> 00:01:54,133

and a connector J6503 on this line,

23

00:01:54,566 --> 00:01:56,200

a total of four components

24

00:01:56,500 --> 00:02:01,266

During maintenance, when the reset signal of pin 45 is detected as OL,

25

00:02:02,700 --> 00:02:05,800

we first check whether the connector has been soldered

26

00:02:09,200 --> 00:02:12,600

If the connector has been soldered falsely, just re-solder it,

27

00:02:13,466 --> 00:02:16,333

it will return to normal, and the fault can be repaired

28

00:02:16,900 --> 00:02:21,733

If the connector has not been soldered falsely, we measured its ground value is OL

29

00:02:22,200 --> 00:02:27,733

Because this line only connects to the pins of the CPU, it is difficult to handle at this time

30

00:02:29,766 --> 00:02:32,033

Remove the CPU, re-solder it

31

00:02:35,733 --> 00:02:38,200

After soldering, if it is still infinity,

32

00:02:38,766 --> 00:02:42,000

either the CPU is damaged, or the board is broken

33

00:02:45,500 --> 00:02:47,400

CPU damage is irreparable

34

00:02:48,966 --> 00:02:52,366

If the CPU is not damaged, remove the CPU

35

00:02:52,966 --> 00:02:57,533

One marker of the multimeter is placed at the corresponding point on the CPU,

36

00:02:59,933 --> 00:03:05,433

and one marker is placed at pin 45 to measure the continuity of the circuit.

37

00:03:07,533 --> 00:03:11,266

If the line is connected, it proves that the CPU is broken

38

00:03:12,233 --> 00:03:17,966

If it is OL between these two points, we can use the method of flying wire to solve the fault

39

00:03:20,433 --> 00:03:24,166

These are the repair steps when the reset signal value is infinite

40

00:03:25,633 --> 00:03:27,233

That's all for this lesson
