1

00:00:00,466 --> 00:00:02,066

iPhone trigger circuit

2

00:00:03,633 --> 00:00:07,733

In this video we're going to learn about the no trigger repair process

3

00:00:08,233 --> 00:00:11,700

The maintenance is from simple to complex step by step

4

00:00:13,133 --> 00:00:15,366

No trigger maintenance process 1,

5

00:00:15,633 --> 00:00:19,466

replace the switch cable to eliminate the distribution problem

6

00:00:20,300 --> 00:00:24,766

Because in the actual maintenance, many maintenance is the whole machine

7

00:00:25,166 --> 00:00:29,033

If the switch cable is broken during the disassembly process,

8

00:00:30,133 --> 00:00:33,266

when we press the power button, it may cause no trigger

9

00:00:33,500 --> 00:00:36,733

At this time, we can use tweezers to stub the switch pin

10

00:00:37,633 --> 00:00:41,133

and eliminate the fault caused by the damage of the switch cable

11

00:00:41,566 --> 00:00:42,800

So let's do it

12

00:00:43,766 --> 00:00:49,700

In the maintenance, we first disassemble the machine and connect the adjustable power cord

13

00:00:50,000 --> 00:00:54,766

Then remove the switch cable from it, and we use tweezers to trigger the boot

14

00:00:56,333 --> 00:01:01,033

If the current does not change, it indicates that the mainboard has a problem

15

00:01:02,266 --> 00:01:04,166

If there is a change in the current,

16

00:01:04,533 --> 00:01:08,233

it indicates that the switch cable damage causes no trigger

17

00:01:09,900 --> 00:01:11,766

Ok, that's it for this lesson
