iPhone trigger circuit

2

00:00:03,633 --> 00:00:07,366

In this video we're going to learn about the no trigger repair process

3

00:00:07,666 --> 00:00:09,866

Step 2 of the maintenance process

4

00:00:10,600 --> 00:00:12,633

After the wiring is eliminated,

5

00:00:12,866 --> 00:00:16,433

we can measure whether the diode value of the switch pin is normal

6

00:00:16,566 --> 00:00:19,900

to eliminate the short circuit or open circuit problem

7

00:00:22,200 --> 00:00:24,066

If we measure the value is low,

8

00:00:24,266 --> 00:00:29,333

it is generally the capacitor connected to the line is bad, or the diode is bad

9

00:00:29,900 --> 00:00:33,200

After the elimination of capacitors and diodes,

10

00:00:34,400 --> 00:00:38,700

if the value is still low, it indicates that the power IC is damaged

11

00:00:39,133 --> 00:00:43,200

The repair method is the same for all iphone 7 and older models

12

00:00:43,900 --> 00:00:47,400

Let's take the iphone XS model as an example to measure

13

00:00:48,266 --> 00:00:51,566

First of all, the multimeter to diode gear,

14

00:00:52,033 --> 00:00:55,533

red pen ground, black pen to measure the switch pin

15

00:00:58,633 --> 00:01:01,600

Normal resistance is about 550

16

00:01:01,766 --> 00:01:06,600

If the value is 0, it indicates that the diode connected to the line is damaged

17

00:01:06,733 --> 00:01:08,566

or the capacitor is damaged

18

00:01:09,033 --> 00:01:14,566

After removal, it is not normal, it means that the power IC is damaged

19

00:01:15,500 --> 00:01:20,966

We can look up the diode, capacitor and power IC connected to the line in the bitmap

20

00:01:22,766 --> 00:01:24,500

After clicking the switch pin,

21

00:01:24,566 --> 00:01:29,300

we can first see the connected anti-static diode DZ4310

22

00:01:30,400 --> 00:01:37,033

After passing the safety resistor R4310, it connects to C4310

23

00:01:37,766 --> 00:01:43,866

DZ4310 and C4310 will result in low switch pin values

24

00:01:45,066 --> 00:01:49,233

If the value is still very low after removing these two components,

25

00:01:49,866 --> 00:01:52,466

it indicates that the power IC is damaged

26

00:01:53,633 --> 00:01:55,733

If the measured value is high,

27

00:01:56,300 --> 00:01:59,366

it means that the safety of the line connection is broken,

28

00:01:59,633 --> 00:02:01,300

or the layer is broken

29

00:02:03,100 --> 00:02:05,866

Because what we measure is the value of the chip

30

00:02:08,233 --> 00:02:12,133

If the circuit or fuse between the switch pin and the chip is damaged,

31

00:02:12,333 --> 00:02:15,033

it will result in a high value measured

32

00:02:15,300 --> 00:02:16,800

So let's do this

33

00:02:18,300 --> 00:02:20,933

If OL is displayed during measurement,

34

00:02:21,100 --> 00:02:26,066

it indicates that the safety of the line connection is bad or the layer is broken

35

00:02:27,300 --> 00:02:29,366

After we click the switch pin,

36

00:02:30,600 --> 00:02:35,366

we will find that the pin comes and connects to R4310

37

00:02:36,433 --> 00:02:40,133

R4310 is the safety resistor for the switch pin

38

00:02:41,200 --> 00:02:45,766

After it passes the resistor, it is connected to the power supply IC

39

00:02:47,266 --> 00:02:51,433

If the resistor is damaged, it will result in a higher value

40

00:02:51,800 --> 00:02:57,233

At this time, how do we determine whether the fault is caused by the resistor damage?

41

00:02:59,066 --> 00:03:05,233

We only need to measure the end of the resistor connected to the power IC to see if its value is normal

42

00:03:06,133 --> 00:03:10,466

If the value is normal, it means the safety resistor is damaged

43

00:03:10,666 --> 00:03:12,500

If the value is abnormal,

44

00:03:12,766 --> 00:03:17,000

the cable between the resistor and the power IC is disconnected

45

00:03:20,066 --> 00:03:25,266

At this time, if we want to repair, we can only take off the power IC,

46

00:03:25,833 --> 00:03:28,100

fly a wire from the pad to the resistor

47

00:03:28,433 --> 00:03:30,633

Then weld the power IC onto it

48

00:03:31,100 --> 00:03:33,200

So that's it for this lesson
