102. No trigger maintenance process 4 & 5
In this lesson, we will learn about the no trigger maintenance process 4.
Detail
Comments

1

00:00:01,000 --> 00:00:02,533

iPhone trigger circuit

2

00:00:03,000 --> 00:00:06,833

In this lesson, we will learn about the no trigger maintenance process

3

00:00:07,166 --> 00:00:09,566

No trigger maintenance process 4

4

00:00:10,200 --> 00:00:12,233

If the previous steps are normal,

5

00:00:12,900 --> 00:00:16,100

we need to measure whether the switch pin voltage is normal

6

00:00:17,133 --> 00:00:20,800

The normal switch pin voltage is 1.5 to 1.8V

7

00:00:23,133 --> 00:00:26,900

Next, let's measure the switch pin of the iPhone 12 mainboard

8

00:00:27,533 --> 00:00:30,766

First of all, we connect the power supply

9

00:00:31,400 --> 00:00:35,566

The black pen is grounded and the red pen is used to measure the switch pin

10

00:00:40,566 --> 00:00:44,233

We can see that the switch pin voltage is about 1.75V

11

00:00:45,233 --> 00:00:48,200

If we measure the voltage, the voltage is low,

12

00:00:48,766 --> 00:00:50,166

and it doesn't trigger

13

00:00:50,533 --> 00:00:54,000

It means that the capacitor connected to the switch pin is bad,

14

00:00:54,166 --> 00:00:55,733

or the diode is bad

15

00:00:56,533 --> 00:00:58,900

We can remove the capacitor and diode

16

00:01:00,600 --> 00:01:04,100

For iPhone 11 and 12 series models, the capacitor,

17

00:01:04,200 --> 00:01:09,566

anti static diode and inductor connected to the switch pin are integrated together

18

00:01:11,533 --> 00:01:13,866

This is a drawing of the iPhone 12

19

00:01:14,200 --> 00:01:20,633

The inductor is integrated with a capacitor, an anti static diode and a safety resistor,

20

00:01:22,466 --> 00:01:24,900

three of which make up the component

21

00:01:25,466 --> 00:01:28,466

When capacitors and diodes need to be removed,

22

00:01:28,700 --> 00:01:31,633

the entire component needs to be removed

23

00:01:32,366 --> 00:01:36,966

After we remove it, we need to shorten the first and third pins

24

00:01:40,766 --> 00:01:43,000

We can see its structure in a bitmap

25

00:01:43,733 --> 00:01:49,733

In the bitmap, the switch light pin is only connected to the FL10130

26

00:01:50,233 --> 00:01:54,066

The capacitor and the anti static diode are inside this assembly

27

00:01:54,366 --> 00:01:56,600

When we remove the capacitor and diode,

28

00:01:56,800 --> 00:01:59,200

we need to remove the whole small component

29

00:01:59,566 --> 00:02:04,500

After removal, it is also necessary to short connect the first and the third pins,

30

00:02:05,266 --> 00:02:09,500

otherwise it will cause the line break, and also lead to no trigger

31

00:02:10,300 --> 00:02:12,466

Let's take a look at the actual picture

32

00:02:13,033 --> 00:02:19,200

In the physical image, this element is below the switch seat and is black in surface

33

00:02:19,666 --> 00:02:22,133

We need to remove it in the actual maintenance,

34

00:02:23,300 --> 00:02:26,466

but also need to short connect the first and third pins

35

00:02:27,166 --> 00:02:30,466

After processing, we measure the switch pin voltage

36

00:02:30,800 --> 00:02:34,900

If the voltage is still abnormal, we need to replace the power supply

37

00:02:35,466 --> 00:02:39,366

After replacing the power supply, if the voltage is not normal,

38

00:02:39,766 --> 00:02:42,066

it indicates that the CPU is damaged

39

00:02:42,633 --> 00:02:45,966

If the CPU is damaged, it cannot be repaired

40

00:02:46,833 --> 00:02:49,600

We can only return the machine to the customer

41

00:02:50,400 --> 00:02:52,733

No trigger maintenance process 5

42

00:02:53,166 --> 00:02:57,400

All the previous maintenance steps have been measured and found to be normal

43

00:02:57,666 --> 00:03:01,000

At this time, the power supply itself may be damaged,

44

00:03:01,533 --> 00:03:03,666

we need to replace the power supply

45

00:03:04,266 --> 00:03:07,533

If it does not trigger after replacing the power supply,

46

00:03:07,866 --> 00:03:10,166

it indicates that the CPU is damaged

47

00:03:10,500 --> 00:03:12,733

and we can only return it to the customer

48

00:03:13,200 --> 00:03:15,300

So that's all for this lesson
