1

00:00:00,633 --> 00:00:03,033

High current occurs when iPhone starts up

2

00:00:03,700 --> 00:00:08,433

In this video, we mainly explain the fault identification of high startup current

3

00:00:08,800 --> 00:00:13,400

High startup current actually refers to the current jump when the machine starts up

4

00:00:15,466 --> 00:00:19,433

In a normal machine, its current jumps from about 80mA

5

00:00:22,066 --> 00:00:26,300

So if something goes wrong, it will have a current higher than 80mA,

6

00:00:26,400 --> 00:00:28,400

some of it could be more than 1A,

7

00:00:28,633 --> 00:00:31,500

or it could be 200/300mA

8

00:00:31,900 --> 00:00:34,200

According to the size of the startup current,

9

00:00:34,433 --> 00:00:38,000

the startup current fault can be divided into two types:

10

00:00:38,200 --> 00:00:42,466

the large startup current and the excessively large startup current

11

00:00:42,966 --> 00:00:47,433

In the actual maintenance, some people will call it the boot large short

12

00:00:48,466 --> 00:00:52,466

Boot large short and large startup current are referred to as a fault

13

00:00:53,100 --> 00:00:55,566

Fault symptom of large startup current

14

00:00:56,433 --> 00:00:59,800

After the mainboard is powered on, we trigger the switch,

15

00:01:00,200 --> 00:01:03,800

and the current will jump directly to more than 300mA,

16

00:01:04,000 --> 00:01:05,833

which is a large current fault

17

00:01:06,400 --> 00:01:08,100

In the picture, for example,

18

00:01:08,400 --> 00:01:12,833

when we flip the switch, the current jumps directly to 1.8A

19

00:01:13,533 --> 00:01:18,600

Let's go to the physical objects to observe the fault phenomenon of large current boot

20

00:01:20,566 --> 00:01:23,633

Let's take a look at the startup current of a good mainboard

21

00:01:24,966 --> 00:01:29,033

Once the mainboard is connected to the power cord, we'll trigger the switch

22

00:01:30,300 --> 00:01:34,333

As you can see, the current starts at about 60mA

23

00:01:35,566 --> 00:01:38,033

And this current is a normal jump current

24

00:01:39,700 --> 00:01:42,400

Fault symptom of high current when triggering

25

00:01:42,866 --> 00:01:45,100

This is a piece of XR mainboard

26

00:01:45,933 --> 00:01:51,133

After short-connecting, we can find that the current directly becomes about 2A

27

00:01:51,466 --> 00:01:53,466

Let's look at this 11 mainboard

28

00:01:53,833 --> 00:01:57,166

After connecting the power cord, we trigger the switch

29

00:01:58,200 --> 00:02:03,500

After triggering the switch, the current directly reaches 500 mA

30

00:02:03,966 --> 00:02:06,066

Let's look at this 11 mainboard

31

00:02:06,233 --> 00:02:08,933

The current jump on this mainboard is also abnormal,

32

00:02:09,133 --> 00:02:13,833

it goes from 90mA to 500 or 800mA

33

00:02:14,466 --> 00:02:16,900

This is also trigger high current

34

00:02:17,233 --> 00:02:19,800

Let's take a look at the iPhone 12 mainboard

35

00:02:20,033 --> 00:02:24,700

When we trigger the switch, the current jumps directly to 1.8A

36

00:02:25,466 --> 00:02:29,000

These fault phenomena belong to the trigger high current

37

00:02:31,100 --> 00:02:34,233

The second type of startup current fault phenomenon

38

00:02:34,566 --> 00:02:37,833

When the mainboard is energized, we trigger the switch,

39

00:02:38,166 --> 00:02:42,966

the current will increase instantaneously, and then return to 0

40

00:02:43,433 --> 00:02:46,500

This belongs to the protection of the power supply

41

00:02:47,233 --> 00:02:49,333

It's common on Android machines,

42

00:02:49,933 --> 00:02:52,466

and it's also common on Apple's machines

43

00:02:52,966 --> 00:02:56,266

Let's look at the current phenomenon of trigger protection

44

00:02:57,733 --> 00:03:00,233

We can see that after we turn on the switch,

45

00:03:01,766 --> 00:03:08,100

the current will momentarily reach more than 300mA and then return to 0

46

00:03:08,433 --> 00:03:13,400

Press the on button again, it jumps again, then goes to 0

47

00:03:13,666 --> 00:03:18,733

This phenomenon is triggering a large current, and is a power source protection

48

00:03:19,366 --> 00:03:23,366

Introduction to the fault of excessively large startup current

49

00:03:23,933 --> 00:03:25,700

When the mainboard is powered on,

50

00:03:25,900 --> 00:03:30,766

we will trigger the boot and the current will jump from 100 to 300mA

51

00:03:31,133 --> 00:03:35,166

For example, in the picture, when the mainboard is powered on,

52

00:03:35,500 --> 00:03:40,433

it triggers the switch, and the current changes from about 200mA

53

00:03:41,966 --> 00:03:46,133

The starting current of a normal machine is around 80mA

54

00:03:46,433 --> 00:03:52,200

If the takeoff current is larger than the normal current, about 100 to 300mA,

55

00:03:52,633 --> 00:03:56,100

it belongs to the excessively startup large current

56

00:03:56,766 --> 00:03:58,766

Now let's take a look at the real thing

57

00:04:00,966 --> 00:04:04,433

When the mainboard is powered up, we'll trigger the switch

58

00:04:08,100 --> 00:04:09,666

After triggering the switch,

59

00:04:09,866 --> 00:04:13,600

we can see that the current jumps from more than 200 mA

60

00:04:14,033 --> 00:04:17,166

Then a fault like this would be a high trigger current

61

00:04:18,400 --> 00:04:23,466

But some machines, when triggered, the current jumps from more than 200mA,

62

00:04:23,966 --> 00:04:26,000

but the current can still jump up

63

00:04:28,166 --> 00:04:30,566

This does not affect the system,

64

00:04:31,400 --> 00:04:34,700

we commonly call it power consumption fast failure

65

00:04:35,166 --> 00:04:37,300

So that's it for this lesson
