1

00:00:00,433 --> 00:00:02,266

iPhone startup high current

2

00:00:02,933 --> 00:00:07,633

In this video, we mainly explain the maintenance process of large current after startup

3

00:00:09,100 --> 00:00:12,300

The startup high current means that when the mainboard is energized,

4

00:00:12,366 --> 00:00:17,333

we trigger the switch, the current jumps from more than 100 or 200mA

5

00:00:17,933 --> 00:00:20,100

But some of it does not affect the boot,

6

00:00:20,266 --> 00:00:23,566

sometimes we call it power consumption fast failure

7

00:00:24,833 --> 00:00:26,833

Let's take a look at the repair process

8

00:00:28,166 --> 00:00:31,966

Maintenance process Step 1, appearance inspection

9

00:00:32,366 --> 00:00:33,833

The checks are the same

10

00:00:34,933 --> 00:00:37,000

Step 2 of the maintenance process

11

00:00:37,433 --> 00:00:41,900

After the mobile phone is triggered, the current is more than 200 mA

12

00:00:42,366 --> 00:00:47,566

If it turns on, we can test the phone's function to determine which circuit is responsible

13

00:00:50,266 --> 00:00:54,466

Common functions that lead to high startup current include fingerprint,

14

00:00:54,633 --> 00:00:57,033

photosensitivity, sensing,

15

00:00:57,166 --> 00:01:00,833

compass, and peripheral circuits such as USB

16

00:01:02,933 --> 00:01:04,866

Now let's test the sensitivity

17

00:01:05,233 --> 00:01:10,166

Sensitivity means that the screen automatically brightens when exposed to bright light

18

00:01:12,000 --> 00:01:14,233

Sensing distance is when we make a call,

19

00:01:14,833 --> 00:01:19,700

the screen will automatically turn off when there is an object near the receiver position

20

00:01:22,133 --> 00:01:25,500

If it doesn't turn off, there is a problem with sensing

21

00:01:26,700 --> 00:01:29,666

Let's open the compass and see if it rotates

22

00:01:30,933 --> 00:01:34,700

If it does not rotate, there is a problem with the compass circuit

23

00:01:35,166 --> 00:01:37,400

Measure which function is abnormal,

24

00:01:37,766 --> 00:01:40,766

we can overhaul the corresponding functional circuit

25

00:01:41,166 --> 00:01:43,200

Maintenance process Step 3

26

00:01:43,500 --> 00:01:47,033

If all the functions of the mobile phone are normal when tested,

27

00:01:47,500 --> 00:01:50,466

we can disconnect the cable and test the board again

28

00:01:52,200 --> 00:01:53,966

When the mainboard is powered up,

29

00:01:56,733 --> 00:01:58,966

we use a tweezer to trigger the switch pin,

30

00:01:59,100 --> 00:02:02,733

and we can see that the current starts to jump from 60mA

31

00:02:02,866 --> 00:02:04,866

So this is a normal mainboard

32

00:02:05,200 --> 00:02:09,266

Some external device damage will also lead to a larger startup current

33

00:02:10,600 --> 00:02:15,233

If we pull out the cables and run the power test, the boot current is normal

34

00:02:16,433 --> 00:02:18,400

We can buckle the cable in turn,

35

00:02:18,866 --> 00:02:21,700

determine which external device causes the fault

36

00:02:22,866 --> 00:02:24,866

Ok, that's it for this lesson
