109. Maintenance process Step 2
In this video we are going to focus on the repair process step 2.
Detail
Comments

1

00:00:00,366 --> 00:00:02,633

High current occurs when iPhone starts up

2

00:00:03,033 --> 00:00:05,933

In this video we are going to focus on the repair process

3

00:00:06,433 --> 00:00:08,466

Step 2 of the maintenance process

4

00:00:10,533 --> 00:00:12,133

If there is a thermal imager,

5

00:00:12,333 --> 00:00:16,700

we can use the thermal imager to determine short-circuited or damaged components

6

00:00:17,166 --> 00:00:19,966

The mainboard is energized, the switch is triggered,

7

00:00:20,233 --> 00:00:22,800

and we put the mainboard under the thermal imager

8

00:00:23,433 --> 00:00:25,000

If a component breaks,

9

00:00:25,266 --> 00:00:28,333

the temperature rises and the thermal imager shows it

10

00:00:31,633 --> 00:00:33,300

If there are damaged components,

11

00:00:33,533 --> 00:00:35,900

we will remove or replace them directly

12

00:00:36,400 --> 00:00:37,933

So let me demonstrate

13

00:00:40,933 --> 00:00:44,133

The mainboard is energized, and then trigger the switch

14

00:00:49,366 --> 00:00:53,766

When the mainboard has a high current, the damaged components will be hot

15

00:00:54,533 --> 00:00:57,100

At this point we can look at the thermal imager

16

00:00:57,933 --> 00:01:01,566

If a component is damaged, its temperature will rise sharply

17

00:01:04,033 --> 00:01:08,066

This is a capacitor, we can see that the capacitor is damaged

18

00:01:10,366 --> 00:01:12,833

If the power supply chip is obviously hot,

19

00:01:12,966 --> 00:01:14,700

we don't have to deal with it

20

00:01:15,300 --> 00:01:19,066

Because the power supply chip is used to convert the power supply to the rear pole,

21

00:01:19,300 --> 00:01:23,833

after the rear pole line short circuit, the power supply will be hot firstly

22

00:01:24,266 --> 00:01:26,533

After removing the damaged component,

23

00:01:26,733 --> 00:01:28,200

we trigger the switch

24

00:01:30,066 --> 00:01:33,000

As we can see, the current jump is back to normal

25

00:01:35,133 --> 00:01:37,466

Precautions for using thermal imager

26

00:01:38,133 --> 00:01:39,766

When we're repairing the machine,

27

00:01:41,833 --> 00:01:46,400

if it is a large current immediately after the boot, and then return to 0,

28

00:01:46,633 --> 00:01:48,833

this belongs to the power supply protection

29

00:01:49,400 --> 00:01:53,733

In this case, we can not find the damaged component with the thermal imager

30

00:01:55,966 --> 00:01:56,866

Note 2

31

00:01:57,666 --> 00:02:00,400

When we observe the mainboard under the thermal imager,

32

00:02:00,966 --> 00:02:03,033

if only the main power supply is hot

33

00:02:03,566 --> 00:02:06,233

We can ignore it and wen don't remove the power chip

34

00:02:07,666 --> 00:02:12,266

The fault may be caused by a short circuit in the rear power supply of the power output

35

00:02:14,633 --> 00:02:17,600

We can follow the following maintenance process to operate

36

00:02:18,100 --> 00:02:20,100

So that's all for this lesson
