1

00:00:00,433 --> 00:00:02,800

High current occurs when iPhone starts up

2

00:00:03,200 --> 00:00:06,500

In this lesson, we will learn about the maintenance process

3

00:00:07,366 --> 00:00:09,366

Maintenance process Step 3

4

00:00:09,733 --> 00:00:13,833

If we don't have a thermal imager, we need to repair it the usual way

5

00:00:14,833 --> 00:00:16,900

We can start with the easiest way

6

00:00:17,900 --> 00:00:20,833

After the boot, we touch the mainboard with our hands

7

00:00:20,833 --> 00:00:23,766

to determine whether the mainboard has hot components

8

00:00:25,400 --> 00:00:29,366

If the mainboard is hot, we can smoke the rosin in the hot position,

9

00:00:31,033 --> 00:00:35,400

and then trigger the boot to see if the rosin on the component has melted

10

00:00:35,866 --> 00:00:39,433

If it melts, it means the component is probably damaged

11

00:00:39,633 --> 00:00:41,833

and we need to replace or remove it

12

00:00:42,566 --> 00:00:44,000

So let me demonstrate

13

00:00:45,066 --> 00:00:47,733

Let's take the iPhone 12 mainboard for example

14

00:00:48,000 --> 00:00:51,366

When we connected the power line, we triggered the switch,

15

00:00:52,133 --> 00:00:54,200

and then there was a large current

16

00:00:55,466 --> 00:00:58,400

At this time, we can first use the hand to touch,

17

00:00:58,500 --> 00:01:01,033

see whether there are hot positions on the mainboard

18

00:01:01,666 --> 00:01:04,933

When the current is relatively large, we touch quickly,

19

00:01:05,533 --> 00:01:09,566

do not press hard on it, otherwise it will easily burn the hand

20

00:01:10,033 --> 00:01:13,933

When we find the hot spot, we smoke the rosin in the hot spot

21

00:01:14,333 --> 00:01:19,666

This mainboard, we felt the hard drive was hot, we smoked rosin on the hard drive

22

00:01:28,166 --> 00:01:32,200

After the rosin is smoked, the power is turned on,

23

00:01:33,566 --> 00:01:39,866

and the rosin on the component is melted, where the rosin is melted, which component is damaged

24

00:01:40,366 --> 00:01:43,933

As you can see, the rosin on this capacitor has melted

25

00:01:46,033 --> 00:01:50,233

When the rosin melts, it means the capacitor is probably damaged

26

00:01:50,633 --> 00:01:52,733

We'll remove it and measure it

27

00:01:54,033 --> 00:01:58,066

After we remove the damaged capacitor, trigger the switch

28

00:01:58,900 --> 00:02:01,500

We can see the current jump returning to normal

29

00:02:04,500 --> 00:02:06,500

Maintenance precautions

30

00:02:07,000 --> 00:02:11,466

If the mainboard we are repairing is instantaneously high current protected,

31

00:02:11,566 --> 00:02:13,133

we can skip this step

32

00:02:13,800 --> 00:02:17,600

Because the power supply protection, the current will not continue,

33

00:02:18,066 --> 00:02:20,600

the components on the mainboard will not be hot

34

00:02:20,900 --> 00:02:24,600

So we'll skip this step and use the repair process below

35

00:02:25,200 --> 00:02:28,533

If we touch the mainboard, only find that the power supply is hot,

36

00:02:29,766 --> 00:02:32,633

we do not go to remove or replace the power chip

37

00:02:32,966 --> 00:02:38,000

The power supply chip converts the power supply from the battery to the rear pole components

38

00:02:38,633 --> 00:02:41,266

When the rear pole component has a short circuit,

39

00:02:41,533 --> 00:02:43,633

the power supply will be hot first

40

00:02:44,333 --> 00:02:46,233

So, that's all for this lesson
