High current occurs when iPhone starts up

2

00:00:03,100 --> 00:00:06,933

In this video, we will focus on the repair process step 4

3

00:00:08,233 --> 00:00:11,933

If we cannot judge the damaged components through the above steps,

4

00:00:12,200 --> 00:00:16,166

we need to use a multimeter to judge the mainboard short-circuit position

5

00:00:18,300 --> 00:00:22,900

Measure the diode values of all the power supplies output by the power supply chip

6

00:00:25,066 --> 00:00:30,033

Which power supply value is 0, it shows that this power supply is short circuited,

7

00:00:32,066 --> 00:00:36,533

that represents the components connected to this power supply have been damaged

8

00:00:37,000 --> 00:00:39,000

It could be capacitors or chips

9

00:00:39,400 --> 00:00:40,866

So let me demonstrate

10

00:00:41,700 --> 00:00:45,733

We find the power supply according to the power IC power supply search method

11

00:00:48,533 --> 00:00:51,033

According to the output name of the power supply,

12

00:00:51,266 --> 00:00:53,566

search for the measuring point in the bitmap

13

00:00:54,100 --> 00:00:57,800

The yellow dot in the bitmap allows us to measure the secondary volume

14

00:00:58,500 --> 00:01:02,700

Let's test the first power supply, which has a test spot above the hard disk

15

00:01:05,066 --> 00:01:06,566

Let's go and measure it

16

00:01:07,400 --> 00:01:11,733

When measuring the diode value, the multimeter is set to the diode gear,

17

00:01:13,100 --> 00:01:16,666

the red pen is grounded, and the black pen is measured

18

00:01:19,300 --> 00:01:21,200

The measured value is 34

19

00:01:21,766 --> 00:01:24,100

According to the reference value in the bitmap,

20

00:01:25,233 --> 00:01:28,700

the diode value of this line is only about 35

21

00:01:29,166 --> 00:01:32,433

Some value is very low. If you are not sure,

22

00:01:32,600 --> 00:01:35,433

you can refer to the same location of the ID board

23

00:01:36,000 --> 00:01:39,266

If the measurements are the same, that means it's normal

24

00:01:40,166 --> 00:01:42,533

A number of 0 means a short circuit

25

00:01:43,300 --> 00:01:45,433

Let's measure the second power supply

26

00:01:46,366 --> 00:01:49,233

The power supply has a measuring point on the outside

27

00:01:51,900 --> 00:01:55,066

The measured value is 9, which is very low

28

00:01:57,800 --> 00:01:59,466

This also means normal

29

00:02:00,666 --> 00:02:04,100

When in doubt, we can measure the same ID board to see if the value is correct

30

00:02:06,533 --> 00:02:10,566

We need to measure the power output of the power supply, about 30 ways

31

00:02:11,166 --> 00:02:14,000

If the measuring point is inside the shield when we measure,

32

00:02:14,233 --> 00:02:16,633

we need to remove the shield before measuring

33

00:02:18,933 --> 00:02:22,900

Ok, now we're going to measure the power supply of BUCK SWITCHES,

34

00:02:23,600 --> 00:02:27,366

and we're going to measure the power supply of PP1V8_S2

35

00:02:30,033 --> 00:02:33,333

This power supply is connected by a large number of components,

36

00:02:33,633 --> 00:02:37,966

we can first measure this pin, the value is more than 270

37

00:02:39,066 --> 00:02:40,500

The red pen is grounded,

38

00:02:40,933 --> 00:02:42,900

and the black pen measures this foot position

39

00:02:45,500 --> 00:02:48,400

We measured that the power supply value was 0,

40

00:02:49,266 --> 00:02:53,166

which means that PP1V8_S2 power supply short circuit

41

00:02:53,666 --> 00:02:57,033

A short circuit means that the power supply component is damaged

42

00:02:58,433 --> 00:03:00,700

It could be capacitors, it could be chips

43

00:03:02,166 --> 00:03:03,233

Precautions

44

00:03:04,166 --> 00:03:07,533

The power supply output has more than 30 power supplies,

45

00:03:08,100 --> 00:03:10,366

and it takes time for us to measure

46

00:03:10,866 --> 00:03:14,900

We can start by determining if there's a short circuit in the drive's power supply

47

00:03:15,800 --> 00:03:19,966

We just need to measure the capacitance on the side of the hard drive

48

00:03:20,066 --> 00:03:22,233

Why test the hard disk power supply first?

49

00:03:22,700 --> 00:03:25,300

Because the hard disk power supply is easy to damage

50

00:03:26,000 --> 00:03:29,466

Note 2

51

00:03:29,833 --> 00:03:33,033

Some of the power supplies have very low ground values

52

00:03:33,900 --> 00:03:38,633

For example, GPU power supply, its value is very low, only 1 or 2,

53

00:03:39,866 --> 00:03:43,266

but it does not mean short circuit

54

00:03:43,733 --> 00:03:45,933

This mainboard is the iPhone X mainboard

55

00:03:46,333 --> 00:03:51,500

We measured the power supply of the GPU and it was only 3, but it was normal

56

00:03:52,400 --> 00:03:54,300

The value is already very low

57

00:03:55,200 --> 00:04:00,600

Some multimeters, the value could be more than 3 when the two pens touch together

58

00:04:00,900 --> 00:04:04,366

Low value during measurement does not indicate short circuit

59

00:04:05,066 --> 00:04:09,133

When measuring the multimeter will ring, it does not mean short circuit,

60

00:04:11,000 --> 00:04:12,566

we must look at the value,

61

00:04:13,433 --> 00:04:16,133

the value is 0 to represent short circuit

62

00:04:16,933 --> 00:04:18,800

So that's it for this lesson
