1

00:00:00,400 --> 00:00:02,633

High current occurs when iPhone starts up

2

00:00:03,000 --> 00:00:06,800

In this video, we will learn about the repair process step 5

3

00:00:08,100 --> 00:00:10,733

If we measure a short circuit in the power supply,

4

00:00:11,600 --> 00:00:15,333

we apply the rosin on all the components connected to this line

5

00:00:17,700 --> 00:00:20,400

And trigger the boot to see if the rosin melts

6

00:00:23,566 --> 00:00:28,433

If it melts, that means it's damaged and we need to remove or replace it

7

00:00:31,200 --> 00:00:32,600

So let me demonstrate

8

00:00:33,700 --> 00:00:39,066

In the previous section, we measured a short circuit in PP1V8_S2 power supply

9

00:00:39,500 --> 00:00:43,500

A short circuit means that the components connected to the line are damaged

10

00:00:44,500 --> 00:00:50,500

Double-layer mainboard, we first need to distinguish the upper short circuit or the lower short circuit

11

00:00:51,200 --> 00:00:53,833

If the ground value of the upper layer is 0,

12

00:00:54,433 --> 00:00:57,400

it indicates that the upper mainboard is short-circuited

13

00:00:59,666 --> 00:01:02,333

If the ground value of the lower layer is 0,

14

00:01:02,500 --> 00:01:05,433

it indicates that the lower mainboard is short-circuited

15

00:01:07,333 --> 00:01:10,066

After distinguishing the upper and lower layers,

16

00:01:10,466 --> 00:01:13,166

we smoke the rosin on the components of the mainboard

17

00:01:14,833 --> 00:01:16,966

If the component is inside the shield,

18

00:01:17,233 --> 00:01:20,933

we don't have to smoke it, we smoke the outside first

19

00:01:27,300 --> 00:01:30,766

We apply rosin on the short circuit connecting components

20

00:01:32,333 --> 00:01:37,833

Then power on the switch, trigger the boot, to see if the rosin on the component is melted

21

00:01:38,166 --> 00:01:41,100

If it is melted that means the component is damaged

22

00:01:41,500 --> 00:01:45,833

The power supply will show high current after the machine is turned on

23

00:01:46,333 --> 00:01:48,400

We wait for 3 or 4 seconds,

24

00:01:48,600 --> 00:01:51,466

and then we look at the components of the smoked rosin

25

00:01:51,966 --> 00:01:55,600

We looked at the components of smoked rosin under a microscope

26

00:01:57,333 --> 00:02:00,566

We found that the rosin on this capacitor had melted

27

00:02:02,900 --> 00:02:07,766

It's possible that this capacitor is damaged, causing the high startup current

28

00:02:08,333 --> 00:02:11,000

We'll test it after we remove the capacitor

29

00:02:11,400 --> 00:02:14,800

After the capacitor is removed, we trigger the switch

30

00:02:16,166 --> 00:02:19,533

and we can see that the current changes to 80mA

31

00:02:23,200 --> 00:02:27,300

This indicates that the capacitor damage caused the high startup current

32

00:02:27,633 --> 00:02:29,266

Maintenance precautions

33

00:02:30,066 --> 00:02:32,766

If the melted component is the main power supply,

34

00:02:33,366 --> 00:02:38,100

we do not deal with it, it is likely to be caused by short circuit in the rear pole

35

00:02:39,200 --> 00:02:41,166

So that's it for this lesson
