1

00:00:00,333 --> 00:00:02,400

High current occurs when iPhone starts up

2

00:00:02,833 --> 00:00:06,500

In this lesson, we will focus on the maintenance process step 6

3

00:00:07,066 --> 00:00:10,500

After the rosin is applied, the switch is triggered,

4

00:00:11,366 --> 00:00:13,366

if no hot component is found,

5

00:00:14,133 --> 00:00:17,166

we need to use adjustable power supply to burn the machine

6

00:00:19,466 --> 00:00:20,900

When the machine is burning,

7

00:00:21,266 --> 00:00:25,033

the voltage of the adjustable power supply is adjusted to be consistent

8

00:00:25,033 --> 00:00:27,900

with the voltage of the short-circuit fault point

9

00:00:28,700 --> 00:00:32,833

For example, when we measure a short circuit in 1.8V power supply,

10

00:00:33,300 --> 00:00:36,900

we need adjust the adjustable power supply to 1.8V

11

00:00:38,200 --> 00:00:40,066

If the voltage is too high,

12

00:00:40,233 --> 00:00:42,866

all the components on the line will be damaged

13

00:00:44,700 --> 00:00:49,566

When burning, we first clamp the tweezer with the positive pole of the adjustable power supply,

14

00:00:49,866 --> 00:00:53,566

connect to the short circuit, and then ground the negative pole

15

00:00:55,833 --> 00:00:59,900

Wait about 10 seconds to see if the rosin on the component has melted

16

00:01:02,233 --> 00:01:06,566

Where the rosin is melted, it means the component under the rosin is broken,

17

00:01:06,833 --> 00:01:08,633

including the main power supply

18

00:01:09,166 --> 00:01:10,600

So let me demonstrate

19

00:01:11,200 --> 00:01:16,533

First, let's adjust the voltage to the same voltage as the short-circuited fault point

20

00:01:17,033 --> 00:01:20,566

The fault voltage of short circuit just now is 1.8V,

21

00:01:20,966 --> 00:01:23,533

so we will adjust it to 1.8V

22

00:01:26,566 --> 00:01:30,300

The current does not need to be adjusted, the maximum is OK

23

00:01:30,866 --> 00:01:34,000

We use the red clip of the boot wire to hold the tweezer

24

00:01:35,500 --> 00:01:37,866

The tip of the tweezer has better be thick,

25

00:01:38,400 --> 00:01:41,066

because the current of the burning machine is too large,

26

00:01:41,500 --> 00:01:45,400

the tip of the tweezer is too thin, it is easy to be burnt

27

00:01:46,666 --> 00:01:49,400

We put the tip of the tweezer into the short circuit

28

00:01:53,233 --> 00:01:55,966

A short circuit will connect a lot of components,

29

00:01:56,400 --> 00:01:59,100

so we chose a good short connection location

30

00:01:59,666 --> 00:02:01,533

Do not choose the corner position,

31

00:02:02,033 --> 00:02:04,766

because corner position may lead to short circuit,

32

00:02:05,000 --> 00:02:06,566

the mainboard will be burnt

33

00:02:08,833 --> 00:02:14,233

After positive pole is connected, the black clamp is connected to the screw post position,

34

00:02:14,433 --> 00:02:16,100

that is, the ground wire

35

00:02:17,433 --> 00:02:19,333

After three or four seconds,

36

00:02:19,666 --> 00:02:22,633

let's see if the rosin on the component has melted

37

00:02:23,500 --> 00:02:26,700

Where melting is indicative of component damage

38

00:02:29,200 --> 00:02:31,300

If there is a shield on the component,

39

00:02:33,100 --> 00:02:36,300

we need to remove the shield and smoke the rosin on the component

40

00:02:36,300 --> 00:02:38,766

to see if there is any component damage

41

00:02:42,533 --> 00:02:46,266

The large current of mainboard is generally caused by capacitor damage

42

00:02:47,133 --> 00:02:50,233

If the current is 300 or 400mA,

43

00:02:50,533 --> 00:02:52,566

it is usually because the chip is damaged

44

00:02:53,733 --> 00:02:55,600

So that's all for this lesson
