1

00:00:00,433 --> 00:00:02,200

iPhone startup high current

2

00:00:02,566 --> 00:00:07,533

In this lesson, we mainly explain the maintenance process of large current after startup

3

00:00:08,233 --> 00:00:10,133

Maintenance process Step 4

4

00:00:10,566 --> 00:00:13,800

If the above conventional methods can not troubleshoot,

5

00:00:13,900 --> 00:00:16,000

that is the mainboard has a problem

6

00:00:16,533 --> 00:00:19,166

At this point, we can measure the diode value

7

00:00:19,166 --> 00:00:22,566

of all the LDO power supplied by the power supply output

8

00:00:23,566 --> 00:00:25,133

In the previous lesson,

9

00:00:25,366 --> 00:00:29,100

we talked about the LDO power supply as a low current power supply

10

00:00:29,233 --> 00:00:33,233

So when it shorts out, it causes the trigger current to be too high

11

00:00:33,366 --> 00:00:36,066

We usually test the LDO power supply first

12

00:00:36,633 --> 00:00:38,666

Let's take iPhone 12 as an example

13

00:00:38,666 --> 00:00:42,466

to measure the LDO power supply of the IC output of the power supply

14

00:00:43,033 --> 00:00:46,000

We first find the power supply IC in the component map,

15

00:00:46,166 --> 00:00:48,800

and then find the main power supply in the bitmap

16

00:00:52,233 --> 00:00:56,933

Then jump to the schematic and locate the pin of the power identifier LDO

17

00:01:00,000 --> 00:01:03,100

This power supply refers to LDO power supply,

18

00:01:03,333 --> 00:01:05,333

whose current is relatively small,

19

00:01:06,166 --> 00:01:11,166

such as 200mA, 250mA and 50mA

20

00:01:12,100 --> 00:01:16,600

Select the name, right click, click Find bitmap signal

21

00:01:16,833 --> 00:01:19,400

These yellow dots are the measuring points

22

00:01:21,433 --> 00:01:24,133

We find the measuring points on the physical picture,

23

00:01:24,433 --> 00:01:26,100

the red marker is grounded,

24

00:01:26,366 --> 00:01:28,433

and the black marker is used to measure

25

00:01:29,933 --> 00:01:34,700

Measured a value of 515, the normal value is about 500

26

00:01:36,233 --> 00:01:38,900

We don't need to test the power on this hard drive

27

00:01:39,200 --> 00:01:40,933

This current is relatively large,

28

00:01:41,133 --> 00:01:43,900

it short circuit will lead to a large startup current

29

00:01:44,833 --> 00:01:48,666

Below, we measure the power supply PP3V0_S2,

30

00:01:49,100 --> 00:01:52,000

we could measure the position of the yellow point in the bitmap

31

00:01:55,666 --> 00:01:58,300

This power supply is to the USB chip power,

32

00:01:58,566 --> 00:02:00,900

U9300 is USB

33

00:02:01,166 --> 00:02:03,433

The multimeter is switched to the diode gear,

34

00:02:03,900 --> 00:02:07,266

the red marker is grounded, and the black marker is measured

35

00:02:08,366 --> 00:02:10,866

The measured value is 389,

36

00:02:12,033 --> 00:02:14,600

indicating that the power supply is no problem,

37

00:02:14,866 --> 00:02:17,233

because the normal value is more than 300

38

00:02:17,566 --> 00:02:22,200

If it comes out as 0, that means there's a short circuit in the power supply

39

00:02:22,733 --> 00:02:24,700

Let's remove the capacitor first

40

00:02:25,000 --> 00:02:28,433

If it doesn鈥檛 work, we may need to replace the USB chip

41

00:02:29,300 --> 00:02:32,966

Like the power supply of LDO, we need to measure it

42

00:02:33,766 --> 00:02:36,466

When measured, if the value is 0,

43

00:02:36,633 --> 00:02:39,066

it means that the power supply is short circuited

44

00:02:40,233 --> 00:02:42,866

If the LDO power supply is short-circuited,

45

00:02:43,066 --> 00:02:45,766

the connected capacitor is generally broken,

46

00:02:46,766 --> 00:02:50,100

and the possibility of chip damage is relatively low

47

00:02:50,733 --> 00:02:53,033

Step 5 of the maintenance process

48

00:02:53,466 --> 00:02:56,966

If we measure the LDO power supply without short circuit,

49

00:02:57,366 --> 00:03:00,066

like this situation is more difficult to fix

50

00:03:00,366 --> 00:03:03,600

It may be caused by a short circuit in BUCK power supply

51

00:03:03,900 --> 00:03:06,700

This short circuit is not a complete short circuit

52

00:03:06,766 --> 00:03:08,566

It is a slightly short circuit

53

00:03:09,200 --> 00:03:11,666

Because if there's a complete short circuit,

54

00:03:11,800 --> 00:03:13,900

it will lead to large startup current

55

00:03:14,800 --> 00:03:17,400

High startup current maintenance experience

56

00:03:17,866 --> 00:03:22,433

If the USB chip of iPhone is damaged, the startup current is high

57

00:03:22,900 --> 00:03:24,366

We can just remove the chip

58

00:03:25,933 --> 00:03:29,533

After removal, if the current returns to normal,

59

00:03:29,833 --> 00:03:32,466

it indicates that the USB chip is damaged

60

00:03:33,000 --> 00:03:35,366

We just need to replace the USB chip

61

00:03:36,800 --> 00:03:39,066

If the chip is removed and not installed,

62

00:03:39,533 --> 00:03:41,666

it will lead to the white Apple and restart

63

00:03:42,800 --> 00:03:46,766

If this happens, we just need to solder the USB chip on

64

00:03:49,066 --> 00:03:53,300

This is the end of the maintenance process for excessively large startup current
