1

00:00:00,700 --> 00:00:02,500

High current when iPhone starts up

2

00:00:02,900 --> 00:00:07,733

In this lesson, we mainly explain the advanced principle of high current on the boot

3

00:00:08,166 --> 00:00:09,966

From the previous course,

4

00:00:10,433 --> 00:00:14,800

we know that the power supply IC is mainly to convert the power supply of the battery

5

00:00:14,800 --> 00:00:17,200

into the voltage required by each chip

6

00:00:20,066 --> 00:00:22,533

When the power IC is converting the power supply,

7

00:00:22,633 --> 00:00:23,933

it has two modes,

8

00:00:25,366 --> 00:00:29,200

one is BUCK mode and the other is LDO mode

9

00:00:31,666 --> 00:00:33,666

There are many connections between them

10

00:00:33,833 --> 00:00:35,700

Let's look at it in detail

11

00:00:36,700 --> 00:00:42,000

In the first step, when we plug in the battery or switch on the adjustable power supply,

12

00:00:42,366 --> 00:00:46,633

the main power supply will receive the PP_VDD_MAIN power supply

13

00:00:47,266 --> 00:00:51,800

This main power supply will feed into a number of pins of the power supply IC,

14

00:00:52,433 --> 00:00:57,466

which will provide the operating voltage for the conversion of the BUCK power supply later

15

00:00:58,333 --> 00:00:59,800

When we press the switch,

16

00:01:00,233 --> 00:01:02,766

the switch signal is sent to the main power supply,

17

00:01:02,966 --> 00:01:05,033

which turns on the conversion module

18

00:01:06,500 --> 00:01:09,300

Different modules generate different power supplies

19

00:01:10,133 --> 00:01:14,700

The power supply of BUCK generates a large current through the inductor

20

00:01:15,100 --> 00:01:18,800

The more inductor, the greater the current it generates

21

00:01:19,400 --> 00:01:23,100

For example, some power supplies will have one inductor,

22

00:01:23,600 --> 00:01:28,300

some will have two or even three, and some will have four inductors

23

00:01:28,600 --> 00:01:31,100

When the BUCK power supply is generated,

24

00:01:31,400 --> 00:01:34,533

in addition to providing operating voltage to the chip,

25

00:01:34,866 --> 00:01:40,533

it will return to the chip and provide operating voltage to either the LDO module inside the chip

26

00:01:40,566 --> 00:01:43,466

or the BUCK SWITCHES module inside the chip

27

00:01:44,100 --> 00:01:46,533

After these modules have power supply,

28

00:01:46,666 --> 00:01:50,233

they will convert the LDO power supply without inductor,

29

00:01:50,666 --> 00:01:52,866

and then convert it to power supply,

30

00:01:53,200 --> 00:01:55,500

and its current will be relatively small

31

00:01:56,133 --> 00:02:01,566

Let's use the iPhone 8P model as an example to find drawings and experiment

32

00:02:02,466 --> 00:02:05,666

Because the iPhone 8P model is a long strip mainboard,

33

00:02:06,133 --> 00:02:08,166

it is easier to do experiments

34

00:02:08,633 --> 00:02:13,933

If it is a double-layer mainboard, we need to layer and fit, very troublesome

35

00:02:14,566 --> 00:02:17,133

We find the main power supply in the component map,

36

00:02:17,366 --> 00:02:19,433

and search it in the circuit diagram

37

00:02:19,800 --> 00:02:21,633

After finding the power supply,

38

00:02:22,033 --> 00:02:26,633

let's first look at each power supply module of PP_VDD_MAIN main supply

39

00:02:27,833 --> 00:02:33,500

In the circuit diagram, many names will be marked after the main power supply enters the power IC

40

00:02:34,100 --> 00:02:36,833

Different names represent different power supplies

41

00:02:38,866 --> 00:02:42,766

For example, the main power supply comes and goes into the pins

42

00:02:42,766 --> 00:02:47,700

M15, 16, 17, 18 of the power supply IC

43

00:02:48,900 --> 00:02:53,433

These pins are designed to power routes 0 and 1 of BUCK0

44

00:02:57,066 --> 00:03:00,900

T15, T16, T17, T18,

45

00:03:01,533 --> 00:03:08,066

these pins are mainly powered for the second and third circuits that convert BUCK0 power supply

46

00:03:09,466 --> 00:03:12,366

Let's take a look at the power supply of BUCK0

47

00:03:12,800 --> 00:03:16,300

BUCK0 power supply consists of four inductors,

48

00:03:17,200 --> 00:03:19,100

and its power supply will be marked

49

00:03:19,566 --> 00:03:21,700

For example, the first one,

50

00:03:22,600 --> 00:03:26,233

LX0 refers to the 0 power supply of BUCK0

51

00:03:27,066 --> 00:03:33,800

We have route 1 of BUCK0, route 2 of BUCK0, route 3 of BUCK0

52

00:03:34,433 --> 00:03:38,500

Different pins are used specifically to convert different power supplies

53

00:03:39,400 --> 00:03:43,666

For example, Y15, Y16 and Y17,

54

00:03:44,333 --> 00:03:48,000

they are mainly used to convert the power supply of BUCK7

55

00:03:52,866 --> 00:03:56,033

This power supply refers to the BUCK7 power supply,

56

00:03:56,200 --> 00:03:58,266

which is generated by an inductor

57

00:03:58,733 --> 00:04:01,366

So it has less power supply input pins

58

00:04:02,900 --> 00:04:06,100

Now let's look at the conversion mode of LDO power supply

59

00:04:07,133 --> 00:04:11,700

In this power supply module, the left side belongs to LDO input,

60

00:04:11,833 --> 00:04:14,533

and the right side belongs to LDO output

61

00:04:15,200 --> 00:04:19,366

LDO input, we can see that after the power supply comes in,

62

00:04:19,900 --> 00:04:22,400

it will connect different power supply names

63

00:04:22,833 --> 00:04:24,466

Like the position on the left,

64

00:04:26,166 --> 00:04:30,400

PP1V1_S2 is powered by PP1V25_S2

65

00:04:30,766 --> 00:04:34,500

When the power came in, they switched to a different power supply

66

00:04:35,666 --> 00:04:42,533

PP1V1 is used to convert power supply to LDO4, LDO8 and LDO14

67

00:04:42,933 --> 00:04:45,733

Now let's look at the power supply of LDO4

68

00:04:48,033 --> 00:04:51,400

The power supply of LDO4 is 0.7V,

69

00:04:51,566 --> 00:04:54,966

which is changed from 1.1 to 0.7V

70

00:04:55,500 --> 00:04:58,833

The power supply of LDO 8 is 0.9V,

71

00:04:59,233 --> 00:05:02,366

which is changed from 1.1 to 0.9V

72

00:05:02,933 --> 00:05:06,000

This is a conversion of the LDO power supply

73

00:05:08,100 --> 00:05:09,900

When the power supply is converted,

74

00:05:10,133 --> 00:05:12,566

it is converted to a similar power supply

75

00:05:12,966 --> 00:05:17,033

The power supply advantage of this conversion is a small voltage drop,

76

00:05:17,466 --> 00:05:19,433

which means less battery loss

77

00:05:21,266 --> 00:05:24,200

That way, the battery will last longer

78

00:05:25,233 --> 00:05:29,000

Let's take a look at the SWITCH OUTPUTS power supply conversion module

79

00:05:29,600 --> 00:05:33,900

In the circuit diagram, BUCK3 passes through an inductor

80

00:05:34,333 --> 00:05:37,566

After generating PP1V8_S2 power supply,

81

00:05:38,266 --> 00:05:41,900

we can see that there is a line, back inside the power IC

82

00:05:42,566 --> 00:05:46,000

This power supply will convert SWITCH OUTPUTS power supply

83

00:05:48,133 --> 00:05:52,233

This power supply will be converted into BUCK3_SW1,

84

00:05:52,333 --> 00:05:56,666

BUCK3_SW2, BUCK3_SW3

85

00:05:57,400 --> 00:05:59,700

All three are 1.8V

86

00:06:00,633 --> 00:06:02,900

Ok, that's it for this lesson
