1

00:00:00,166 --> 00:00:02,266

iPhone starts with high current

2

00:00:03,000 --> 00:00:05,166

In this video we mainly explain

3

00:00:05,466 --> 00:00:09,400

Advanced Power-on High Current Principle 2 Verification of Working Principle

4

00:00:10,400 --> 00:00:12,766

According to the video content explained in the previous section

5

00:00:13,000 --> 00:00:15,300

After the BUCK conversion module generates power

6

00:00:15,333 --> 00:00:16,566

will be LDO

7

00:00:17,400 --> 00:00:20,466

And BUCK_SWITCHES module to provide working voltage

8

00:00:20,700 --> 00:00:23,933

These modules then generate some power

9

00:00:24,700 --> 00:00:26,866

that in our actual maintenance

10

00:00:26,866 --> 00:00:29,066

May experience a malfunction

11

00:00:29,633 --> 00:00:33,100

When the LDO power supply of BUCK power supply conversion is short-circuited

12

00:00:33,300 --> 00:00:36,666

Or when the converted BUCK_SWITCHES power supply is short-circuited

13

00:00:37,500 --> 00:00:39,633

Our switching inductors get hot

14

00:00:39,833 --> 00:00:42,900

But when we use a multimeter to measure the secondary body value

15

00:00:42,900 --> 00:00:45,033

His numbers are still normal

16

00:00:45,533 --> 00:00:47,866

In this case the conversion

17

00:00:48,233 --> 00:00:51,800

LDO power supply or BUCK_SWITCHES power supply is caused by a short circuit

18

00:00:52,233 --> 00:00:54,100

Next let's verify

19

00:00:54,733 --> 00:00:59,333

We use the iPhone8P model to find drawings and do experiments

20

00:00:59,533 --> 00:01:02,733

Because the iPhone 8P model is a long strip motherboard

twenty one

00:01:02,733 --> 00:01:04,766

It is more convenient when doing experiments

twenty two

00:01:04,866 --> 00:01:06,400

If it is a double-layer motherboard

twenty three

00:01:06,533 --> 00:01:08,500

It is troublesome to need layered fit

twenty four

00:01:08,633 --> 00:01:11,066

We find the main power in the callout group

25

00:01:11,433 --> 00:01:13,566

Go to the drawings to search for the main power supply

26

00:01:14,333 --> 00:01:16,166

we use the power

27

00:01:16,433 --> 00:01:19,633

BUCK3 power supply as an example to demonstrate

28

00:01:19,966 --> 00:01:21,233

BUCK3 power supply

29

00:01:21,300 --> 00:01:24,833

through the inductor L2730 will generate

30

00:01:25,366 --> 00:01:27,500

PP1V8_S2 power supply

31

00:01:28,066 --> 00:01:31,666

PP1V8_S2 power supply will return to the inside of the chip

32

00:01:31,700 --> 00:01:36,300

Used to convert BUCK3_SW1, 2, 3

33

00:01:36,600 --> 00:01:38,133

then we will

34

00:01:38,866 --> 00:01:41,200

The power supply capacitor of BUCK3_SW3

35

00:01:45,900 --> 00:01:49,500

Let's take a look after C3622 is shorted

36

00:01:50,000 --> 00:01:50,800

inductance

37

00:01:51,766 --> 00:01:53,200

L2730

38

00:01:54,900 --> 00:01:56,066

Will it be hot?

39

00:01:57,433 --> 00:01:59,800

After we short circuit C3622

40

00:01:59,833 --> 00:02:03,066

Rosin on Inductor L2730

41

00:02:03,066 --> 00:02:06,400

Let's turn it on again and see if the rosin melts

42

00:02:06,666 --> 00:02:09,833

After C3622 is shorted, we trigger the switch

43

00:02:12,933 --> 00:02:14,933

At this time we can see the current

44

00:02:14,933 --> 00:02:16,100

Directly around 700mA

45

00:02:16,633 --> 00:02:17,800

At this time we are

46

00:02:17,866 --> 00:02:19,733

See if the rosin melts

47

00:02:20,133 --> 00:02:21,366

After triggering the switch

48

00:02:21,566 --> 00:02:24,166

The rosin on the inductor melts slowly

49

00:02:28,100 --> 00:02:29,333

after a while

50

00:02:29,333 --> 00:02:30,533

We can see that

51

00:02:30,833 --> 00:02:32,933

The rosin on the inductor has melted

52

00:02:33,200 --> 00:02:34,900

Let's measure again next time

53

00:02:35,200 --> 00:02:36,866

The ground value of this power supply

54

00:02:37,166 --> 00:02:40,533

We will find that the diode value is still normal

55

00:02:41,033 --> 00:02:43,166

Let's verify it next

56

00:02:43,300 --> 00:02:45,733

BUCK power supply to LDO power supply

57

00:02:45,733 --> 00:02:48,533

After the LDO power supply is short-circuited, it will also cause

58

00:02:49,333 --> 00:02:51,133

Inductor generating current heats up

59

00:02:51,433 --> 00:02:55,766

Let's take BUCK4, PP1V1_S2 power supply as an example

60

00:02:56,266 --> 00:02:59,933

Then this power supply will return to the inside of the chip

61

00:03:05,033 --> 00:03:07,466

Used to transfer LDO4

62

00:03:07,966 --> 00:03:11,266

LDO8 and LDO14

63

00:03:11,500 --> 00:03:14,566

Then we will supply power to LDO8

64

00:03:17,033 --> 00:03:18,900

0.9V HDD power supply

65

00:03:21,066 --> 00:03:22,866

The capacitor above the supply line

66

00:03:23,333 --> 00:03:25,000

C2602 short circuit

67

00:03:25,200 --> 00:03:27,833

Let's take a look later

68

00:03:29,133 --> 00:03:30,066

BUCK4

69

00:03:30,833 --> 00:03:32,000

Power supply inductance

70

00:03:32,500 --> 00:03:35,133

Does the L2741 get hot?

71

00:03:35,666 --> 00:03:39,066

Below we short the capacitor C2602

72

00:03:39,066 --> 00:03:42,000

Then smoke the inductor L2741 with rosin

73

00:03:42,200 --> 00:03:45,766

We're triggering the boot to see if the rosin melts

74

00:03:45,966 --> 00:03:48,366

After power on, the current becomes 500mA

75

00:03:48,666 --> 00:03:50,933

Below we are under the microscope

76

00:03:50,966 --> 00:03:52,400

Will the inductor melt?

77

00:03:53,166 --> 00:03:55,833

Inductor L2741

78

00:03:55,966 --> 00:03:58,533

Found that the rosin on the top is slowly melting

79

00:04:06,500 --> 00:04:07,800

wait about 1 minute

80

00:04:07,866 --> 00:04:08,900

we will find

81

00:04:09,000 --> 00:04:11,400

The rosin on the inductor has melted

82

00:04:11,400 --> 00:04:11,966

after power outage

83

00:04:12,000 --> 00:04:12,466

below

84

00:04:12,466 --> 00:04:15,566

We use a multimeter to measure the resistance of the power supply

85

00:04:16,366 --> 00:04:17,633

At this time we found

86

00:04:17,766 --> 00:04:20,533

The value of the power supply is around 50

87

00:04:21,566 --> 00:04:23,533

At this time, the board is a little hot

88

00:04:23,533 --> 00:04:25,233

So the value is low

89

00:04:26,266 --> 00:04:27,766

When we repair

90

00:04:27,833 --> 00:04:29,566

this may happen

91

00:04:29,966 --> 00:04:31,000

Inductor is hot

92

00:04:31,033 --> 00:04:34,566

But when we measure the secondary body value, the value is normal

93

00:04:34,700 --> 00:04:36,300

At this time we have to think

94

00:04:36,300 --> 00:04:39,700

It may be that the inductance is hot caused by the conversion circuit of the rear pole

95

00:04:40,300 --> 00:04:42,033

During our actual maintenance

96

00:04:42,500 --> 00:04:44,633

There may also be a glitch

97

00:04:45,600 --> 00:04:46,966

It is the high current at startup

98

00:04:47,033 --> 00:04:48,433

but we measure

99

00:04:48,533 --> 00:04:51,400

When all BUCK power supply and LDO power supply

100

00:04:51,400 --> 00:04:52,733

he didn't short circuit

101

00:04:52,966 --> 00:04:56,233

But the current is very large after starting up

102

00:04:56,433 --> 00:04:57,600

like this situation

103

00:04:57,600 --> 00:04:58,533

possible

104

00:04:58,533 --> 00:05:01,633

It is caused by the empty welding of the inductor powered by BUCK

105

00:05:02,466 --> 00:05:04,966

Because the mobile phone motherboard is relatively small

106

00:05:05,566 --> 00:05:07,100

His switching MOS tube

107

00:05:07,100 --> 00:05:09,600

are integrated inside the power IC

108

00:05:09,700 --> 00:05:12,000

Then the inductor is externally

109

00:05:12,200 --> 00:05:14,400

Then if the inductor is air-welded

110

00:05:14,400 --> 00:05:17,600

It will cause the internal switch tube to work abnormally.

111

00:05:17,600 --> 00:05:19,400

resulting in high current

112

00:05:19,900 --> 00:05:21,666

Power-on high current fault

113

00:05:22,333 --> 00:05:23,866

all the course content

114

00:05:23,866 --> 00:05:25,933

we're done talking here
