1

00:00:00,433 --> 00:00:02,633

Small startup current of iPhone

2

00:00:03,200 --> 00:00:08,200

In this lesson, we will focus on small current fault identification

3

00:00:09,166 --> 00:00:13,600

Small current means that when the mainboard is connected to the adjustable power supply,

4

00:00:13,733 --> 00:00:15,133

we trigger the switch

5

00:00:15,433 --> 00:00:18,000

The current displayed is relatively small

6

00:00:18,600 --> 00:00:22,700

Only tens or tens of milliamps, and the machine doesn't turn on

7

00:00:23,100 --> 00:00:26,233

This phenomenon is defined as a small current fault

8

00:00:26,900 --> 00:00:31,500

In iPhones, the startup current is different from different machines

9

00:00:33,800 --> 00:00:38,966

For example, the starting current of iPhone 6 series is about 70mA

10

00:00:39,166 --> 00:00:44,933

For iPhone 6S to xs max models, the startup current is about 50mA

11

00:00:46,033 --> 00:00:50,800

The starting current of iPhone 11 and 12 series is about 80mA

12

00:00:52,300 --> 00:00:56,100

Startup small current fault refers to the mainboard is energized,

13

00:00:56,400 --> 00:01:00,733

we trigger the switch, the startup current is between 0-30mA,

14

00:01:00,933 --> 00:01:02,700

which is a small current fault

15

00:01:03,866 --> 00:01:07,333

According to different models of the takeoff current is not the same,

16

00:01:07,566 --> 00:01:10,166

there are some differences in the actual judgment

17

00:01:10,733 --> 00:01:14,533

For example, the mainboard of iPhone 12 in the picture,

18

00:01:15,333 --> 00:01:17,900

its normal startup current is 80mA

19

00:01:19,133 --> 00:01:23,133

The small current fault of this model is that when we press the switch,

20

00:01:23,800 --> 00:01:28,600

its current is about 40/ 50mA, which is a small current fault

21

00:01:29,000 --> 00:01:31,866

Generally speaking, after pressing the switch,

22

00:01:32,066 --> 00:01:35,366

the current is less than half of the normal start current,

23

00:01:35,533 --> 00:01:37,333

it is a small current fault

24

00:01:37,900 --> 00:01:42,000

Now let's observe the physical mainboard small current fault phenomenon

25

00:01:43,100 --> 00:01:45,933

Let's look at the trigger current of the iPhone7

26

00:01:48,200 --> 00:01:53,300

After the switch is triggered, the current starts to jump from about 50mA,

27

00:01:53,666 --> 00:01:55,600

which is a normal current jump

28

00:01:56,500 --> 00:02:00,566

After the switch is triggered, the current is only 19mA,

29

00:02:01,433 --> 00:02:04,700

and it does not move, which is a small current fault

30

00:02:08,033 --> 00:02:10,833

Let's take a look at the iPhone X's current jump

31

00:02:12,666 --> 00:02:14,000

When the switch is triggered,

32

00:02:14,133 --> 00:02:16,766

the current jumps from more than 50 milliamps

33

00:02:17,233 --> 00:02:20,133

Let's look at the small current fault of iPhone X

34

00:02:21,633 --> 00:02:26,400

After the switch is triggered, the current is only 24mA and is frozen,

35

00:02:26,900 --> 00:02:28,766

which is a small current fault

36

00:02:29,800 --> 00:02:32,666

Let's look at the trigger current of the iPhone 12

37

00:02:33,433 --> 00:02:38,233

After the switch is triggered, the current starts to jump from about 80mA,

38

00:02:38,500 --> 00:02:40,300

which is a normal current jump

39

00:02:41,600 --> 00:02:46,166

After triggering the switch, the current is set at 47mA,

40

00:02:46,333 --> 00:02:48,366

which is a small current fault

41

00:02:50,833 --> 00:02:56,466

As we have just seen, if the starting current is less than half of the normal starting current,

42

00:02:56,700 --> 00:02:58,866

it is usually a small current fault

43

00:02:59,433 --> 00:03:01,366

So, that's it for this lesson
