1

00:00:00,466 --> 00:00:02,533

Small startup current of iPhone

2

00:00:02,833 --> 00:00:09,233

In this lesson, we will focus on the common terms explanations used in startup small current circuits

3

00:00:10,300 --> 00:00:14,233

There are several terms commonly used in startup small current circuit

4

00:00:14,533 --> 00:00:18,366

The first two terms we have learnt in the boot high current circuit

5

00:00:19,633 --> 00:00:23,300

LDO refers to the power supply output of small current,

6

00:00:23,633 --> 00:00:27,633

while BUCK refers to the power supply output of large current

7

00:00:28,366 --> 00:00:33,700

CLK refers to the clock signal and RESET refers to the reset signal

8

00:00:33,933 --> 00:00:36,533

In electronics, for a chip to work,

9

00:00:36,833 --> 00:00:40,600

it first needs power, clock signal and reset signal

10

00:00:41,633 --> 00:00:46,300

The clock signal refers to the frequency that electronic products need to work

11

00:00:49,433 --> 00:00:53,500

The higher the clock frequency, the faster the chip runs

12

00:00:54,766 --> 00:00:56,866

RESET is a reset signal

13

00:00:57,100 --> 00:00:59,800

When the chip is working, there is a reset signal

14

00:01:00,566 --> 00:01:03,400

It is mainly used to make the chip work from the beginning

15

00:01:07,233 --> 00:01:12,733

Without this reset signal, the chip may not work and may remain in its original state

16

00:01:16,100 --> 00:01:20,800

TEST_CLKOUT, this is the test clock output

17

00:01:21,566 --> 00:01:24,000

When the clock circuit is working properly,

18

00:01:24,100 --> 00:01:26,066

it will issue a test clock

19

00:01:26,700 --> 00:01:31,733

SYSTEM_COLD_RESET, this is a system-wide reset,

20

00:01:32,266 --> 00:01:34,600

in the iPhone it's a CPU reset signal

21

00:01:37,100 --> 00:01:40,133

The CPU also needs a reset signal for it to work

22

00:01:42,266 --> 00:01:44,200

So that's all for this lesson
