1

00:00:00,833 --> 00:00:03,000

Small current when iPhone is turned on

2

00:00:03,400 --> 00:00:08,566

In this lesson, we mainly learn the working principle of the small current circuit when starting up

3

00:00:08,900 --> 00:00:12,933

The working principle of small current is suitable for all Apple models

4

00:00:13,366 --> 00:00:16,033

Let's take a look at the workflow of small current

5

00:00:17,666 --> 00:00:22,233

First step, when we buckle the battery or connect the adjustable power supply,

6

00:00:22,466 --> 00:00:24,733

the main power supply will be generated

7

00:00:25,500 --> 00:00:29,500

In the second step, after the main power supply receives the main power supply,

8

00:00:29,800 --> 00:00:33,600

it will generate PP1V8_ALWAYS standby power supply

9

00:00:34,533 --> 00:00:38,433

In the third step, after the power supply generates standby power,

10

00:00:38,666 --> 00:00:41,333

it will be connected through the circuit inside the chip

11

00:00:41,333 --> 00:00:44,633

to provide a pull-up voltage for the switch pin

12

00:00:46,700 --> 00:00:50,200

The fourth step, when we short the switch pin,

13

00:00:51,566 --> 00:00:55,733

the switch pin voltage will change from 1.8V to 0V

14

00:00:56,700 --> 00:00:59,600

This signal will be sent to the main power supply

15

00:01:00,233 --> 00:01:03,166

After the main power supply receives the power-on signal,

16

00:01:03,400 --> 00:01:06,033

it will generate more than 30 power supplies,

17

00:01:06,433 --> 00:01:09,866

which will provide working voltage for the chip on the mainboard

18

00:01:12,133 --> 00:01:15,900

With so many chips on the mainboard, the CPU will work first,

19

00:01:17,600 --> 00:01:21,600

and the chip needs power supply, clock signal and reset signal to work

20

00:01:24,300 --> 00:01:27,333

After booting, the CPU has power supply

21

00:01:27,700 --> 00:01:32,633

After the CPU has power supply, the clock module inside the CPU starts to work,

22

00:01:33,333 --> 00:01:37,433

providing a working voltage for the 24M crystal oscillator

23

00:01:38,533 --> 00:01:40,766

After the crystal oscillator is powered,

24

00:01:41,033 --> 00:01:43,766

it will generate a 24M clock signal

25

00:01:43,933 --> 00:01:49,733

and return it to the CPU to provide a reference clock for the clock module inside the CPU

26

00:01:51,933 --> 00:01:55,833

This clock will provide a clock signal for future working circuits

27

00:01:57,066 --> 00:01:59,066

When the clock module works normally,

28

00:01:59,733 --> 00:02:04,800

it will send a test clock to the main power supply, TEST_CLKOUT

29

00:02:06,866 --> 00:02:09,500

After the main power supply receives the test clock,

30

00:02:09,900 --> 00:02:12,400

it will send a reset signal to the CPU

31

00:02:13,300 --> 00:02:17,600

After the CPU has power supply, clock signal and reset signal,

32

00:02:17,900 --> 00:02:20,966

its internal integrated startup module will work

33

00:02:22,333 --> 00:02:26,366

After the startup module works, it will consume power,

34

00:02:27,066 --> 00:02:30,500

and the current will be displayed on the adjustable power supply

35

00:02:31,166 --> 00:02:34,566

Small current means that the startup module does not work at all,

36

00:02:36,000 --> 00:02:39,933

So we see that the current on the adjustable power supply is very small

37

00:02:40,833 --> 00:02:42,700

If the startup module wants to work,

38

00:02:43,033 --> 00:02:46,400

it needs power supply, clock signal and reset signal

39

00:02:47,033 --> 00:02:50,066

If one of these three conditions is abnormal,

40

00:02:50,333 --> 00:02:52,533

it will cause a small current fault

41

00:02:53,266 --> 00:02:59,166

When we overhaul, we need to overhaul the CPU's power supply, clock signal and reset signal

42

00:03:00,000 --> 00:03:01,766

That's all for this video
