Small current when iPhone is turned on

2

00:00:03,566 --> 00:00:08,600

In this video, we will mainly verify the working principle of the small power-on current

3

00:00:09,133 --> 00:00:13,100

We know that the CPU lacks power supply, clock signal and reset signal,

4

00:00:13,666 --> 00:00:15,933

which will lead to small current faults

5

00:00:17,500 --> 00:00:22,433

Let's remove the 24M crystal oscillator first, or disconnect the line,

6

00:00:22,566 --> 00:00:24,600

and observe the change of current

7

00:00:27,100 --> 00:00:29,533

Let's take the iPhone X model as an example

8

00:00:30,100 --> 00:00:33,433

Find the 24M crystal oscillator in the component map,

9

00:00:35,366 --> 00:00:38,300

and search for its position number in the circuit diagram

10

00:00:41,966 --> 00:00:44,366

After finding the crystal oscillator,

11

00:00:44,566 --> 00:00:49,700

we can see that the crystal oscillator pin passes through a resistor R1011,

12

00:00:49,833 --> 00:00:51,766

and then connects to the CPU

13

00:00:52,433 --> 00:00:55,300

The other pin is directly connected to the CPU

14

00:00:55,666 --> 00:00:58,633

After removing the resistor R1011,

15

00:00:58,900 --> 00:01:02,333

let's turn it on to see if it will cause a small current

16

00:01:03,166 --> 00:01:06,700

We first find the position of R1011 in the bitmap,

17

00:01:12,700 --> 00:01:15,300

the resistor is below the crystal oscillator

18

00:01:16,133 --> 00:01:19,533

Let's take a look at the take-off current of the iPhone X mainboard

19

00:01:22,133 --> 00:01:27,000

After the switch is triggered, the current starts to jump from 50mA

20

00:01:28,333 --> 00:01:34,100

Next, after we remove the resistor R1011, look at the start-up current

21

00:01:43,033 --> 00:01:47,000

After the resistor is removed, we trigger the switch,

22

00:01:50,366 --> 00:01:54,733

the current is only 24mA, which is half of the normal current,

23

00:01:55,066 --> 00:01:57,133

which is 50mA normally

24

00:01:57,600 --> 00:02:02,566

Next, we disconnect or ground the reset of the CPU, and then test it

25

00:02:07,100 --> 00:02:09,833

We search for COLD_RESET in circuit diagram

26

00:02:14,100 --> 00:02:20,466

The reset signal of the CPU is connected with other reset signals through a resistor R1020

27

00:02:22,666 --> 00:02:27,200

Let's take a look at the position of R1020 in the physical object

28

00:02:31,466 --> 00:02:35,233

It is at the bottom side of the CPU, above the USB chip

29

00:02:38,266 --> 00:02:43,766

We remove the resistor R1020, and then turn on the power to test the current

30

00:02:49,600 --> 00:02:52,300

After removal, we trigger the switch,

31

00:02:55,800 --> 00:02:58,200

the current is only 41mA,

32

00:02:58,966 --> 00:03:02,233

which is about 10mA less than the normal current

33

00:03:04,866 --> 00:03:11,900

Through testing, we found that problems with the clock signal and reset signal will cause small current

34

00:03:13,333 --> 00:03:17,600

If the power supply inductor of the CPU is removed or falsely soldered,

35

00:03:17,966 --> 00:03:19,733

it may cause a large current

36

00:03:20,133 --> 00:03:22,166

If you're interested you can test it

37

00:03:22,500 --> 00:03:24,566

Ok, that's all for this video
